AEI Security & Communications DigiSender X7 DG440 Instruction Manual

Wireless video sender system

Advertisement

Quick Links

SPECIFICATIONS
Transmitter :
Remote Relay Receiver
433.92MHz
Audio/Video Frequency
2.4000GHz ~ 2.4835GHz
Channel Frequency
Channel 1
Channel 2
Channel 3
Channel 4
Modulation
FM
Video Input Level
1V PP/75Ω
Colour Video Input
Phase Alternate Line (PAL)
Audio Input Level
1.0v PP (Mod 1KHz, Dev 15KHz)
Audio Bandwidth
10Hz - 22KHz (-1dB)
Input Connectors
DigiConnector Euro SCART x2, RCA Phono x2
Power Source
DC
Receiver :
Remote Relay Transmitter
433.92MHz
Audio/Video Frequency
2.4000GHz ~ 2.4835GHz
Modulation
FM
Video Output Level
1V PP/75Ω
Sensitivity
-80dBm
Audio Output Level
1.0V PP (Mod 1KHz, Dev 15KHz)
Audio Bandwidth
10Hz - 22KHz (-1dB)
Output Connectors
Euro SCART
Power Source
DC
Approvals
See Decleration of Conformity
Antenna System
Internal Omni-directional dipole (2.4GHz)
Omni-directional dipole (433.92MHz)
System Range
≤ 200metres free air space
≈ 40 metres in-building (through walls)
Remote Relay Protocol Coding
RC5, RC6, Active Digital
IrDA 16 Channel
(c)2007 AEI Security & Communications Ltd. All rights reserved.
Registered in England: 02831823
AEI Security & Communications Ltd
Weslake Industrial Park
Rye Harbour Road, Rye
East Sussex
TN31 7TE
United Kingdom
DigiConnector, IR Systeme Technik and DigiEye are trademarks of AEI Security & Communications Ltd
DigiSender is a registered trademark of AEI Security & Communications Ltd
2.414GHz
2.432GHz
2.450GHz
2.468GHz
MODEL: DG440
DigiSender
Wireless Video Sender System
X7
IMPORTANT: ALWAYS KEEP THIS
INSTRUCTION MANUAL FOR
FUTURE REFERENCE
Functions of this product are covered
by one or more patents.
190308-7

Advertisement

loading
Need help?

Need help?

Do you have a question about the DigiSender X7 DG440 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AEI Security & Communications DigiSender X7 DG440

  • Page 1 190308-7 SPECIFICATIONS MODEL: DG440 Transmitter : Remote Relay Receiver 433.92MHz DigiSender ™ Audio/Video Frequency 2.4000GHz ~ 2.4835GHz Channel Frequency Channel 1 2.414GHz Channel 2 2.432GHz Channel 3 2.450GHz Wireless Video Sender System Channel 4 2.468GHz Modulation Video Input Level 1V PP/75Ω Colour Video Input Phase Alternate Line (PAL) Audio Input Level...
  • Page 2 DG440 DigiSender™ X7 WARNING To prevent damage do Table of Contents not expose this unit to rain or moisture. Page 3 Introduction SECTION 1: Step by Step Installation Guide Page 4,5 Unpacking your DigiSender™ X7 Page 6,7 Install the DigiSender™ X7 Transmitter Unit Page 8 Install the IR Systeme Technik™...
  • Page 3 DG440 DigiSender™ X7 DG440 DigiSender™ X7 INTRODUCTION Upgrades & Accessories DigiSender™X7 - Advanced Wireless Video Sender Congratulations purchasing DigiSender™ X7. This product represents state of the art wireless video and infra red technology at exceptional value for money. This system is fully upgradable. You can add additional receivers, aerial convertors, wireless baby monitor cameras and countless other upgrades.
  • Page 4: Rear Panel Descriptions

    DG440 DigiSender™ X7 DG440 DigiSender™ X7 STEP 1 Rear Panel Descriptions Unpacking your DigiSender™ X7 RECEIVER All packs are computer weigh checked when packed. However, it is a good idea to check all kit contents are present before proceeding with the installation. DigiSender™...
  • Page 5 DigiConnectors 1. Remote Extender Channel 5 & 6. RCA Input 3 & 4 Default: Channel 1 Use these to connect to a RCA phono See Advanced Section for details. device such as a CCTV camera 7. Audio/Video Channel 2. IR Emitter Output Default: Channel 1 Connect the supplied IR Emitter See Advanced Section for details.
  • Page 6 DG440 DigiSender™ X7 DG440 DigiSender™ X7 STEP 2 Audio/Video Channel Install the DigiSender™ X7 Transmitter Unit Remote Relay Channel The transmitter unit is designed to send video and sound from one of up to 4 The DigiSender™ X7 features 4 audio/video channels and 4 primary remote relay connected sources to a receiver somewhere else in your home.
  • Page 7 DG440 DigiSender™ X7 DG440 DigiSender™ X7 Frequently Asked Questions (FAQ) & Technical Support continued... My DigiSender™ remote control has and/or Audio/Video channel. It will not Avoid positioning the transmitter near to 2.4GHz wireless enabled devices stopped working operate any satellite or cable systems. such as modern games consoles, wireless controllers, laptops, DECT phones You need to replace the remote control You need to use your original...
  • Page 8: Troubleshooting

    DG440 DigiSender™ X7 DG440 DigiSender™ X7 STEP 3 TROUBLESHOOTING Install the IR Systeme Technik™ remote extender Remote Control Extender Once set up correctly, the remote Because everyone’s set up is different If you have any difficulty operating your source equipment remote control in extender will enable you to utilise your there are many ways you can install the your second room please follow the advice below below:...
  • Page 9 DG440 DigiSender™ X7 DG440 DigiSender™ X7 OPTIONAL TROUBLESHOOTING Connecting inputs 3 & 4 Sound Problems Please follow the guide below if you experience any trouble with the picture and Inputs 3 & 4 can be used with any PAL These inputs are ideal for: sound.
  • Page 10 DG440 DigiSender™ X7 DG440 DigiSender™ X7 STEP 4 Install the DigiSender™ X7 Receiver Unit cont... The DigiSender™ X7 Receiver will pick up transmitted signals from the transmitter unit and output them to a television. In addition, the receiver detects remote controls being used in the second room and will send those signals to the source I see a snowstorm effect or I see lines over the picture...
  • Page 11 DG440 DigiSender™ X7 DG440 DigiSender™ X7 TROUBLESHOOTING Picture Problems continued... Q: What do you see on your second television? Did you know? The receiver can be connected to a Hi-Fi unit using the Left & Right Audio outputs on the rear of the DigiSender™receiver unit. The picture is present but poor quality Phono cable may be required.
  • Page 12 DG440 DigiSender™ X7 DG440 DigiSender™ X7 STEP 5 continued... Using the DigiSender™ X7 The DigiSender™X7 is designed to be The supplied remote control can be Transmitter Source Select Controls. simple to use once set up. used to switch between sources, such The POWER button toggles the as Satellite/Cable, DVD and VCR.
