Beko L5A Service Manual page 28

Pin
Pin Name Type
No.
51 GND SY SUPPLYD
Ground, Sync Pad Circuitry
52 V SUPSY SUPPLYD
Supply Voltage, Sync Pad Circuitry
53 INTLC OUT
Interlace Output
54 AVO OUT
Active Video Output
55 FSY/HC OUT
Front Sync/ Horizontal Clamp Pulse
56 MSY/HS IN/OUT
Main Sync/Horizontal Sync Pulse
57 SC1_in_R IN
SCART 1input,right
58 VREFTOP
Reference voltage IF A/D converter
59 NC
Not connected
60 MONO_IN IN
Mono input
61 AVSS
Analog ground
62 AVSS
Analog ground
63 NC
Not connected
64 NC
Not connected
65 AVSUP
Analog power supply 5V
66 AVSUP
Analog power supply 5V
67 ANA_IN+ IN
IF input 1
IF common{can be left vacant,only
68 ANA_IN- IN
if IF input1 is also not in use}
IF input{can be left vacant,only if
69 ANA_IN2+ IN
IF input1 is also not in use}
70 TESTEN IN
Test pin
71 XTAL_IN IN
Crystal oscillator
Short Description
Audio Processing - MSP3440G
Pin
Pin Name Type
No.
Crystal oscillator
72 XTAL_OUT OUT
Test pin
73 TP
Audio clock output(18.432MHz)
74 AUD_CL_OUT O UT
Not connected
75 NC
Not connected
76 NC
D_CTR_I/O_1
77 D_CTR_I/O_1 IN/OUT
D_CTR_I/O_0
78 D_CTR_I/O_0 IN/OUT
I2C Bus address select
79 ADR_SEL IN
Stand-by(low active)
80 STANDBYQ IN
Short Description
