Summary of Contents for zBoost YX645
-
Page 1: User Guide
30 day money back guarantee when you buy directly from Wi-Ex . If product is purchased ® from a reseller or third party, you must use their return policy. 1 Year Manufacturer Warranty Register your zBoost ® product at www.Wi-Ex.com DMAN-0041 v2.0910... -
Page 2: About Zboost® From Wi-Ex
YX645 USER GUIDE About zBoost® from Wi-Ex® Wi-Ex® is the leader in cell phone signal boosters. zBoost® enhances the performance of your cell phone, PDA and wireless data card. Compatibility – Dual Band zBoosts are compatible with 800MHz and 1900MHz regardless of technology- including CDMA and GSM. -
Page 3: Safety And Product Warranty Information
Ce pouvoir est de la réduction par le biais de la sortie d’alimentation ou la réduction de gain et non par un Before you begin, make sure all of the following parts came with your zBoost® YX645. atténuateur à la sortie du dispositif. -
Page 4: Table Of Contents
Mounting the Base Unit ......................... 8 Installing the Indoor Antenna ........................ 9 Illustration of YX645 setup in home ....................10 Confi rm Th at Th e zBoost® is Working Properly ................... 11 Improving Th e Coverage Area ......................11 zBoost® Base Unit Light Indicators ......................12 YX645 Technical Specifi cations.........................13... -
Page 5: Overview
Cell phone signals can be completely blocked or refl ected by buildings, walls, trees, hills and other terrain features resulting in low signal strength. Before placing a zBoost® in a home, make sure that you can place calls on the outside of the building, in the Energy Efficient Windows attic, at roof level or wherever you plan to place the Signal Antenna. -
Page 6: Determine The Needed Coverage Area
Grounding the Directional Signal Antennas Identify the location in your home/offi ce where you need signal coverage the most. Th e zBoost® YX645 Th e Directional Signal Antenna assembly must be properly grounded when it is installed outdoors. Th is will can cover up to 10,000 square feet (coverage varies based on outdoor signal level, building construction, help protect the customer’s property and the Base Unit against lightning strikes during a lightning storm. -
Page 7: Placement Of The Signal Antenna
YX645 USER GUIDE zBOOST® YX645 USER GUIDE NOTE: Th e zBoost® YX645 requires at least 15 feet of vertical separation between the Base Unit and the Installing Your zBoost® Signal Booster Signal Antennas. Generally, increasing this distance (up to 40 feet) will increase the performance and decreasing the distance will limit zBoost®... -
Page 8: Running The Coaxial Cable To The Base Unit
Running the Coaxial Cable to the Base Unit Coaxial cable is not provided with the YX645. After installing the Signal Antennas and connecting them you will need to run coaxial cable to the location where you plan to install the Base Unit. Th e recommended maximum cable length run for RG-6 is 60’... -
Page 9: Confi Rm Th At Th E Zboost® Is Working Properly
Hold your cell phone about 5 feet from the Base Unit and then turn it on. Wait up to 1 minute for the cell phone to register the signal coming from the Base Unit. If the signal meter shows an improvement, your zBoost unit is working properly. Improving Your Coverage Area With everything connected and the Base Unit plugged in, you should walk throughout the room and see that you are able to reliably place calls. -
Page 10: Zboost® Base Unit Light Indicators
Base Unit Light Indicators Technical Specifi cations At Initial Power Up Only Solid GREEN Normal condition at power YX645 PCS-CEL Technical Specifi cations Slowly Alternating RED and GREEN zBoost® is working, but at reduced performance and coverage due to “non- PCS Frequency CEL Frequency ideal”... -
Page 11: Frequently Asked Questions
Does the zBoost® work if you have no bars? No, if no signal is present outdoors zBoost® producs will not work for you. Also, keep in mind if your best signal is 1 bar at the Signal Antenna, your coverage will be limited to one or two rooms. You could improve... -
Page 12: Warranty Information
YX645 USER GUIDE zBOOST® YX645 USER GUIDE Make sure you keep… Warranty Information Please keep your sales receipt or other document showing proof of purchase. Attach it to this User Guide and keep both nearby. Also, keep the original box and packing material in case you need to return your product.
