TWO VOLTAGE SELECTOR SWITCHES Only multi-voltage model is provided with these switches. Mains voltages in Saudi Arabia are 127 V and 220 V only. Never use this model with the 110 V setting in Saudi Arabia. The line voltage selector switches are on the rear panel.
01 Before you start Operating other Pioneer components ..27 Checking what’s in the box ... . 5 Installing the receiver ....5 05 Controls and displays Making cable connections .
Page 4
Surround left speaker distance Programming signals from other remote setting ......47 controls (VSX-D812/D912 only) ..59 Subwoofer distance setting .
Before you start Chapter 1: Before you start Checking what’s in the box Making cable connections Please check that you've received the Make sure not to bend the cables over the top following supplied accessories: of this unit (as shown in the illustration). If this happens, the magnetic field produced by the •...
Before you start Incorrect use of batteries may result in such hazards as leakage and bursting. Observe the following precautions: • Never use new and old batteries together. • Insert the plus and minus sides of the batteries properly according to the marks in the battery case.
5 minute guide Chapter 2: 5 minute guide Introduction to home theater You are probably used to using stereo equipment to listen to music, but may not be used to home theater systems that give you many more options (such as surround sound) when listening to soundtracks.
5 minute guide Listening to Surround Sound This receiver was designed with the easiest possible setup in mind, so with the following quick setup guide, you should have your system hooked up for surround sound in no time at all. In most cases, you can simply leave the receiver in the default settings.
5 minute guide Connect your speakers. A complete setup of speakers is shown here (six speakers for the VSX-D712, and eight for the VSX-D812/D912), but everyone’s home setup will vary. Simply connect the speakers you have in the manner shown below. The receiver will work with just two stereo speakers (the front speakers in the diagram) but using at least three speakers is recommended, and a complete setup is best.
Page 10
5 minute guide Front speakers Center speaker Surround speakers Surround back speakers CEN- FM UNBAL SUB W. 7.1CH LOOP Ω INPUT COMPONENT ASSIGNABLE (DVD/LD) IN SURROUND VIDEO DIGITAL BACK SURROUND MONITOR OUT ANTENNA MONITOR OUT VCR / SURROUND BACK CONTROL (CD-R/TAPE/MD) (TV/SAT) IN FRONT...
Page 11
5 minute guide • If you are using only one surround back speaker, connect the positive wire to the right channel (+) terminal, and the negative wire to the left channel (–) terminal (shown below). • If you select subwoofer (SB SW) in the Surround back speaker setting on page 45 you can hook up a subwoofer instead of speakers to the surround back speaker terminals.
5 minute guide Using the Quick Setup Use the MULTI JOG dial to choose your speaker setup. You can use the Quick Setup to get your When a subwoofer was detected in step 2, you system up and running with just a few button can cycle between the following choices: presses.
Page 13
5 minute guide Press ENTER. Use the MULTI JOG dial to choose your room size. Depending on the distance of your speakers from the listening position, choose between small, medium, or large (S, M or L), M being an average-sized room. Press ENTER.
Quick surround sound setup Chapter 3: Quick surround sound setup VSX-D912 only Automatically calibrating Connect the microphone to the SETUP MIC jack on the front panel. your listening area (MCACC) Place the microphone at your normal The Multi-Channel Acoustic Calibration listening position.
Page 15
Quick surround sound setup • ERR Fch – Check the front speaker connections. • ERR Sch – Check the surround or • If the room environment is not optimal for surround back speaker connections. the auto surround setup (too much ambient noise, echo off the walls, obsta- •...
Connecting up Chapter 4: Connecting up Component video cords Use component video cords to get the best possible color reproduction of your video • Before making or changing any source. The color signal of the TV is divided connections, switch off the power and into the luminance (Y) signal and the color disconnect the power cord from the AC (PB and PR) signals and then output.
Connecting up Connecting digital components The easiest way to hook up this receiver for surround sound is to use a digital input. You can do this by either coaxial or optical connections (you do not need to do both). The quality of these two types of connections is the same but since some digital components only have one type of digital terminal, it is a matter of matching like with like (for example, the coaxial output from the component to coaxial input on the receiver).
Connecting up • If you have an LD player, you need to make special connections to ensure you can play 2 RF format LDs on your system. If this is the case, hook up your DVD or LD player directly to an RF demodulator using both the 2 RF output and either a coaxial or optical digital connection.
Connecting up Connecting DVD multi-channel components If you prefer to use a seperate component for decoding DVDs, you can connect a decoder or a DVD player with multi-channel analog outputs to the multi-channel inputs of this receiver. When connecting your equipment, always make sure the power is turned off and the power cord is disconnected from the AC outlet.
Connecting up Connecting video components Connect your video components to the jacks as shown below. With digital video components (like a DVD player), you must use the connections shown on this page for the video signal, but in order to hear a digital source (like a DVD) you should hook up the audio to a digital input (see page 17).
Connecting up Connecting antennas Antenna snap connectors Twist the exposed wire strands together and Connect the AM loop antenna and the FM insert into the hole, then snap the connector wire antenna as shown below. To improve shut. reception and sound quality, connect external antennas (see Using external antennas below).
Connecting up Connecting the speakers (VSX-D712) A complete setup of six speakers (including the subwoofer) is shown below, but everyone’s home setup will vary. Simply connect the speakers you have in the manner shown below. The receiver will work with just two stereo speakers (the front speakers in the diagram) but using at least three speakers is recommended, and a complete setup is best.
Connecting up Connecting the speakers (VSX-D812/D912) A complete setup of eight speakers (including the subwoofer) is shown below, but everyone’s home setup will vary. Simply connect the speakers you have in the manner shown below. The receiver will work with just two stereo speakers (the front speakers in the diagram) but using at least three speakers is recommended, and a complete setup is best for surround sound.
Connecting up • When using the speaker on your TV as the • These speaker terminals are hazardous center speaker (C), connect the CENTER when live. To prevent the risk of electric PREOUT jack on this unit to the audio shock when connecting or disconnecting input jack on your TV.
Page 25
Connecting up Overhead view of speaker setup • When placing speakers near the TV, we recommend using magnetically shielded speakers to prevent possible interference, Front Front such as discoloration of the picture when Center Right Left the TV is switched on. If you do not have magnetically shielded speakers and notice discoloration of the TV picture, Subwoofer...
Connecting up Connecting additional amplifiers This receiver has more than sufficient power for any home use, however it is possible to add additional amplifiers to every channel on the VSX-D812/D912 or the surround back channel of the VSX-D712. Make the connections shown below to add amplifiers to power your speakers. Always make sure that the receiver is switched off and unplugged from the wall outlet before making or changing any connections.
• To hear sound only from the pre-outs, By connecting a control cord (optional), you disconnect any speakers that are can point the remote controls of other Pioneer connected directly to the receiver. components at the receiver’s remote sensor. • If you’re not using a subwoofer, change...
Controls and displays Chapter 5: Controls and displays Front panel MULTI JOG DVD/LD TV/SAT VCR/DVR VIDEO ENTER CD-R/ TAPE/MD TUNER MASTER VOLUME STANDBY DOWN STANDBY / ON PULL OPEN PHONES 12 13 14 15 16 17 ADVANCED STEREO/ SIGNAL MIDNIGHT/ SB CH QUICK TONE...
Page 29
Controls and displays STATION +/– buttons 17 QUICK SETUP Selects station presets when using the tuner See Using the Quick Setup on page 12. (page 54). 18 VIDEO INPUT 10 TUNING +/– buttons See Connecting to the front panel video Selects the frequency when using the tuner terminal on page 20.
Controls and displays Display SIGNAL SELECT indicators 2 DIGITAL When the STANDARD mode of the receiver is Lights to indicate the type of input signal assigned for the current component: on, this lights to indicate decoding of a Dolby Digital signal. AUTO Lights when AUTO signal select is on.
Page 31
Controls and displays 11 Character display 12 Neo:6 When the (STANDARD) NEO:6 mode of the receiver is on, this lights to indicate NEO:6 processing. 13 ADV.SURR. (Advanced Surround) Lights when one of the Advanced Surround modes has been selected. 14 LOUDNESS Lights when LOUDNESS has been selected.
Controls and displays Remote control RECEIVER Switches the remote to control the receiver (used to select the features such as SLEEP, MCACC SETUP, etc). Also use this button to set up surround sound RECEIVER SOURCE INPUT SELECT (page 43, page 50). MULTI CONTROL RECEIVER CONTROL buttons DVD/LD...
Page 33
Controls and displays FL DIMMER SLEEP Dims or brightens the display. Use to put the receiver in sleep mode and select the amount of time before the MASTER VOLUME +/– receiver turns off. Use to set the listening volume. (TUNE +/–, ST +/–) /ENTER Receiver and component control Use the arrow buttons when setting up buttons (Press the corresponding MULTI...
Page 34
Controls and displays CHANNEL +/– Switches between stereo and mono Use to select channels. reception of FM broadcasts. If the signal VOLUME +/– is weak then switching to mono will Use to adjust the volume on your TV. improve the sound quality (page 53). D.ACCESS After pressing, you can access a radio station directly using the number buttons...
Playing sources Chapter 6: Playing sources Introduction to Sound Modes You can identify Dolby Digital software by the 1 or marks. Most Dolby There are three basic sound options: Stereo/ Surround software is marked 3, but Direct (STEREO/DIRECT), Standard (STAN- unmarked software may also incorporate DARD) or Advanced Surround (ADVANCED SURROUND).
Playing sources Neo:6 Music (MUSIC) Sports (SPORTS) This mode gives 6.1 channel surround sound This is designed for sports programs with alot and is suitable for music. The Neo:6 Music of action, adding to the excitement by mode plays the stereo source as is through bringing background action to the forefront.
Playing sources Listening to multi-channel • Press SIGNAL SELECT (front panel) to select the input signal corresponding to playback the source component. Each press cycles through the options as follows: RECEIVER INPUT SELECT AUTO MULTI CONTROL DVD/LD TV / SAT VCR/DVR TV CONT DVD 5.1 ch/...
Playing sources Start playback of the component you • Press ADVANCED SURROUND repeat- selected in step 1. edly to cycle the sound options. Each press changes the display as follows: ADV. ADV. TV SURR. MOVIE MUSIC • You can’t use the STANDARD mode with 6-STEREO SPORTS 96kHz PCM or DTS 96kHz/24-bit stereo...
Playing sources Using the Surround Back • Press SB CH MODE (front panel) repeatedly to cycle the surround back Channel (SB CH) channel options. • Default setting: SB ON (VSX-D812/D912), Each press cycles through the options as SB OFF (VSX-D712) follows: You can have the receiver automatically SB ON...
Playing sources Using the Virtual Surround Each press cycles through the options as follows: Back mode (VSB) Selecting this mode allows you to hear a VSB ON virtual back channel through your surround VSB OFF speakers. For example, you can choose to VSB AUTO listen to sources with no surround back channel information (for example, 5.1...
Playing sources Using Midnight and Loudness Press TONE to select the frequency you want to adjust. listening Each press switches between BASS and The Midnight listening feature allows you to TREBLE. hear effective surround sound of movies at Use the MULTI JOG dial to change the low volume levels.
Playing sources Start playback of the component you selected in step 1. • When playback from the multi-channel Selecting the multi-channel inputs is selected, you can’t use the INPUT ATT, TONE, and MIDNIGHT/ analog inputs LOUDNESS buttons, as well as the STAN- If you have connected a decoder or a DVD DARD, ADVANCED SURROUND, and player with multi-channel analog outputs to...
Setting up Chapter 7: Setting up Choosing your receiver setup Speaker setting (page 44) Specify the number and type of speakers To ensure the best possible surround sound, you have connected. be sure to complete the following set up operations. This is particularly important Surround back speaker setting when using DTS and Dolby surround.
Setting up Surround back speaker distance Repeat steps 3 and 4 to adjust other setting (page 47) setup options. Specifies the distance from your listening When you’re done, press ENTER to position to your surround back speakers. exit. Surround left speaker distance setting (page 47) Specify the distance from your listening position to your surround left speaker.
Setting up One of the following configurations should match your setup: • To select SB L, you must have SL selected FS-CS-SS in the Speaker setting. FS-CS-S FL-C -S Subwoofer setting You can choose whether the subwoofer is FL-C -SS FS-C -SS used or not.
Setting up We recommend setting this to 200Hz if your • to set the attenuation S speakers are smaller bookshelf-type level (0 dB, 10 dB or dB(∞)). speakers. 0 dB 10 dB • to specify the crossover frequency for your small speakers (100 Hz, 150 Hz or 200 Hz).
Setting up Surround back speaker distance • to set the distance of the center speaker from the main listening setting position (within the range of 0.1 m to 9.0 • Default setting: 2 m You should set the distance of the surround back speakers accurately to hear sounds coming from all speakers at the same time.
Setting up • to set the distance of the If Dolby Digital mode is switched on, you will subwoofer from the main listening posi- hear the channel you have selected (either tion (within the range of 0.1 m to 9.0 m). ch1 or ch2) through your center speaker.
Setting up Surround back channel input • to assign the optical digital 1 input (DVD, TV, CD, CDR, VCR or OFF). setting (VSX-D812/D912 only) Optical digital 2 • Default setting: SB 2ch IN (VSX-D812/D912 only) You only have to make this setting if you are •...
Setting up Manually calibrating your Press RECEIVER. listening area (MCACC) Press MCACC SETUP. The MCACC system uses the left front You can use the Multi-Channel Acoustic Cali- speaker as a reference point to calibrate the bration (MCACC) system to fine tune your speaker level and channel delay.
Setting up Setting separate channel The test tone for channel delay is output in the same order as step 5: levels for listening modes • Default setting: 0 dB In addition to the MCACC setup, you can also set relative channel levels from the listening position using the method below.
Page 52
Setting up Press MASTER VOLUME +/– to adjust the volume to an appropriate level. Use LEVEL +/– to adjust the speaker levels in turn. You should hear the test tone at the same volume from each speaker when seated in the main listening position.
Using the tuner Chapter 8: Using the tuner Listening to the radio Automatic tuning To search for stations in the currently The following steps show you how to tune in selected band, press and hold TUNE +/– to FM and AM radio broadcasts using the for about a second.
Using the tuner Tuning directly to a station Sometimes, you'll already know the frequency of the station you want to listen to. In this MULTI JOG ENTER case, you can simply enter the frequency directly using the number buttons on the MASTER VOLUME SIGNAL MIDNIGHT/...
Using the tuner Press T.EDIT (TUNER EDIT). The display shows ST. MEMORY, then a blinking memory class. • To erase a station name, simply repeat steps 1-3 and input four spaces instead of STEREO TUNED a name. SP A 99.50 •...
Using the tuner Listening to station presets Changing the frequency step You will need to have some presets stored to If you find that you can’t tune into stations do this. See Saving station presets on page 54 successfully, the frequency step may not be if you haven’t done this already.
Making recordings Chapter 9: Making recordings Making an audio or a video Select the source you want to record. Use the MULTI CONTROL buttons (or INPUT recording SELECT). You can make an audio or a video recording Select the input signal (if necessary). from the built-in tuner, or from an audio or Press SIGNAL SELECT (front panel) to select video source connected to the receiver (such...
Controlling the rest of your system Chapter 10: Controlling the rest of your system Setting the remote to control Selecting preset codes other components directly There are several ways to set your remote to control the other components in your system. The easiest way to do this is to assign the component’s manufacturer preset code MULTI CONTROL...
Controlling the rest of your system Use the number buttons to enter the nent (for example , or other operation preset code. buttons). This can also be used to program You can find the preset codes on page 64 additional operations (buttons not covered in (VSX-D712) and page 65 (VSX-D812/912).
Controlling the rest of your system Direct function When you’re done, press RECEIVER to store the operation(s). • Default setting: ON You can use the direct function feature to control one component using the remote control while at the same time, using your •...
Controlling the rest of your system Controls for TVs This remote control can control components after entering the proper codes or teaching the receiver the commands (see Setting the remote to control other components on page 58 for more on this). Use the MULTI CONTROL buttons to select the component. Button(s) Function Components...
Controlling the rest of your system Button(s) Function Components & Select or adjust and navigate items on the menu screen. ENTER ENTER brings up the DTV menus. Press to select or adjust and navigate items on the menu Cable TV/Satellite TV/TV/ screen.
Page 63
Controlling the rest of your system Button (s) Function Components Stops playback (on some models, pressing this when the CD/MD/CD-R/VCR/DVD/LD/ disc is already stopped will cause the disc tray to open). DVR player/Cassette deck Number Directly access tracks on a program source. CD/MD/CD-R/VCR/LD buttons player...
Investigate the other components and electrical appliances being used. If the trouble cannot be rectified even after exercising the checks listed below, ask your nearest Pioneer authorized service center or your dealer to carry out repair work. Problem Remedy The power does not turn on.
Page 68
Additional information Problem Remedy Broadcast stations cannot be • Connect an outdoor antenna (refer to page 21). selected automatically. No sound from surround or • Refer to Speaker setting on page 44 to check the speaker settings. center speakers. • Refer to Manually calibrating your listening area (MCACC) on page 50 (with the VSX-D912, you can do this using the Quick surround sound setup on page 14) to check the speaker levels.
Additional information Problem Remedy Can’t operate the remote • Replace the batteries (refer to page 5). control. • Operate within 7 m, 30° of the remote sensor on the front panel (refer to page 6). • Remove the obstacle or operate from another position. •...
Additional information Specifications Signal-to Noise Ratio [EIA, at 1 W (1 kHz)] CD, VCR/DVR, CD-R/TAPE/MD, Amplifier section DVD/LD, TV/SAT..... 79 dB Continuous power output (stereo) Signal-to Noise Ratio Front.
Additional information 50 dB Quieting Sensitivity..Mono: 20.2 dB J shape plug (VSX-D712/D812/D912-K only)... 1 Stereo: 38.6 dBf Microphone (VSX-D912 only)... . 1 Signal-to-Noise Ratio.
Page 72
1. Utilice un destornillador de tamaño ADVERTENCIA: EL APARATO NO ES IMPERMEABLE. NO PONER ALGUNA FUENTE DE medio. AGUA CERCA DEL APARATO, COMO VASO DE FLORES, RECIPIENTES COSMÉTICOS Y 2. Inserte primero el destornillador en la MEDICINALES, ETC. H001A Sp ranura del selector de tensión de la derecha y ajústelo de forma que la punta PRECAUCIÓN:...
Page 73
Cómo cargar las pilas ....5 componentes Pioneer ....26 Campo operativo del mando a distancia .
Page 74
Ajuste del realzador de graves ..44 Cómo seleccionar directamente Ajuste de la frecuencia de corte..44 códigos predefinidos ....57 Ajuste del atenuador LFE .
Antes de empezar Capítulo 1: Antes de empezar Comprobación de los • Si realiza la instalación sobre un bastidor, estante o similar deje más de 20 cm de accesorios suministrados espacio por encima del receptor. Le rogamos que compruebe que ha recibido los siguientes accesorios que suministramos: •...
Antes de empezar Cómo cargar las pilas • Hay obstáculos entre el mando a distancia y el sensor remoto del receptor. • La luz solar directa o luz fluorescente se refleja en el sensor remoto. • El receptor está instalado cerca de un aparato que emite rayos infrarrojos.
Guía en 5 minutos Capítulo 2: Guía en 5 minutos Introducción al home theater Probablemente esté acostumbrado a utilizar un equipo estéreo para escuchar música, pero tal vez no esté acostumbrado a los sistemas home theater que le proporcionan muchas más ventajas (como el sonido surround) cuando se escuchan bandas sonoras.
Guía en 5 minutos Cómo escuchar sonido surround Este receptor se diseñó para una configuración lo más sencilla posible, así que con la siguiente guía de configuración rápida, podrá tener su sistema conectado para un sonido surround rápi- damente. En la mayoría de los casos puede dejar simplemente el receptor con los valores de ajuste por defecto.
Page 79
Guía en 5 minutos Conecte los altavoces. Se muestra una configuración completa de los altavoces (seis altavoces, para el VSX-D712, y ocho, para el VSX-D812/D912) pero la configuración home de cada uno variará. Simplemente conecte los altavoces de los que dispone tal y como se muestra a continuación. El receptor funcionará...
Page 80
Guía en 5 minutos Altavoces frontales Altavoz central Altavoces surround Altavoces posteriores surround CEN- FM UNBAL SUB W. 7.1CH LOOP Ω INPUT COMPONENT ASSIGNABLE (DVD/LD) IN SURROUND VIDEO DIGITAL BACK SURROUND MONITOR OUT ANTENNA MONITOR OUT VCR / SURROUND BACK CONTROL (CD-R/TAPE/MD) (TV/SAT) IN...
Page 81
Guía en 5 minutos • Si selecciona realzador de graves (SB SW) en el Ajuste del altavoz posterior surround en la página 44 puede conectar un realzador de graves en lugar de altavoces a los terminales de los altavoces posteriores surround. Conecte los cables como se muestra en la página ante- rior (tal y como se muestra a continuación), conecte el cable positivo al terminal del canal derecho (+), y el cable negativo al terminal del canal izquierdo (–).
Guía en 5 minutos Cómo utilizar la configuración Utilice el selector MULTI JOG para elegir la configuración de los altavoces. rápida Si se detectó un realzador de graves en el Puede utilizar la configuración rápida para paso 2, puede seleccionar entre las preparar el sistema y hacer que funcione con siguientes opciones: sólo pulsar unos botones.
Page 83
Guía en 5 minutos Pulse ENTER. Utilice el selector MULTI JOG para elegir el tamaño de la sala. Dependiendo de la distancia de los altavoces a la posición de audición, elija entre Pequeño, Medio o Grande (S, M o L), M siendo una sala de tamaño medio.
Configuración rápida del sonido surround Capítulo 3: Configuración rápida del sonido surround Sólo VSX-D912 Calibración automática del Conecte el micrófono a la toma SETUP MIC del panel frontal. área de audición (MCACC) Coloque el micrófono en la posición El sistema de calibración acústica multicanal normal de audición.
Page 85
Configuración rápida del sonido surround Apague el aparato, compruebe el problema El sistema comprobará el tamaño de los alta- indicado por el mensaje ERR (véase más voces, el retardo y nivel de canales. Si ha adelante), e intente llevar a cabo de nuevo la conectado un realzador de graves, compro- configuración surround automática.
Conexiones Capítulo 4: Conexiones Cables de vídeo del Importante componente • Antes de efectuar o modificar las Utilice los cables de vídeo del componente conexiones, apague y desconecte el cable para obtener la mejor reproducción del color de alimentación de la toma de CA. posible de su fuente de vídeo.
Conexiones Conexión de componentes digitales La mejor manera de conectar este receptor para un sonido surround es utilizar una entrada digital. Podrá hacerlo mediante una conexión coaxial u óptica (no es necesario que haga ambas). La calidad de estos dos tipos de conexiones es la misma, pero debido a que algunos componentes digitales sólo disponen de un tipo de terminal digital, es necesario hacerlos corresponder (por ejemplo, la salida coaxial del componente a la entrada coaxial del receptor).
Conexiones Nota • Si dispone de un reproductor de LDs, será necesario que haga conexiones especiales para asegurarse de que puede reproducir LDs con formato 2 RF en su sistema. Si este es el caso, conecte el reproductor de DVDs o LDs directamente a un demodulador RF utilizando la salida 2 RF y una conexión digital coaxial u óptica.
Conexiones Conexión de componentes DVD multicanal En caso de que prefiera utilizar un componente separado para decodificar DVDs, puede conectar un decodificador o un reproductor de DVDs con entradas analógicas multicanal a las entradas multicanal de este receptor. Cuando conecte el equipo, asegúrese siempre de que está apagado y el cable de alimentación desconectado de la toma de CA.
Conexiones Conexión de componentes de vídeo Conecte los componentes de vídeo a las tomas tal y como se muestra a continuación. Con componentes de vídeo digital (como un reproductor de DVDs), será necesario que utilice las conexiones que se muestran en esta página para una señal de vídeo, pero para que se pueda escuchar una fuente digital (como un DVD) será...
Conexiones Conexión de antenas Conectores instantáneos de antena Trence los filos expuestos del cable e insér- Conecte la antena de cuadro AM y la antena telos por el orificio, a continuación, encaje a de cable FM tal y como se muestra en la presión el conector para cerrarlo.
Conexiones Conexión de los altavoces (VSX-D712) A continuación se muestra una configuración completa de seis altavoces (incluido el realzador de graves), pero la configuración en casa de cada uno variará. Simplemente conecte los alta- voces de los que dispone tal y como se muestra a continuación. El receptor funcionará con sólo dos altavoces estéreo (los altavoces frontales en el diagrama), pero se recomienda que se utilicen al menos tres altavoces, y una configuración completa para conseguir el mejor.
Conexiones Conexión de los altavoces (VSX-D812/D912) A continuación se muestra una configuración completa de ocho altavoces (incluido el realzador de graves), pero la configuración en casa de cada uno variará. Simplemente conecte los alta- voces de los que dispone tal y como se muestra a continuación. El receptor funcionará con sólo dos altavoces estéreo (los altavoces frontales en el diagrama), pero se recomienda que se utilicen al menos tres altavoces, y una configuración completa para conseguir el mejor sonid surround.
Conexiones Nota Precaución • Cuando utilice el altavoz del televisor • Estos terminales de altavoz son peli- como el altavoz central (C), conecte la grosos cuando están conectados a la red. toma CENTER PREOUT de este aparato a Para evitar el peligro de descarga eléc- la toma de entrada de audio del televisor.
Page 95
Conexiones Plano superior de la instalación de los • Sitúe los altavoces frontales derecho e iz- quierdo a distancias equitativas con res- altavoces pecto al televisor. • Cuando coloque los altavoces cerca del te- Izquierdo frontal Central Derecho frontal levisor, recomendamos utilizar altavoces con protección magnética para evitar posi- bles interferencias, como la pérdida de co- Realzador...
Conexiones Conexión de amplificadores adicionales Este receptor tiene potencia más que suficiente para un uso en casa, sin embargo, sin embargo, es posible añadir amplificadores adicionales a todos los canales en el VSX-D812/ D912 o al canal surround posterior del VSX-D712. Efectúe las conexiones que se muestran a continuación para añadir amplificadores y así...
Pioneer más próximo. Funcionamiento de otros componentes Pioneer Al conectar un cable de control (opcional) puede apuntar con los controles remotos de otros componentes Pioneer el sensor remoto del receptor. Las señales del mando a...
Controles y pantallas Capítulo 5: Controles y pantallas Panel frontal MULTI JOG DVD/LD TV/SAT VCR/DVR VIDEO ENTER CD-R/ TAPE/MD TUNER MASTER VOLUME STANDBY DOWN STANDBY / ON PULL OPEN PHONES 12 13 14 15 16 17 ADVANCED STEREO/ SIGNAL MIDNIGHT/ SB CH QUICK TONE...
Page 99
Controles y pantallas Botones STATION +/– 17 QUICK SETUP Selecciona presintonías al utilizar el sintoni- Véase Cómo utilizar la configuración rápida en zador (página 53). la página 11. 10 Botones TUNING +/– 18 VIDEO INPUT Selecciona la frecuencia al utilizar el sintoni- Véase Conexión al terminal de vídeo del panel zador (página 52).
Controles y pantallas Pantalla Indicadores SIGNAL SELECT 2 DIGITAL Se ilumina para indicar el tipo de señal de Cuando el modo STANDARD del receptor entrada asignada al componente actual: está activado, se ilumina para indicar decodi- ficación de una señal Dolby Digital. AUTO Se ilumina cuando la señal de AUTO está...
Page 101
Controles y pantallas 10 Indicador de los altavoces Muestra el sistema de altavoces utilizado en esos momento. 11 Pantalla de caracteres 12 Neo:6 Cuando el modo NEO:6 (STANDARD) del receptor está activado, se ilumina para indicar el procesado de NEO:6. 13 ADV.SURR.
Controles y pantallas Mando a distancia RECEIVER Activa el mando a distancia para controlar el receptor (se emplea para seleccionar características tales como SLEEP, MCACC SETUP, etc). También RECEIVER SOURCE INPUT SELECT utilice este botón para configurar el sonido surround (página 42, página 49). MULTI CONTROL DVD/LD TV / SAT...
Page 103
Controles y pantallas FL DIMMER SLEEP Hace que la pantalla se haga más tenue Utilícelo para poner el receptor en modo o más brillante. latente y seleccionar el tiempo que ha de transcurrir antes de que el receptor se MASTER VOLUME +/– apague.
Page 104
Controles y pantallas 14 Botones TV CONTROL Cambia entre recepción monoaural y Estos botones están indicados para controlar estéreo de emisiones en FM. En caso de el televisor asignado al botón TV CONT Por que la señal sea débil, al cambiar a tanto, si sólo dispone de un televisor al que monoaural la calidad del sonido mejorará...
Reproducción de fuentes Capítulo 6: Reproducción de fuentes Introducción a los modos de . La mayoría del software Dolby sonido Surround lleva la marca 3, pero un software sin marcas puede también incor- Hay tres opciones de sonido básicas: Estéreo/ porar Dolby Surround.
Reproducción de fuentes Neo:6 Cinema (CINEMA) TV Surround (TV. SURR.) Este modo proporciona un sonido surround Este modo produce sonido surround tanto de 6.1 canales y es apropiado para películas. para fuentes de TV monoaurales como El modo Neo:6 Cinema proporciona una sepa- estéreo.
Reproducción de fuentes Elección de la señal de entrada • Puede que se produzca un sonido digital cuando un reproductor de CDs o LDs • Valor de ajuste por defecto: AUTO compatible con DTS reproduzca una Tendrá que conectar un componente a señal analógica.
Reproducción de fuentes Utilización de los modos Si está escuchando una fuente de dos canales, cada vez que pulse la pantalla Surround avanzados cambiará de la siguiente manera: Cuando selecciona una de las opciones de Surround avanzado, la decodificación de MOVIE (2 Pro Logic II) Dolby Pro Logic, Dolby Digital y DTS se...
Reproducción de fuentes Cómo utilizar el canal • Pulse SB CH MODE (panel frontal) repetidamente para recorrer las opciones surround posterior (SB CH) del canal surround posterior. • Valor de ajuste por defecto: SB ON (VSX- Cada pulsación selecciona las opciones del D812/D912), SB OFF (VSX-D712) modo siguiente: Puede hacer que el receptor cambie automá-...
Reproducción de fuentes Cómo utilizar el modo surround Cada pulsación selecciona las opciones del modo siguiente: virtual posterior (VSB) Seleccionando este modo podrá escuchar un VSB ON canal surround virtual posterior a través de VSB OFF sus altavoces surround. Por ejemplo, puede VSB AUTO decidir escuchar fuentes sin información de canal surround posterior (por ejemplo, mate-...
Reproducción de fuentes Utilización del modo de audi- Pulse TONE para seleccionar la frecuen-cia que desea ajustar. ción Midnight y Loudness Cada vez que pulsa, se cambia entre BASS y La función de audición Midnight le permite TREBLE. escuchar un sonido surround adecuado en Utilice el selector MULTI JOG para las películas a un nivel de volumen bajo.
Reproducción de fuentes Comienza la reproducción del compo- Nota nente que ha seleccionado en el paso 1. • Cuando está seleccionada la reproduc- Selección de entradas ción desde entradas multicanal, no se pueden utilizar los botones INPUT ATT, analógicas multicanal TONE, y MIDNIGHT/LOUDNESS así...
Configuración Capítulo 7: Configuración Elección de la configuración Ajuste de los altavoces (página 43) Especifique el número y el tipo de alta- de su receptor voces que ha conectado. Para garantizar el mejor sonido surround Ajuste del altavoz posterior surround asegúrese de completar las siguientes opera- (página 44) ciones de configuración.
Configuración Ajuste de la distancia del altavoz • Ajuste de la entrada 2 digital coaxial posterior surround (página 46) • Ajuste de la entrada 1 digital óptica Especifique la distancia desde la posición • Ajuste de la entrada 2 digital óptica de audición de los altavoces posteriores (sólo VSX-D812/D912) surround.
Configuración • En caso de que no utilice un realzador de • Utilice para seleccionar SB S, graves, recomendamos ajustar los alta- SB , SB SW o SB L. voces frontales a L. SB S • Avance por las opciones disponibles utilizando y elija una configuración que corresponda con la configuración del...
Configuración La frecuencia de corte es el punto en el que el Nota receptor divide los sonidos (las frecuencias) altas y bajas entre los altavoces. Debido a que • En caso de que todos los altavoces la mayoría de los altavoces pequeños no pue- (frontal, central y surround) estén ajus- den manejar tonos graves profundos, puede tados como L, la frecuencia de corte no...
Configuración • Utilice para ajustar la distancia Deberá ajustar de manera precisa la del altavoz frontal izquierdo desde la distancia de los altavoces surround para posición de audición principal (dentro de poder escuchar el sonido procedente de un margen de 0,1 a 9,0 m). todos los altavoces al mismo tiempo.
Configuración • Utilice para ajustar la distancia • Utilice para ajustar el control de del altavoz surround izquierdo desde la la gama dinámica (OFF, MAX, o MID). posición de audición principal (dentro de un margen de 0,1 a 9,0 m). Nota •...
Configuración Ajustes de la entrada de vídeo del Una vez haya asignado un componente a una toma digital, siempre que seleccione ese componente componente, (por ejemplo, un reproductor de Aquí es donde le indica al receptor qué DVDs), el receptor cambia automáticamente componentes ha conectado a las tomas de a ajuste de entrada digital y DIGITAL aparece vídeo del componente en la parte posterior...
Configuración Calibración manual del área Pulse RECEIVER. de audición (MCACC) Pulse MCACC SETUP. El sistema MCACC utiliza el altavoz frontal iz- Puede utilizar el sistema de calibración acús- quierdo como punto de referencia para calibrar tica multicanal (MCACC) para afinar los el nivel de altavoces y el retardo de canales.
Configuración Ajuste de niveles de canal altavoz. Intente lograr que el sonido de los dos tonos llegue simultáneamente a una posición distintos para modos de ligeramente por delante de usted y entre el audición espacio abarcado con los brazos. • Valor de ajuste por defecto: 0 dB Además de la configuración MCACC también puede ajustar los niveles de canal relativos desde la posición de audición con el método...
Page 122
Configuración página 44 para asegurarse que ha especi- ficado correctamente la configuración de los altavoces. Pulse MASTER VOLUME +/– para ajustar el volumen a un nivel adecuado. Utilice LEVEL +/– para ajustar los niveles de los altavoces por turno. Deberá escuchar el tono de prueba al mismo volumen de cada altavoz sentado en la posi- ción de audición principal.
Utilización del sintonizador Capítulo 8: Utilización del sintonizador Cómo escuchar la radio Sintonización automática Para buscar emisoras en la banda selec- Los pasos siguientes le muestran cómo sinto- cionada actualmente, pulse y mantenga nizar transmisiones radiofónicas de FM y AM pulsado TUNE +/–...
Utilización del sintonizador Pulse el botón TUNER para seleccionar el sintonizador. Utilice el botón BAND para cambiar la MULTI JOG ENTER banda (FM o AM), si es necesario. Cada vez que pulsa, se cambia la banda entre MASTER VOLUME SIGNAL MIDNIGHT/ SB CH QUICK...
Utilización del sintonizador Pulse T.EDIT (TUNER EDIT). • Pulse ENTER para confirmar un carácter. La pantalla mostrará ST. MEMORY, y a conti- En caso de que no se introduzca ningún nuación, una clase de memoria parpa- carácter, se incluirá un espacio. deando.
Utilización del sintonizador Cómo escuchar presintonías Necesitará tener algunas presintonías guarda- das para hacerlo. Si no lo ha hecho ya, consul- te Cómo guardar presintonías en la página 53. Pulse TUNER para seleccionar el sinto- nizador. Pulse CLASS para seleccionar la clase en la que está...
Cómo realizar grabaciones Capítulo 9: Cómo realizar grabaciones Cómo realizar una grabación Seleccione la fuente que desea grabar. Utilice los botones MULTI CONTROL (o de audio o de vídeo INPUT SELECT). Puede realizar una grabación de audio o de Seleccione la señal de entrada (en caso vídeo desde el sintonizador incorporado o necesario).
Cómo controlar el resto del sistema Capítulo 10: Cómo controlar el resto del sistema Cómo ajustar el mando a Cómo seleccionar distancia para controlar otros directamente códigos componentes predefinidos Hay varias maneras de ajustar el mando a distancia para controlar los otros compo- nentes del sistema.
Cómo controlar el resto del sistema Utilice los botones numerados para asignar un código predefinido para progra- introducir el código preestablecido. mar operaciones (botones no cubiertos por Puede encontrar los códigos preestablecidos los códigos predefinidos). en la página 64 (VSX-D712) y en la página 65 Mientras pulsa el botón RECEIVER, (VSX-D812/D912).
Cómo controlar el resto del sistema Función directa Cuando haya terminado, pulse RECEI- VER para guardar la(s) operación(es). • Valor de ajuste por defecto: ON Puede utilizar la función directa para controlar un componente utilizando el mando a distan- Nota cia, y al mismo tiempo utilizar el receptor para •...
Cómo controlar el resto del sistema Controles del televisor Este mando a distancia puede controlar componentes una vez introducidos los códigos adecuados o una vez se ha enseñado al receptor los comandos (véase Cómo ajustar el mando a distancia para controlar otros componentes en la página 57 para más información). Utilice los botones MULTI CONTROL para seleccionar el componente.
Cómo controlar el resto del sistema Botón (es) Función Componentes Botones Utilícelos para seleccionar un canal de TV específico. TV por cable/TV vía satélite/ numerados TV/DTV Botón +10 Utilícelo para añadir un punto decimal cuando se selecciona un canal de TV específico. ENTER/ Utilícelo para introducir un canal.
Page 133
Cómo controlar el resto del sistema Botón (es) Función Componentes Púlselo para avanzar hasta el comienzo de la próxima Reproductor de CDs/MDs/ pista. CD-R/DVDs/LDs Pulsando repetidamente se salta al comienzo de las pistas siguientes. Reproduce la cara delantera de la cinta en un platina Platina de casetes reversible.
Page 134
Cómo controlar el resto del sistema Botón (es) Función Componentes Hace una pausa en la cinta. Platina de Cassette Detiene la cinta. Platina de Cassette ENTER Comienza la reproducción. Platina de Cassette Retroceso rápido/Avance rápido de la cinta. Platina de Cassette Navega por las opciones/menús del DVD.
Page 135
FUNAI 640 GOLDSTAR 411 SONY 016 (consola de KENWOOD 310, 311 GRANDIENTE 657 GRADIENTE 441 videojuegos) ONKYO 342 PIONEER 600, 651, 231 PIONEER 400, 443 PIONEER 000, 008 PHILIPS 322, 336 RCA 319 STB (SATÉLITE/CATV) Grabadora de DVD SONY 316, 329 Fabricante Código...
Si el problema no puede rectificarse incluso después de llevar a cabo las comprobaciones listadas a continuación, diríjase a su centro de servicio o distribuidor autorizado Pioneer más cercano para que lleve a cabo los trabajos de reparación. Problema Solución...
Page 139
Información adicional Problema Solución Ruido considerable en trans- • Sintonice la frecuencia correcta. misiones radiofónicas. • Conecte la antena (véase la página 20). • Encamine los cables digitales alejados de los terminales y cables de la antena. • Extienda totalmente la antena de cable de FM, posiciónela para obtener una recepción óptima y sujétela en la pared.
Información adicional Problema Solución Se emite sonido de otros • Ajuste SIGNAL SELECT a AUTO, DIGITAL o ANALOG de acuerdo componentes pero no del con el tipo de conexión realizada (véase la página 36). reproductor de LDs o DVDs. • Ajuste los valores de entrada digital correctamente (véase la página 48).
Información adicional Especificaciones Relación de señal a ruido [EIA, a 1 W (1 kHz)] CD, VCR/DVR, CD-R/TAPE/MD, Sección del amplificador DVD/LD, TV/SAT ..... .79 dB Potencia de salida continua (estéreo) Relación señal/ruido [DIN (Potencia Frontal.
Page 150
VIDEO IN DIGITAL DIGITAL OUT CEN- FM UNBAL SUB W. 7.1CH LOOP Ω INPUT TWO VOLTAGE SELECTOR COMPONENT 110 V 220 V ASSIGNABLE (DVD/LD) IN SURROUND VIDEO 120 - 127 V 240 V (CD-R/TAPE/MD) DIGITAL BACK SURROUND MONITOR OUT ANTENNA MONITOR OUT (TV / VCR /...
Page 151
• Ω Ω • CEN- SUB WOOFER FM UNBAL LOOP Ω COMPONENT ASSIGNABLE (DVD/LD) IN VIDEO DIGITAL MONITOR OUT ANTENNA MONITOR OUT SURROUND DVD 5.1CH INPUT VCR / CONTROL (TV/SAT) IN VIDEO VCR / FRONT CENTER SURROUND FRONT TV / (TV / SAT) ASSIGNABLE...
Page 152
CEN- FM UNBAL SUB W. Ω 7.1CH LOOP INPUT COMPONENT ASSIGNABLE (DVD/LD) IN SURROUND VIDEO DIGITAL BACK SURROUND MONITOR OUT ANTENNA MONITOR OUT VCR / SURROUND BACK CONTROL (CD-R/TAPE/MD) (TV/SAT) IN FRONT SURROUND CENTER VIDEO VCR / FRONT CENTER SURROUND BACK SURROUND FRONT TV /...
Page 153
• – SB SW • – VSX-D812/D912 SURROUND BACK DVD/LD QUICK SETUP MULTI JOG ENTER • • STANDARD...
Page 154
MULTI JOG 2.1ch 3.1ch 4.1ch 7.1ch* 6.1ch 5.1ch 2.0ch 3.0ch 4.0ch 7.0ch* MULTI JOG ENTER 6.0ch 5.0ch MASTER VOLUME ADVANCED STEREO/ SIGNAL MIDNIGHT/ MONITOR TONE QUICK SETUP SURROUND DIRECT SELECT LOUDNESS SPEAKERS DOWN MULTI JOG ENING MODE VIDEO INPUT L DIMMER •...
Page 155
ENTER MULTI JOG ENTER MULTI JOG BACK BACK ENTER...
Page 156
SETUP MIC MCACC STANDBY/ON STANDBY RECEIVER MCACC SETUP RECEIVER MCACC SETUP NOISY! MCACC SETUP GO NEXT ? ENTER ENTER MCACC SETUP • • ERR MIC •...
Page 157
• ERR Fch • ERR Sch • • ERR SW • 2.0ch 2.1ch* 3.0ch 3.1ch* 7.1ch* 4.0ch • STANDARD ADVANCED 7.0ch 4.1ch* SURROUND 6.1ch* 6.0ch 5.1ch* 5.0ch STANDARD ADVANCED • SURROUND SELECT • ENTER SW.VOL.UP/SW.VOL.DWN MCACC SETUP GO NEXT ? ENTER ENTER COMPLETE...
Page 159
DIGITAL OUT • DIGITAL DIGITAL CEN- FM UNBAL SUB W. 7.1CH LOOP Ω INPUT COMPON VIDEO DIGITAL SURROUND MONITOR ANTENNA MONITOR OUT VCR / DIGITAL SURROUND BACK CONTROL (CD-R/TAPE/MD) VIDEO VCR / FRONT TV / (TV / SAT) ASSIGNABLE COAX MONITOR T V / / LD...
Page 160
• • OUTPUT CEN- FM UNBAL SUB W. LOOP Ω 7.1CH INPUT COMPONENT ASSIGNABLE (DVD/LD) IN VIDEO DIGITAL SURROUND MONITOR OUT ANTENNA MONITOR OUT VCR / SURROUND BACK CONTROL (TV/SAT) IN (CD-R/TAPE/MD) VIDEO VCR / FRONT CENTER SURROUND BACK TV / (TV / SAT) REC PLAY...
Page 161
• CEN- FM UNBAL SUB W. 7.1CH LOOP Ω INPUT PREOUT SURROUND DIGITAL SURROUND BACK ANTENNA MONITOR OUT VCR / SURROUND BACK CONTROL FRONT SURROUND CENTER (CD-R/TAPE/MD) VIDEO FRONT SURROUND VCR / SURROUND FRONT CENTER SURROUND BACK SURROUND FRONT TV / OUTPUT OUTPUT BACK OUTPUT...
Page 162
• INPUT OUTPUT VIDEO VIDEO OUTPUT CEN- FM UNBAL SUB WOOFER VIDEO Ω LOOP PREOUT SURROUND DIGITAL BACK SURROUND ANTENNA MONITOR OUT SURROUND BACK VCR / DVD 7.1CH INPUT CONTROL (CD-R/TAPE/MD) FRONT SURROUND CENTER VIDEO VCR / FRONT CENTER SURROUND BACK SURROUND TV / (TV /...
Page 163
10mm CEN- FM UNBAL SUB WOOFER LOOP Ω DIGITAL SURROUND ANTENNA MONITOR OUT SURROUND BACK VCR / DVD 7.1CH INPUT CONTROL (CD-R/TAPE/MD) VIDEO VCR / FRONT TV / (TV / SAT) ASSIGNABLE FM UNBAL COAX MONITOR T V / / LD Ω...
Page 164
VSX-D712 +/– • Ω Ω CEN- SUB WOOFER FM UNBAL Ω LOOP COMPONENT ASSIGNABLE (DVD/LD) IN VIDEO DIGITAL MONITOR OUT ANTENNA MONITOR OUT SURROUND DVD 5.1CH INPUT VCR / CONTROL (TV/SAT) IN VIDEO VCR / FRONT CENTER SURROUND FRONT TV / (TV / SAT) ASSIGNABLE...
Page 165
VSX-D812/D912 +/– • Ω Ω CEN- FM UNBAL SUB W. LOOP Ω 7.1CH INPUT COMPONENT ASSIGNABLE (DVD/LD) IN SURROUND VIDEO DIGITAL BACK SURROUND MONITOR OUT ANTENNA MONITOR OUT VCR / SURROUND BACK CONTROL (CD-R/TAPE/MD) (TV/SAT) IN FRONT SURROUND CENTER VIDEO VCR / FRONT CENTER...
Page 168
• VSX-D712 CEN- SUB WOOFER FM UNBAL LOOP Ω DIGITAL ANTENNA MONITOR OUT SURROUND INPUT DVD 5.1CH INPUT VCR / CONTROL VIDEO VCR / FRONT CENTER SURROUND FRONT TV / (TV / SAT) ASSIGNABLE COAX T V / MONITOR / LD DIGITAL FRONT (CD)
Page 170
MULTI JOG DVD/LD TV/SAT VCR/DVR VIDEO ENTER CD-R/ TAPE/MD TUNER MASTER VOLUME STANDBY DOWN STANDBY / ON PULL OPEN PHONES 12 13 14 15 16 17 ADVANCED STEREO/ SIGNAL MIDNIGHT/ SB CH QUICK STATION TUNING STANDARD SPEAKERS TONE SURROUND DIRECT SELECT LOUDNESS MODE...
Page 171
STATION +/– 17 QUICK SETUP 10 TUNING +/– 18 VIDEO INPUT 11 LISTENING MODE 19 DIGITAL IN STANDARD 20 SETUP MIC ADVANCED SURROUND SETUP MIC STEREO/DIRECT 21 FL DIMMER 22 INPUT ATT 12 SIGNAL SELECT 23 MPX 13 MIDNIGHT/LOUDNESS 24 BAND 14 SPEAKERS 25 CLASS 15 SB CH MODE...
Page 172
SIGNAL SELECT 2 DIGITAL STANDARD AUTO AUTO 2 PRO LOGIC II STANDARD VIR.SB DIGITAL INPUT ATT 2 DIGITAL ANALOG DIRECT MIDNIGHT STANDARD SLEEP...
Page 174
RECEIVER SLEEP MCACC SETUP RECEIVER SOURCE INPUT SELECT RECEIVER CONTROL MULTI CONTROL DVD/LD TV / SAT VCR/DVR TV CONT STANDARD CD-R/TAPE TUNER RECEIVER ADVANCED STEREO/ MIDNIGHT/ STANDARD SURROUND DIRECT LOUDNESS TEST SELECT LEVEL TONE EFFECT DIMMER ADVANCED SURROUND MUTE RECEIVER CONTROL MASTER VOLUME TOP MENU...
FL DIMMER TUNE +/– , ST +/– ENTER MASTER VOLUME TUNE +/– ST +/ – MULTI CONTROL MULTI CONTROL TOP MENU MULTI CONTROL TUNER TV/SAT DTV MENU RETURN AUDIO MCACC SETUP BAND DTV ON/OFF MENU DTV INFO INPUT ATT DISPLAY T.EDIT CLASS STATION+/–...
Page 176
D.ACCESS CHANNEL +/– 10 INPUT SELECT 11 LED 12 SOURCE 13 DISC ENTER 14 TV CONTROL TV CONT TV CONT MULTI CONTROL TV CONT (TV CONTROL) INPUT SELECT CHANNEL +/– VOLUME +/–...
Page 177
STEREO/DIRECT STANDARD ADVANCED SURROUND STEREO DIRECT Pro Logic II Movie (MOVIE) STEREO DIRECT Pro Logic II Music (MUSIC) • DIRECT Pro Logic (PROLOGIC) STEREO Neo:6 Cinema (CINEMA)
Page 178
Neo:6 Music (MUSIC) SPORTS GAME EXPANDED STANDARD • 6-STEREO PHONES SURROUND ADV. MOVIE ADV. MUSIC AUTO • TV. SURR. ADVANCED STEREO/ SIGNAL MIDNIGHT/ SB CH QUICK TONE SETUP STANDARD SURROUND DIRECT SELECT LOUDNESS SPEAKERS MODE PHONES SURR. MULTI JOG LISTENING MODE VIDEO INPUT INPUT ATT FL DIMMER...
Page 179
• SIGNAL SELECT RECEIVER INPUT SELECT AUTO MULTI CONTROL DVD/LD TV / SAT VCR/DVR TV CONT DVD 5.1 ch/ CD-R/TAPE TUNER DIGITAL DVD 7.1 ch STANDARD ANALOG AUTO DIGITAL ANALOG DVD 5.1ch DVD 7.1ch DVD/LD DIGITAL AUTO 2 DIGITAL MULTI CONTROL INPUT SELECT •...
Page 180
• ADVANCED SURROUND ADV. ADV. TV SURR. • MOVIE MUSIC STANDARD 6-STEREO SPORTS EXPANDED GAME STEREO DIRECT • ADVANCED SURROUND PHONES SURROUND • STEREO DIRECT • DIRECT • EFFECT + – • STEREO STANDARD...
SB CH • SB CH MODE SB ON • SB ON SB AUTO SB OFF SB AUTO SB ON • SB OFF SB SW • PL II MOVIE/ NEO:6 CINEMA/ PL II MUSIC/ NEO:6 MUSIC PRO LOGIC AUTO AUTO AUTO AUTO...
VSB ON VSB OFF VSB AUTO VSB ON • VSB AUTO • SB SW • SB CH MODE • PL II MOVIE/ NEO:6 CINEMA/ PL II MUSIC/ NEO:6 MUSIC PRO LOGIC AUTO AUTO AUTO AUTO...
Page 183
TONE BASS TREBLE MULTI JOG • MIDNIGHT/LOUDNESS • STEREO/DIRECT MIDNIGHT DIRECT STEREO SPEAKER A • LOUDNESS SPEAKER A • DVD 5.1 ch DVD 7.1 ch MIDNIGHT/LOUDNESS RECEIVER INPUT SELECT MULTI CONTROL DVD/LD VCR/DVR TV CONT TV / SAT CD-R/TAPE TUNER MULTI JOG ENTER MASTER VOLUME...
• INPUT ATT TONE MIDNIGHT LOUDNESS STANDARD ADVANCED SURROUND STEREO DIRECT • DVD/LD TV/SAT VCR/DVR VIDEO CD-R/ TAPE/MD TUNER ADVANCED STEREO/ TUNING STATION STANDBY STANDARD SURROUND DIRECT STANDBY / ON PHONES SURR. LISTENING MODE TUNER EDIT CLASS BAND INPUT ATT FL DIMMER MULTI JOG PHONES...
Page 185
RECEIVER RECEIVER ENTER RECEIVER STANDBY RECEIVER...
Page 190
• L ch 1.R ch2 SW NO • • Lch 1.R ch2 • • • • • TV VCR • • • • TV VCR...
Page 191
• SB 2ch IN • • TV CD CDR VCR 1ch IN SB 2ch IN • SB 2ch IN SB 1ch IN • DIGITAL IN DIGITAL • • TV CD CDR VCR • • TV CD CDR VCR • • TV CD CDR VCR...
Page 192
RECEIVER MCACC MCACC SETUP ENTER • ENTER RECEIVER ENTER ENTER MCACC SETUP •...
Page 193
0 dB • CH SELECT COMPLETE RESUME ADVANCED STANDARD SURROUND TEST SELECT LEVEL TONE • STANDARD MASTER VOLUME ADVANCED SURROUND STANDARD ADVANCED SURROUND TEST TONE •...
Page 194
MASTER VOLUME +/– LEVEL +/– TEST TONE CH SELECT LEVEL +/– • STANDARD STEREO DVD 5.1 ch DVD 7.1 ch ADVANCED SURROUND • STANDARD ADVANCED SURROUND • • STANDARD ADVANCED SURROUND...
Page 196
TUNER BAND MULTI JOG ENTER MASTER VOLUME SIGNAL MIDNIGHT/ SB CH QUICK SELECT LOUDNESS SPEAKERS MODE TONE SETUP DOWN MULTI JOG VIDEO INPUT D.ACCESS SETUP DIGITAL IN S-VIDEO VIDEO AUDIO 106.00 6 0 0 ADVANCED STEREO/ SIGNAL MIDNIGH STEREO TUNED STATION TUNING STANDARD...
Page 197
T.EDIT TUNER EDIT ST. MEMORY • STEREO TUNED SP A • 99.50 DISPLAY CLASS ST +/– STATION +/– MULTI JOG ENTER ENTER T.EDIT TUNER EDIT ST.NAME MULTI JOG ST +/ • – • ENTER ENTER •...
Page 198
TUNER BAND CLASS STANDBY/ON FM 100 kHz/AM 10 kHz FM 50 kHz/AM 9 ST +/– STATION +/– •...
Page 199
MULTI CONTROL INPUT SELECT SIGNAL SELECT INPUT SELECT DVD/LD TV/SAT VCR/DVR VIDEO MULTI CONTROL CD-R/ TAPE/MD TUNER DVD/LD TV / SAT VCR/DVR TV CONT STATION STANDBY CD-R/TAPE TUNER STANDBY / ON TUNER EDIT CLASS MULTI JOG PHONES • ADVANCED STEREO/ SIGNAL MIDNIGHT/ SB CH...
Page 200
MULTI CONTROL MULTI CONTROL DVD/LD VCR/DVR TV CONT TV / SAT CD-R/TAPE TUNER RECEIVER DVD/LD: TV/SAT: MASTER VOLUME VCR/DVR: TUNE CD-R/TAPE: ENTER TUNE TV CONT: TUNER: • RECEIVER MULTI CONTROL...
Page 201
RECEIVER MULTI CONTROL RECEIVER • MULTI CONTROL • RECEIVER TUNER 2 – 5 cm • SAT MULTI CONTROL TV CONT TV CONTROL • • RECEIVER...
Page 202
RECEIVER • • • RECEIVER MULTI MULTI CONTROL CONTROL RECEIVER CONTROL MASTER VOLUME RECEIVER MULTI CONTROL • RECEIVER RECEIVER • RECEIVER TUNER •...
Page 203
MULTI CONTROL INPUT SELECT CHANNEL +/– VOLUME +/– TOP MENU MENU AUDIO GUIDE GUIDE ENTER/ DISC...
Page 204
ENTER ENTER TV CONTROL TV CONT • TV CONT MULTI CONTROL TV CONT MULTI CONTROL SOURCE...
Page 205
ENTER/ DISC ENTER MENU ENTER ENTER CHANNEL +/– TOP MENU AUDIO GUIDE...
