Page 1: Table Of Contents
For Your Safety, 4 Installation Instructions,5-8 Burner and Nozzle Specification, 8 Features, 9 Control Panel, 10 Hotplate, 11 Grill, 12 52TGW Oven, 13 HAL 51 Oven Cooking Chart, 14 HAG 51 Care and Cleaning, 15 Cooking Results Not Satisfactory?,16 Something Wrong with your cooker?, 17... - Page 2 Correcting Errata Correcting Errata Correcting Errata Operating Instructions: 19508240301; 19506068209; 19507127104; 19506068008; 19508240501 The following information DO NOT apply to the models listed in the instruction booklet: MAIN OVEN: "Each shelf has a safety stop to prevent it from being pulled out too far when attending to food. Shelves are removed from the oven by pulling them out to the stop and then lifting them at the front to withdraw."...
- Page 3 Introduction Your new cooker is guaranteed and will give lasting To the Installer: Before installation, fill in the product details on the service. back cover of this book. The guarantee is only applicable if the cooker has The information can be found on the rating plate. been installed in accordance with the Installation Instructions.
-
Page 4: 52Tgw
Model Gas section Rated power Class kW (1) HAG 51 HAL 51 12,50 (909 g/h - G30) 52TGW II2H3+ (893 g/h - G31) (1) The values in g/h refer to the capacities with liquid gas (Butane, Propane). -
Page 5: For Your Safety
For your Safety NEVER . . . Please read the precautions below before using your cooker. NEVER leave children unsupervised where the ALWAYS . . . cooker is installed as all surfaces will get hot during and after use. ALWAYS make sure you understand the controls NEVER allow anyone to sit or stand on any part of... - Page 6 Installation Installation of the cooker The appliance must only be installed by a competent person. In the UK, CORGI registered For a correct installation of the cooker the following installers undertake to work to safe and satisfactory precautions must be followed: standards.
- Page 7 Installation Moving the Cooker Connecting the gas supply To make the connection, a flexible hose should be used corresponding to the current gas regulations which are: • the hose must never be at any point in its lenght in contact with the “hot” parts of the cooker; •...
- Page 8 Installation • Pry the fixing tab “V” and remove the oven burner c ) c ) c ) c ) Minimum regulation of the hob burners: • Unscrew the oven burner nozzle using the socket • turn the tap to minimum; “Z”...
-
Page 9: Burner And Nozzle Specification
N o t e N o t e N o t e N o t e N o t e 52TGW Should the pressure of the gas used be different (or HAL 51 vary) from the recommended pressure, it is HAG 51... -
Page 10: Features
Features GLASS COVER *52 TGW only HOB VENTILATION SLOTS 1900W 1900W 2600W 1000W CONTROL PANEL GRILL/MEAT PAN WITH REMOVABLE HANDLE AND WIRE FOOD SUPPORT MODEL & SERIAL GRILL/TOP OVEN NUMBER TOP OVEN DOOR DOOR MAIN OVEN W I R E W O R K INNER GLASS SHELF SUPPORTS... - Page 11 Control Panel RIGHT LEFT RIGHT GRILL LEFT MAIN FRONT REAR FRONT REAR OVEN BURNER BURNER BURNER BURNER ELECTRONIC* INIECTION BUTTON Control Knobs for the gas burners • The position of the gas burner controlled by each one of the knobs is shown by a solid ring .
-
Page 12: Hotplate
Hotplate The hotplate lid is fitted with a safety device which SAFETY REQUIREMENTS FOR DEEP FAT FRYING 1. Never fill chip pans more than one third full with oil cuts off the gas supply to the hotplate burners unless the lid is fully open. Do not use the safety or fat. -
Page 13: Grill
Grill GRILLING MUST BE DONE WITH THE GRILL DOOR Relighting‘ the burner OPEN. CONTROL KNOBS MAY BECOME HOT DURING In the event of the burner flames being accidentally GRILLING. extinguished, turn off the burner control and do not CAUTION: ACCESSIBLE PARTS WILL BECOME attempt to re-ignite the burner for at least one HOT WHEN THE GRILL minute. -
Page 14: Oven
Oven ROASTING OF LARGE POULTRY The main oven is fitted with a safety device that will The maximum weight of poultry that can be cut off the gas supply to the burner if the flame has accommodated is 11.5kg (25 lbs) of suitable shape. been extinguished for any reason. -
Page 15: Oven Cooking Chart
Oven Cooking Chart The following times and setting are for guidance only. You may wish to alter the setting to give a result more to your satisfaction. When a different setting to that shown below is given in a recipe, the recipe instructions should be followed. -
Page 16: Care And Cleaning
Care and Cleaning Grill Top Cavity Remove the grill pan and the wire grid food support, Remove the rod shelves and grill pan. Use a fine it is best to wash these items immediately after use steel wool soap pad to remove stubborn stains from to prevent stains from being burnt on when used the rod shelves, grill pan and the floor of the oven. -
Page 17: Cooking Results Not Satisfactory
Cooking Results Not Satisfactory? Problem Check Grilling Uneven cooking front to Ensure that the grill pan is positioned centrally below back the grill element. Fat splattering Ensure that the grill is not set to too high a temperature. Ensure that the oven shelves are level by using a spirit Oven Baking Uneven rising of cake level on the rod shelf and adjusting, using suitable... -
Page 18: Something Wrong With Your Cooker
Something Wrong with your Cooker? Before contacting your Service Centre or Installer, check the problem guide below, there may be nothing wrong with your cooker. Problem Check If all burners fail to ignite: Ignition does not work Check that sparks appear at the burners; A clicking noise should be heard. - Page 19 Disposal of your product To minimise the risk of injury to children please dispose of your product carefully and safely. Remove all doors and lids. Remove the mains cable (where fitted) by cutting off flush with the appliance and always ensure that no plug is left in a condition where it could be connected to the electricity supply.
- Page 20 We have a dedicated team who can provide free advice and assistance with your appliance if you experience any technical difficulties within the first 90 days of ownership. Simply call our Hotpoint Service Hotline on 08448 224 224 (ROI 0818 313 413) for telephone assistance, or, where necessary, to arrange for an engineer to call.
-
Page 21: After Sales Service
XEROX FABRIANO XEROX FABRIANO XEROX FABRIANO After Sales Service No one is better placed to care for your Hotpoint appliance during the course of its working life than us - the manufacturer. Essential Contact Information Hotpoint Service We are the largest service team in the country offering you access to 400 skilled telephone advisors and 1100 fully qualified engineers on call to ensure you receive fast, reliable, local service.
