Abocom HomePlug AV Ethernet Bridge PLE0200 Quick Install

Plug the included Ethernet network cable into
the computer's Ethernet port.
Plug the other end of this cable into the
Ethernet port of the Bridge.
Plug type
Plug the Bridge into an electrical
socket.( Plug type)
Plug the electrical cable into electrical
port.( Inlet type )
Because the Bridge sends data over the powerlines of
your house, plug the Bridge directly into an electrical
socket. It's recommended not to plug the device into a
power strip with surge protection. And do not plug the
device into UPS. The Bridge has its own power filter for
protection against surges.
Inlet type
Plug type
Inlet type
Plug the other end of this cable into an
electrical socket.
The installation of the Bridge is complete.
You can enjoy this HomePlug AV product
by default setting now. If you want to
further configure the Bridge, proceed to
Software Installation.
Note:
If you want to distinguish the 200M's adapter
(AV) from 14 M's adapter, you can go to the Network
Connections of Control Panel. And open the Connection
which one is connecting and also finish the hardware
installation. You can check the connection speed is
100.0 Mbps, but 14M will show 10.0Mbps.
200M type
14M type
