TRIO Workspace
®
ZB570 Manual
Models:
• ZB570A
• ZB570V
v.0114
Advertisement
Table of Contents
Related Manuals for zBoost Trio Workspace ZB570
Summary of Contents for zBoost Trio Workspace ZB570
- Page 1 30-day money back guarantee when purchased directly from ® zBoost. If product is purchased from a reseller or third party, the purchaser is subject to the policies of the third party. 1 year manufacturer warranty. Warranty registration at www.zBoost.com...
-
Page 3: Fcc Requirements
TRIO Workspace ZB570 Manual ® FCC Requirements This is a CONSUMER Device. BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your provider’s consent. Most wireless providers consent to the use of signal boosters. AT&T, Sprint, T-Mobile, Verizon and 90 additional carriers have already given consent for all consumers to use this device. -
Page 4: Industry Canada Regulations
® About zBoost ® zBoost, the leader in cell phone signal boosters, manufactures an award-winning line of cell phone signal boosters that enhance the performance of your cell phone, smartphone and wireless data card. Uses patented technologies and protects the carrier networks. -
Page 5: Safety Guidelines
TRIO Workspace ZB570 Manual ® Safety and Product Warranty Information Safety Guidelines In accordance with FCC requirements of human exposure to radiofrequency fields, the radiating element (antenna) shall be positioned such that a minimum separation distance of 8 inches (20cm) is maintained between the radiating element and the user and/or general population. Limited Liability In no event shall zBoost be liable for any direct, indirect, special, punitive, incidental, exemplary or consequential damages, or any damages, whether in an action under contract, negligence, or any other theory, arising out of or in connection with the set up of, use of, inability to use, or performance of the information, services, products, and materials available from this manual. -
Page 6: Package Contents
TRIO Workspace ZB570 Manual ® Package Contents Before you begin, make sure all of the following parts came with your zBoost TRIO Workspace. Literature Contents: ① SETUP OVERVIEW ① Setup overview Product Contents: ② zBoost Base Unit ② ③ Indoor Antenna ④... -
Page 7: Optional Accessories
TRIO Workspace ZB570 Manual ® Optional Accessories The following accessories are authorized for this zBoost product. Please see our website for a complete selection. To order, call 1-800-871-1612, or visit, www.zBoost.com. Broadcast Antennas - Indoor CANT-0039 Indoor Broadcast Antenna, Omni Whip Direct to Booster, Black, Wideband, LTE-... -
Page 8: Table Of Contents
SECOND: Place the zBoost Base Unit where you want to create a Cell Zone™ ......... 5 THIRD: Run the provided coaxial cable between the Base Unit and Signal Antenna ......5 FOURTH: Connect zBoost Base Unit to the provided power supply and plug into a power outlet ..6 Improving Your Coverage Area ......................6 zBoost Base Unit Light Indicators ...................... -
Page 9: Overview
® Overview Thank you for choosing zBoost! You will now be able to use your cell phone INSIDE your home. Gone are the days when you had to go to the window upstairs or walk outside to use your cell phone. Like a skylight that brings sunlight into your home, zBoost TRIO transports and amplifies the... -
Page 10: Preparing To Set Up Your Zboost Product
Signal Antenna can be placed for best performance. If you have reliable, fast data speeds outside your home, then zBoost can bring the signal into your home. If only one signal bar is displayed on your cell phone outside, indoor coverage will be limited to one small room. -
Page 11: Setting Up Your Zboost Signal Booster
TRIO Workspace ZB570 Manual ® Setting Up Your zBoost Signal Booster PATIO MASTER BEDROOM KITCHEN BEDROOM The Metro Workspace boosts signal up to 1,500 square feet, making it perfect for apartments, condos and lofts. No outside antenna placement is required. -
Page 12: Second: Place The Zboost Base Unit Where You Want To Create A Cell Zone
Indoor Antenna should have at least 15 feet Suction Cup of horizontal separation. Increasing separation of Attachments the 2 antennas will optimize zBoost performance. For best results, keep the Base Unit off the floor Signal Antenna and at least 2 feet away from other cords, metal objects or other wireless devices such as wireless routers or wireless access points. -
Page 13: Fourth: Connect Zboost Base Unit To The Provided Power Supply And Plug Into A Power Outlet
Working Properly Improving Your Coverage Area When your zBoost system is in place and fully connected, you should walk throughout the room and see that you are able to reliably place calls. Remember, coverage varies based on outdoor signal level, home construction, and antenna placement. Coverage in adjoining rooms will be reduced due to walls or ceiling/floors. - Page 14 TRIO Workspace ZB570 Manual ® Base Unit Indoor Antenna Signal Antenna Power Supply Coax Cable Note Cell phone signal bars are approximate and vary from phone to phone. The number of bars can fluctuate widely, depending on the location of the phone, the position or angle of the phone, weather, etc. Most cell phone signal meters update every 6 to 10 seconds. An increase of only one bar typically indicates a 4x to 10x signal increase.
-
Page 15: Zboost Base Unit Light Indicators
TRIO Workspace ZB570 Manual ® zBoost Base Unit Light Indicators During Initial Power Up Light Mode Status Solution Cycle RED, System is GREEN, powering up. ORANGE Please allow up to 30 seconds. Flashing BASE UNIT will Unplug the BASE UNIT power supply. -
Page 16: Technical Specifications
TRIO Workspace ZB570 Manual ® Technical Specifications Product Specifications for zBoost TRIO Workspace ZB570V Verizon LTE Uplink: 1850 1910 MHz Uplink: 824 849 MHz — — Uplink: 776—787 MHz Frequency Downlink: 746—757 MHz Downlink: 1930 1990 MHz Downlink: 869 894 MHz —... -
Page 17: Frequently Asked Questions
Does the zBoost work if you have no bars? No, if no signal is present outdoors zBoost products will not work for you. Also, keep in mind if your best signal is 1 bar at the Signal Antenna, your coverage will be limited to a small room. You could... -
Page 18: Warranty Information
The “de-kitting” and sale as a standalone product of any one or more components of such a product kit is in violation of zBoost’ warranty. No “de-kitted” product will be eligible for return for any reason. The sale of separate, not-kitted cable, antennas and other accessories is allowed and fully... - Page 19 If still solid red, call customer support 1-800-871-1612. To get warranty service… Warranty service will be provided by zBoost. If you believe you need service for your unit, contact zBoost at 1-800-871-1612 or support@zBoost.com. A representative will go through a diagnostic checklist with you.
