Kroy K4100 Owner's Manual

Kroy k4100 desktop label printer owner’s manual
Hide thumbs Also See for K4100:
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
Read this manual before using your K4100
Clear
FILE
¡
@
1
Q
A
CAPS
SHIFT
K4100 Desktop Label Printer
Toll Free 800.776.5769
Visit www.kroy.com
Barcode
Auto
Date
Label
FONT
SIZE
STYLE
REP
£
º
¢
#
$
%
2
4
5
3
±
W
E
R
T
Å
S
D
F
G
Œ
Ç
Ç
Æ
Ø
Z
C
V
X
ALT
FEED
Kroy K4100
Setup
PRINT
&
ƒ
¥
(
[
)
*
8
6
7
9
´
`
Y
U
U
I
O
¿
H
K
L
J
~
ß
ß
^
B
N
M
]
0
+
'
"
P
=
:
/
?
;
<
>
,
.
ENTER
Order Number 2562100
Rev C 3/08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the K4100 and is the answer not in the manual?

Questions and answers

Related Manuals for Kroy K4100

Summary of Contents for Kroy K4100

  • Page 1 Owner’s Manual Read this manual before using your K4100 Kroy K4100 Barcode Auto Date Setup Clear Label FILE FONT SIZE STYLE PRINT ¡ £ º ¢ & ƒ ¥ ± ´ " ¿ Å CAPS < > ß ß Œ...

  • Page 2: Fcc Notice

    (6) months from the date of purchase. At no charge to the customer except for inbound freight to Kroy’s service center, Kroy will, at Kroy’s option, repair or replace any product determined to be defective. Kroy will pay return UPS ground charges. A purchase receipt or other evidence of purchase will be required before warranty service is rendered.
  • Page 3 Please contact the distributor from where the product was purchased to check the terms of your purchase contract. Alternatively please contact Kroy Europe Ltd: Tel: +44 (0)118 986 5200 Fax: +44 (0)118 986 5205 Email: info@kroyeurope.com Kroy Europe Ltd WEEE Producer No.: WEE/KA0053TQ...

  • Page 4: Table Of Contents

    Table of Contents Chapter 1: Getting Started Contents of Box....................3 Printer Description.................... 4 Important Safety Precautions................5 Connecting AC Adapter..................6 Installing the Supply Cartridge................7 Chapter 2: Printing Your First Label Printing a Label....................9 Turning Printer On.................... 9 Cursor Movement.....................
  • Page 5 Using Your Printer with Other PC Applications.......... 47-48 Appendices Maintaining Your Printer................. A-1 System Messages..................B-1 Troubleshooting..................... C-1 Updating Printer Firmware..............D-1 D-2 Using Accent Characters................E-1 Using the Character Map ................F-1...

  • Page 6: Chapter 1: Getting Started

    Getting Started...

  • Page 7: Contents Of Box

    ¿ Å CAPS > Ç ß ß < Æ Œ Ç Ø SHIFT FEED ENTER (1) Owner’s Manual and (1) CD-ROM (1) K4100 Desktop Label Printer with KLDS Software and Drivers (1) AC Adapter with Power Cord (1) Serial Cable...
