Copyright 2000 Carrier Corporation
Product
Data
Deluxe 4-Way Multipoise
Direct-Vent Variable-Capacity
Deluxe Condensing Gas Furnace
Input Capacities: 40,000 thru 120,000 Btuh
58MVP
Series 140 & 150
Comfort Heat Technology™,
the ultimate in
heating comfort . . .
The Carrier 58MVP WeatherMaker™
Infinity with Comfort Heat Technol-
ogy achieves the optimum combina-
tion of comfort and efficency.
The WeatherMaker Infinity achieves
industry-leading ultra-high efficiency
at up to 96.6 percent Annual Fuel
Utilization Efficiency (AFUE).
Efficient performance is enhanced
through the variable-capacity design.
To maintain ideal comfort, Comfort
Heat Technology automatically
adjusts the heating level, maximizing
the use of low heating levels that
produce near silent furnace operation
while meeting the exact heating needs.
This unit is designed to keep the in-
door temperature within 1 degree of
the thermostat setpoint. Because it op-
erates in low speed most of the time,
the model 58MVP uses up to 80% less
power than single-capacity furnaces.
In addition to providing ultimate
comfort, the model 58MVP has a
sealed combustion system. This
system brings combustion air from
outdoors to the furnace and vents
flue gases safely outside the home.
Because it is sealed, operational noise
is minimal. A sealed combustion
system also means fewer cold drafts
and less air infiltration.
Quality materials are the key behind the
model 58MVP's outstanding
performance. Carrier stands behind
quality. We offer lifetime warranty
protection* on the heat exchangers, the
heart of the WeatherMaker Infinity.
The rest of the unit is backed by a
limited 5-year warranty.
The model 58MVP is available in 6
heat/airflow combinations. The unit
has a 4-way multipoise design and can
Form 58MVP-9PD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 58MVP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Carrier 58MVP

Summary of Contents for Carrier 58MVP

  • Page 1 1 degree of the thermostat setpoint. Because it op- erates in low speed most of the time, the model 58MVP uses up to 80% less power than single-capacity furnaces. In addition to providing ultimate comfort, the model 58MVP has a sealed combustion system.

  • Page 2: Heat Exchangers

    58MVP ideal for use with wall or through the roof when used split-system cooling, including The first cycle after power reset with a factory-authorized vent 2-speed units.
  • Page 3 A96275 NOTES: 1. The 58MVP Furnace is built for use with natural gas. The furnace can be converted for propane gas with a factory-authorized and listed accessory conversion kit. 2. Control location and actual controls may be different than shown above.

  • Page 4: Model Number Nomenclature

    * Factory-authorized and field-installed. Gas conversion kits are A.G.A. recognized. † Required for installation on combustible floors when no coil box is used, or when any coil box other than a Carrier CD5, CK5, or KCAKC cased coil is used.
  • Page 5 One pipe runs inside the other a Carrier cased coil is used. It allowing venting through the is A.G.A. design certified for inner pipe and combustion air...

  • Page 6: Physical Data

    Before purchasing this appliance, read important energy cost and efficiency information available from your retailer. As an ENERGY STAR ® Partner, Carrier Corporation REGISTERED QUALITY SYSTEM has determined that this product meets the These products are engineered and manu- ENERGY STAR ®...

  • Page 7: Performance Data

    Performance data UNIT SIZE 040-14 060-14 080-14 080-20 100-20 120-20 DIRECT-DRIVE MOTOR Hp (ICM) MOTOR FULL LOAD AMPS 12.4 12.4 RPM (Nominal) — SPEEDS Variable 250 — 1300 BLOWER WHEEL DIAMETER x WIDTH (In.) 11 x 10 10 x 7 11 x 10 11 x 10 11 x 10...
  • Page 8 AIR DELIVERY — CFM (With Filter)* AND POWER DRAW (WATTS)** External Static Pressure (ESP) UNIT OPERATING AIRFLOW External Static SIZE MODE Pressure Range* 040-14 Power Draw (WATTS)** Low Heat 565 (650†) 0–0.26 — — — — — High Heat 0–0.49 —...
  • Page 9 AIR DELIVERY CURVE — 040-14 AIR DELIVERY CURVE — 060-14 HIGH HEAT Constant System Constant System Curves Curves HIGH HEAT HEAT HEAT ⁄ ⁄ ⁄ 2 Ton ⁄ 3 Ton ⁄ 2 Ton ⁄ 3 Ton 1000 1100 1200 1300 1400 1500 1000...

  • Page 10: Concentric Vent

    Dimensions CONCENTRIC VENT B IN. DIA PVC VENT/EXHAUST C IN. DIA 1 /2 B IN. DIA PVC INTAKE/COMBUSTION AIR A97110 DIMENSIONS (in.) KIT PART NO. D† KGAVT0501CVT 33-3/8 3-1/2 16-5/8 6-1/4 5-3/4 KGAVT0601CVT 38-7/8 4-1/2 21-1/8 7-3/8 6-1/2 * Dimension A will change accordingly as dimension D is lengthened or shortened. †...
  • Page 12 DOWNFLOW SUBBASE — DIMENSIONS (In.) FURNACE PLENUM OPENING* FLOOR OPENING HOLE NO. CASING FURNACE IN DOWNFLOW APPLICATION FOR WIDTH WIDTH ADJUSTMENT Furnace with or without CD5 or CK5 Coil 17-1/2 15-1/8 16-3/4 20-3/8 Assembly or KCAKC Coil Box Furnace with or without CD5 or CK5 Coil 18-5/8 20-1/4 20-3/8...

  • Page 13: Electrical Data

    Electrical data UNIT SIZE 040-14 060-14 080-14 080-20 100-20 120-20 UNIT VOLTS — HERTZ — PHASE 115 — 60 — 1 OPERATING VOLTAGE RANGE (Min — Max) 104 — 127 MAXIMUM UNIT AMPS 13.8 13.8 11.6 UNIT AMPACITY† 12.0 12.0 12.0 17.9 18.1...

  • Page 14: Combustion-Air And Vent Piping

    Combustion-air and vent piping MAXIMUM ALLOWABLE PIPE LENGTH (FT) ALTITUDE PIPE DIA NUMBER OF 90° ELBOWS ABOVE SEA UNIT SIZE TERMINATION TYPE (IN.)* LEVEL (FT) 1-1/2 040-14 2 Pipe or 2-In. Concentric 1-1/2 060-14 2 Pipe or 2-In. Concentric 1-1/2 080-14 2 Pipe or 2-In.
  • Page 15 MAXIMUM ALLOWABLE PIPE LENGTH (FT) Continued ALTITUDE NUMBER OF 90° ELBOWS ABOVE SEA PIPE DIA LEVEL (FT) UNIT SIZE TERMINATION TYPE (IN.)* 1-1/2 040-14 2 Pipe or 2-In. Concentric 1-1/2 060-14 2 Pipe or 2-In. Concentric 6001 to 7000‡ 1-1/2 080-14 2 Pipe or 2-In.
  • Page 16 MAXIMUM ALLOWABLE EXPOSED VENT PIPE LENGTH (FT) WITH INSULATION IN WINTER DESIGN TEMPERATURE AMBIENT* INSULATION THICKNESS (IN.)† WINTER DESIGN MAX PIPE DIA UNIT SIZE TEMP °F (IN.) 040-14 - 20 060-14 - 20 080-14 080-20 - 20 2-1/2 100-20 2-1/2 - 20 2-1/2 120-20...

  • Page 17: Clearance To Combustibles

    Clearance to combustibles INSTALLATION This forced air furnace is equipped for use with natural gas at altitudes 0 - 10,000 ft (0 - 3,050m). An accessory kit, supplied by the manufacturer, shall be used to convert to propane gas use or may be required for some natural gas applications.

  • Page 18: Typical Installations

    Typical installations COMBUSTION AIR PIPE OUTDOOR UNIT VENT PIPE A/C COIL HUMIDIFIER GAS-FIRED WATER HEATER ELECTRONIC AIR CLEANER AIRFLOW Basement — Upflow Application A93063 ELECTRONIC AIR CLEANER VENT COMBUSTION HUMIDIFIER OUTDOOR UNIT A/C COIL AIRFLOW Closet — Downflow Application A93064...
  • Page 19 COMBUSTION–AIR PIPE VENT PIPE ELECTRONIC AIR CLEANER FURNACE CONDENSATE DRAIN AIR CONDITIONING COIL REFRIGERATION PIPING AIRFLOW Attic — Horizontal Application A93065 COMBUSTION– AIR PIPE VENT PIPE REFRIGERATION PIPING AIR CONDITIONING COIL ELECTRONIC AIR CLEANER AIRFLOW FURNACE CONDENSATE DRAIN Crawlspace — Horizontal Application A93066...
  • Page 20 • Copyright 2000 Carrier Corporation Indianapolis, IN 46231 10-00 Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations. Book Page 20 Catalog No. 525-80002 Printed in U.S.A. PC 101...
