HAYWARD Hi-Performance SELF-PRIMING PUMPS
INSTALLATION AND OPERATING INSTRUCTIONS
Your Hayward Ultra-Pro LX pump has been quality-built
and engineered to give you many years of efficient,
dependable service. The non-conductive, corrosion-proof
motor housing provides protection from the elements and
insulates the electrical motor parts from outside contact.
The advanced design reduces operation and maintenance
to simple, common-sense procedures.

GENERAL TIPS ON PUMP INSTALLATION

For best pump performance, locate the system below
the pool water line and as close to the pool as possible.
If you own an above ground pool please see Note: NSPI-
4 Article V, for safe and proper installation of the
equipment package. Make sure suction joints are tight.
Suction pipe should be as large or larger than discharge
pipe.
Damp, non-ventilated locations should be avoided.
Motors require free circulation of air to aid in cooling.
Insure that the electrical supply available agrees with the
motor's voltage, phase and cycle, and that wire size is
adequate for the HP/KW rating and distance from the
power source. Motor must always be properly grounded.
If cord connected, use only a properly grounded outlet.
Electrical circuits should be protected by proper size
ground fault circuit interrupter (GFCI). All electrical wiring
should be performed by qualified personnel and must
conform to local codes and regulations.

MAINTENANCE

1. Clean strainer basket regularly. Do not strike basket
to clean. Inspect strainer cover gasket regularly and
replace as necessary.
2. Hayward pumps have self-lubricating motor bearings
and shaft seals. No lubrication is necessary.
3. Keep motor housing clean. Insure air vents are free
from obstructions, debris, etc.
HAYWARD POOL PRODUCTS CANADA, INC.
® Hayward Pool Products Canada, Inc. – Licensee
2880 PLYMOUTH DRIVE, OAKVILLE, ONTARIO L6H 5R4 • (905) 829-2880

STARTING AND PRIMING INSTRUCTIONS

Fill strainer/housing completely with water. Never
operate the pump without water. Water acts as a coolant
and lubricant for the mechanical shaft seal.
Open all suction and discharge lines and valves, as well
as air bleed (if available) on filter. (The air that is to be
displaced from the suction line must have some place to
go).
Turn on power and allow a reasonable time for priming.
Priming time depends on suction lift and length of
suction piping. If pump will not start, or will not prime, see
Trouble Shooting GUIDE on back page.
Note: NSPI-4 Article V, standard for above ground and
on ground pools, advises that components such as the
filtration system, pumps and heater be positioned so as
to prevent their being used as a means of access to the
pool by young children.
4. Occasionally, shaft seals must be replaced, due to
wear or damage. See instructions

STORAGE/WINTERIZING

Pump and motor must be protected from freezing. Shut
off all electric power. Disconnect cord/electrical
connections
and
plumbing
thoroughly and clean out any debris. Store pump and
motor in a dry, well ventilated room.
IS-2290-02-HC
connections.
Drain

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ultra-Pro LX Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Hayward Ultra-Pro LX Series

  • Page 1 IS-2290-02-HC HAYWARD Hi-Performance SELF-PRIMING PUMPS INSTALLATION AND OPERATING INSTRUCTIONS Your Hayward Ultra-Pro LX pump has been quality-built and engineered to give you many years of efficient, dependable service. The non-conductive, corrosion-proof motor housing provides protection from the elements and insulates the electrical motor parts from outside contact.
  • Page 2: Parts List

    PART NUMBER Ref. DESCRIPTION MODEL MODEL Req'd SP2290 (T) SP-2295 (T) (ET) Strainer Cover SP1500D2A SP1500D2A Strainer Cover w/O-ring SP1500P SP1500P Basket SP1500LX SP1500LX Strainer Housing SP1500CP SP1500CP Drain Plug (optional) – SP1700FG SP1700FG Drain Plug w/Gasket SP1700FG SP1700FG O-ring SP1500W SP1500W Bolt, No.10-24 Hex.
  • Page 3 ULTRA-PRO LX PUMP MECHANICAL TIMER MODULE INSTRUCTIONS Your integrated timer module is preprogrammed to operate your filtration system for nine (9) hours – one five hour period and one four hour period during the day. All you have to do is set the correct time (Step 2) and plug in. If you prefer customizing your settings, follow Steps 1-5.
  • Page 4: Trouble Shooting

    SERVICE AND REPAIRS Consult your local authorized Hayward dealer or service center. No pumps or motors may be returned directly to the factory without the express written authorization of Hayward Pool Products Canada, Inc.

This manual is also suitable for:

Ultra-pro lx sp2290Ultra-pro lx sp2290tUltra-pro lx sp-2295Ultra-pro lx sp-2295tUltra-pro lx -2295et
