EC Declaration of Conformity
PACKAGING DISPOSAL:
• Dispose of the packaging at your local recycling centre.
• Dispose of paper and carton separately from plastic bags at your local recycling
centre.
• Dispose of the item at the end of its lifespan at your local authorised
household waste recycling centre.
STORAGE
• Oil the blade to prevent rust.
• Empty the fuel tank and secure the cap on the fuel tank.
• Remove the spark plug and pour a small amount of oil into the cylinder.
• Rotate the crankshaft several times using the starting rope in order to
distribute the oil, replace the spark plug.
• Store the hedge trimmer in a dry place, preferably not in direct contact with the
floor and away from heat sources.
EC DECLARATION OF CONFORMITY
We The Enterprise Department Ltd t/a Coopers of Stortford of 11 Bridge Street,
Bishop's Stortford, Hertfordshire, UK. CM23 2JU in accordance with the following
Directive(s):
2006/42/EC (Machinery Directive)
2004/108EC (EMC Directive)
ENISO 12100-12003, ENISO 12100-2:2003, ENISO 14121-1:2007, ENISO
13857:2008, EN 953:1997+A1:2009, EN 1037:1995+A1:2008, ENISO
11806:2009.
Hereby declare that:
Brush Cutter & Trimmer
Has been designed to comply with the relevant sections of the above referenced
specifications. The unit complies with all applicable Essential Requirements of the
Directives.
Mr. Stuart Fowler
Imports Director
16
Brush Cutter and Trimmer
Brush Cutter
Please read this instruction manual thoroughly before starting and and ensure you
are familiar with the operation of your new Brush Cutter and Trimmerr.
Instructions
9488
Trimmer
