Page 1: Installation Instructions
Use & Care Installation Instructions Over the Range Microwave Models: PMOR3021S / PMOR3021B / PMOR3021R IMPORTANT INFORMATION Installation Instructions Operation Instructions Cooking Guides Specifications TINSEB402MRR0... -
Page 2: For Customer Assistance
SERVICER ___________________________ TELEPHONE ________________ TO PHONE: 1(800)793-0093 TO WRITE: DACOR INC. 1440 Bridge Gate Drive Diamond Bar, CA 91765 Please provide the following information when you write or call: model number, serial number, date of purchase, your complete mailing address (including zip code), your daytime telephone number (including area code) and description of the problem. -
Page 3: Table Of Contents
C O N T E N T S For Customer Assistance ......Reheat ............22-23 Precautions to Avoid Possible Exposure Cook ............23-24 to Excessive Microwave Energy ....Popcorn ............ Contents ............Sensor Center Recipes ......Product Warranty ........Meal Time ..........Important Safety Instructions .... -
Page 4: Product Warranty
FULL ONE YEAR WARRANTY If your DACOR product fails to function within one year of the original date of purchase, due to a defect in material or workmanship, DACOR will remedy the defect without charge to you or subsequent users. The owner must provide proof of purchase upon request and have the appliance accessible for service. -
Page 5: Important Safety Instructions
20 seconds 9. This appliance should be serviced only by before removing the container. qualified service personnel. Contact nearest Dacor Authorized Servicer for examination, e. Use extreme care when inserting a spoon or repair or adjustment. other utensil into the container. -
Page 6: Unpacking And Installation Instructions
If there is any damage, do not operate the oven and contact your dealer or DACOR AUTHORIZED SERVICER. See Installation Instructions for more details. - Page 7 1. If you have any questions about the grounding or electrical Figure 2 instructions, consult a qualified electrician or serviceperson. 2. Neither Dacor nor the dealer can accept any liability for damage to the oven or personal injury resulting from failure to Ground observe the correct electrical connection procedures.
- Page 8 U N P A C K I N G A N D I N S T A L L A T I O N I N S T R U C T I O N S 5 TOOLS RECOMMENDED FOR INSTALLATION •...
- Page 9 U N P A C K I N G A N D I N S T A L L A T I O N I N S T R U C T I O N S 7 PREPARATION OF THE OVEN 1.
- Page 10 U N P A C K I N G A N D I N S T A L L A T I O N I N S T R U C T I O N S 8 VENTILATION SYSTEM (PREPARING OVEN FOR INSTALLATION) This Microwave Oven/Hood is designed for adaptation to three types of hood ventilation systems.
- Page 11 U N P A C K I N G A N D I N S T A L L A T I O N I N S T R U C T I O N S (C) VERTICAL EXHAUST: OUTSIDE VENTILATION 1.
- Page 12 U N P A C K I N G A N D I N S T A L L A T I O N I N S T R U C T I O N S 9 OVEN INSTALLATION THIS OVEN CANNOT BE PROPERLY INSTALLED WITHOUT REFERRING TO THE MOUNTING INSTRUC- TIONS FOUND ON WALL AND TOP CABINET TEMPLATES.
- Page 13 U N P A C K I N G A N D I N S T A L L A T I O N I N S T R U C T I O N S 10 PREPARATION AND USE OF THE CARTON TO ASSIST IN THE INSTALLATION OF THE MICROWAVE OVEN Utilization of the carton may make installation easier.
-
Page 14: Unpacking And Installation Instructions
U N P A C K I N G A N D I N S T A L L A T I O N I N S T R U C T I O N S MOUNTING OVEN TO THE WALL Two people are recommended to attach the Microwave Oven/Hood to the Mounting Plate. -
Page 15: Information You Need To Know
I N F O R M A T I O N Y O U N E E D T O K N O W ABOUT YOUR OVEN This Operation Manual is valuable: read it carefully the amount of moisture that condenses in the oven. Generally, covered foods will not cause as much and always save it for reference. -
Page 16: About Utensils And Coverings
Should you wish to check if a dish is safe for been cooked to safe temperatures. Dacor is not microwaving, place the empty dish in the oven and responsible for any damage to the oven when acces- microwave on HIGH for 30 seconds. -
Page 17: About Microwave Cooking
I N F O R M A T I O N Y O U N E E D T O K N O W ABOUT MICROWAVE COOKING • Arrange food carefully. Place thickest areas towards • Rearrange foods such as meatballs halfway outside of dish. -
Page 18: Part Names
P A R T N A M E S FRONT VIEW BOTTOM VIEW (Front of Microwave) (Rear of Microwave) 1 Oven door with see-through window 7 Auto-Touch control panel 2 Door hinges 8 Time display: Digital interactive display, 99 minutes, 99 seconds 3 Oven light 9 Ventilation openings It will light when oven is operating or door is open. - Page 19 P A R T N A M E S CONTROL PANEL Words in the lower portion of the display will light to indicate what function is in progress. 22-23 27-28 25-26 28-29 Number next to the control panel illustration indicates pages on which there are feature descriptions and usage information.
-
Page 20: Before Operating
B E F O R E O P E R A T I N G • Before operating your new microwave oven make TIMER sure you read and understand this operation manual 12:30 CLOCK completely. Touch TIMER/CLOCK pad again. • Before the oven can be used, follow these proce- dures: This is a 12 hour clock. -
Page 21: Manual Operation
M A N U A L O P E R A T I O N TIME COOKING USING THE RACK The rack allows several foods to be cooked or reheated Your oven can be programmed for 99 minutes 99 seconds (99.99). Always enter the seconds after the at one time. -
Page 22: Special Features
S P E C I A L F E A T U R E S SENSOR CENTER When the sensor detects the vapor emitted from The sensor is a semi-conductor device that detects the the food, remainder of cooking time will appear. vapor (moisture and humidity) emitted from the food as Door may be opened when remaining cooking it heats. -
Page 23: Cook
S P E C I A L F E A T U R E S REHEAT CHART CONT. F O O D A M O U N T P R O C E D U R E Ideal for reheating stirrable casseroles, such as macaroni and cheese or stew. 2. -
Page 24: Popcorn
S P E C I A L F E A T U R E S COOK CHART CONT. F O O D A M O U N T P R O C E D U R E 4. Frozen Vegetables .25 - 1.25 lb Add no water. -
Page 25: Sensor Center Recipes
S P E C I A L F E A T U R E S MEAL TIME Your oven has 3 convenient pads to assist with meal 1. BREAKFAST MENU preparation. There are some foods under Breakfast BREAKFAST MENU is for preparing popular breakfast Menu and Lunch Menu that use the sensor. -
Page 26: Lunch Menu
S P E C I A L F E A T U R E S BREAKFAST MENU CHART CONT. F O O D P R O C E D U R E A M O U N T 4. Scrambled For each egg, use 1 teaspoon of butter or margarine and 1 tablespoon of milk. -
Page 27: Dinner Menu
S P E C I A L F E A T U R E S 3. DINNER MENU D I S P L A Y P R O C E D U R E DINNER MENU will cook any of the dinners listed in the chart by simply following the directions in the DINNER YELLOW... -
Page 28: Easy Defrost
S P E C I A L F E A T U R E S 5. ORZO VEGETARIAN MEDLEY 3 cups chopped green, red, orange or yellow Place in a 3 quart casserole: 1 cup orzo or other tiny shaped pasta peppers cups vegetable or chicken broth 1 onion, thinly sliced... -
Page 29: Keep Warm
S P E C I A L F E A T U R E S EASY DEFROST CHART CONT. F O O D P R O C E D U R E A M O U N T 4. Boneless .5 - 2.0 lb Use boneless breast of chicken or turkey. -
Page 30: Short Cuts
S P E C I A L F E A T U R E S SHORT CUTS SHORT CUTS automatically compute the correct SELECT heating time and microwave power level for melting, softening and warming foods shown in the chart. Repeat touching same number pad to select •... -
Page 31: Other Convenient Features
O T H E R C O N V E N I E N T F E A T U R E S HELP GUIDE HELP GUIDE provides 4 features that make using 3. Be sure to choose foods that can be left in the oven your oven easy because specific instructions are safely until the Auto Start time. -
Page 32: Demonstration Mode
O T H E R C O N V E N I E N T F E A T U R E S DEMONSTRATION MODE MORE OR LESS TIME ADJUSTMENT To demonstrate, touch TIMER/CLOCK, the number 0 and then touch the START/EASY MINUTE pad and Should you discover that you like any of the Sensor hold for three seconds. -
Page 33: Cleaning And Care
C L E A N I N G A N D C A R E Disconnect the power cord before cleaning or leave the door open to inactivate the oven during cleaning. Exterior Odor Removal The outside surface is precoated steel and plastic. Clean Occasionally, a cooking odor may remain in the oven. -
Page 34: Replacing Parts
3. Replace light bulbs with equivalent watt bulb 2. Remove the three louver mounting screws and available from your Dacor Authorized Servicer or push down carefully on the tab at each end of the parts distributor. Bulbs are also available at most louver to disengage it. -
Page 35: Service Call Check
If “NO” is the answer to any of the above questions, please check electrical outlet, fuse and/or circuit breaker. If they are functioning properly, CONTACT YOUR NEAREST DACOR AUTHORIZED SERVICER. A microwave oven should never be serviced by a “do-it-yourself” repair person. -
Page 36: Auto-Touch Guide
A U T O - T O U C H G U I D E For more complete information and safety precautions, refer to your Operation Manual. SET CLOCK POPCORN 1 Touch POPCORN pad once ENJOY YOUR OVEN PRESS CLEAR AND PRESS POPCORN is in the display, first touch STOP/CLEAR. - Page 37 1. Syrup 2. Dessert Topping 1 - 10 3. Rolls/Muffins .5 - 2.0 lb 4. Boneless Poultry .5 - 3.0 lb 5. Bone-in Poultry DACOR INC. • 1440 Bridge Gate Drive, Diamond Bar, CA 91765 1-800-793-0093 • www.dacor.com PRINTED IN USA...
-
Page 38: Notes
