Page 1: User Manual
User Manual X3 Series (X3, X3 Pro & X3R) X3 Pro... -
Page 2: Table Of Contents
1. X3 & X3-Pro…………………………………………………………………………………………………..3 2. X3R………………………………………………………………………………………………………………..4 Assembly Instructions……………………………………….………………………………………………..…...5 1. X3 & X3-Pro…………………………………………………………………………………………………..5 2. X3R………………………………………………………………………………………………………………..8 Operating Instructions……………………………………………………………………………....10 1. X3, X3 Pro & X3R……………….……………………………….………………………………………… 10 T-Handle Control Functions……..……………………………………………………………10 Additional Functions……………….………………………………………………………………11 Remote Control Instructions (X3R Only)…………………………………………………..13 Maintenance & Additional Instructions…………….…………………………………………………14 1. Battery Charging and Maintenance…………….………………………………………………….14 2. -
Page 3: Packing List
PACKING LIST 1. Standard Parts (X3 & X3 Pro) 1 Caddy Frame 2 Rear Wheels (Left & Right) 1 Battery Pack (Lead Acid or Lithium Battery, Bag, Leads) 1 Charger 1 Tool Kit 1 User Manual, Warranty, Terms & Conditions 2. -
Page 4: Parts Glossary
6. Wheel Hub with Locking Mechanism 7. Rear Wheel Rubber Tread 8. Battery Tray with Plug Receptacle 9. Lower Bag Support and Fender with Support Strap and Tracking Adjustment Mechanism 10. Front Wheel 11. Frame Locking Hinge (2 locks on X3 Pro) 12. 110-240V Charger... -
Page 5: X3R
2. X3R 1. T-Handle with Control Face Faceplate and Manual Speed Control 2. Upper Bag Support 3. Upper Bag Support Bungee Pigtails 4. Battery with Leads and Carrying Case a) (12V 34/35Ah Sealed Lead Acid Deep Cycle) 5. 2 Identical Rear Wheels 6. -
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS 1. X3/X3 Pro 1. Unpack all items carefully and check inventory. 2. Place frame structure (one piece) on soft and clean ground to protect frame from being scratched. Erect frame by unfolding and connecting the main frame tube together at the joint and locking the Y-shape lower support structure to the main frame with the frame lock mechanism. - Page 7 X3 Pro 3. Attach wheels to axles by pushing wheel locking button on the wheel hub and inserting the axle extension into the wheel. Make sure to keep the locking button on wheel hub pushed in during this process, in order to enable the axle extensions to be inserted all the way into the wheel so the axle sprocket locks into the hub.
- Page 8 4. Place battery pack on battery tray and fasten Velcro strap around battery tightly. Insert 3 prong battery plug into caddy outlet so notch aligns properly with plug. It is recommended NOT to fasten the screw on the plug to the outlet, so in case of tip over the cable can unplug from the socket.
-
Page 9: X3R
2. X3R 1. Unpack all items carefully and check parts inventory. 2. Place frame structure (one piece) on soft and clean ground to protect frame from being scratched. Attach wheels to axles by pushing wheel locking button on the wheel hub and inserting the axle extension into the wheel. Make sure to keep the locking button on the wheel hub pushed in during this process, in order to enable the axle extensions to be inserted all the way into the wheel. - Page 10 6. Place the battery pack on the battery tray and fasten the Velcro strap around the battery tightly. Insert the 3-prong battery plug into the caddy outlet so the notch aligns properly. It is recommended NOT to fasten the screw on the plug to the outlet, so in case of tip over the cable can unplug from the socket.
-
Page 11: Operating Instructions
OPERATING INSTRUCTIONS 1. X3, X3 Pro & X3R Handle Controls Display screen Speed Control 1. Timed Distance Advance Function : Press once, display will show A , the caddy will run ca. 10 Yards/Meters and stop Press twice, display will show B , the caddy will run ca. -
Page 12: Additional Functions
4. USB plug (optional) located under handle cover for GPS or cell phone. Additional Functions Tracking Adjustment; tracking behavior of all electric caddies is strongly dependent on equal weight distribution on the caddy and slope/topography of the golf course. Test your caddy’s tracking behavior by operating it on an even surface without the bag. - Page 13 Installation of Seat Attach seat holding bar to caddy frame Attach seat stand to seat bottom using the four small screws. Attention: Attach in such manner that the seat is parallel to the driving direction of the caddy, with the opening facing the outside when you slide it into the holding bar. Slide seat stand into holding bar as shown.
-
Page 14: Remote Control Instructions (X3R Only)
Remote Control Instructions (X3R Only) Functions: A. Brake: The red STOP button in the middle of the directional arrows should be used for stopping the caddy. B. Timer: 10, 20, 30 yards/meters C. Backward Arrow: Pressing the back arrow will set the caddy in backward motion. Increase backward speed by pushing multiple times. -
Page 15: Maintenance & Additional Instructions
Before storing a battery for extended periods of time you must fully charge it. DO NOT store a discharged battery or else it might become unusable. Replacement batteries are available from your authorized dealer or directly from Bat-Caddy. Recommendations Fully charge the battery for ca. -
Page 16: Testing Your Caddy
be below its optimal power. Always keep your battery fully charged before another game Never keep your battery connected to the grid during prolonged power outages. It might be irreversibly damaged. Do not fully discharge the battery by “overplaying” it. It is recommended to recharge the battery after every 18 holes. -
Page 17: Recommendations For Efficient And Safe Operation
in remote operation. An additional safety feature of this caddy is that it will stop moving if it does not receive a signal from the remote control at least every 45 seconds. This way, should you ever be distracted, your caddy does not completely get away. By pressing the lower Timer button on the remote the caddy can be moved forward automatically by 10, 20, or 30 yards. -
Page 18: General Maintenance
4. General Maintenance The steps below will ensure that you get a prolonged and reliable life out of your Bat-Caddy. The Caddy has been designed so that the user can concentrate on playing golf, while the caddy does the work of carrying your bag. In order to keep your Bat-Caddy looking its best, we advise that you wipe any mud or grass from the frame, wheels and chassis after every round with a damp cloth or paper towel. - Page 19 Battery Operation and Care: Follow battery charge and maintenance instructions. The battery comes with leads and a 3-prong connector. Note: Bat-Caddy reserves the right to modify/upgrade any components during a model year, so illustrations on our website, brochures and manuals may slightly vary from the actual product shipped.
-
Page 20: Technical Specifications
TECHNICAL SPECIFICATIONS 1. X3 & X3 Pro Model Name Standard Battery 33Ah SLA Dimensions SLA: 8 x 5 x 6 in (20 x 13 x 15 cm) Weight: 20 Lbs Average charge time: 4-8 hours Lifetime: ca. 150 charges Standard Battery Duration 27-36 holes 35Ah SLA @ $25.00... -
Page 21: X3R
Rear Wheels Airless, rubberized tread Quick-release mechanism Drive Train Rear Wheel Drive Gear ratio (17:1) Handle Height Adjustment Materials Aluminum/SS and ABS Available Colors Iridium Silver, Black, White Complimentary Accessories Scorecard Holder (depending on promotions) Cup Holder Umbrella Holder Carrying Bag Seat Optional Accessories Rain Cover... - Page 22 Timed forward advance function (10,20,30 yards) Cruise Control Power On/Off USB Port (optional) Distance/Range 13 mi(20 km)/27+ holes Climbing Ability 30 degrees Off-Power Free-Wheeling Mode Maximum Load 77 lbs (35 kg) Charger Input: 110-240V AC Output: 12V/3A-4A Trickle Charger Motor Power: 2 x 200 Watt (400 Watt) 12V DC Electric...
-
Page 23: Troubleshooting Guide
Check if wheels are secured to axle by split pin Motor is running but wheels don’t turn Check right and left wheel position on X3/X3 Pro Check right/left wheel clutches Check if wheel is fitted over clutch & latched to axle... -
Page 24: Frequently Asked Questions (Faqs)
FREQUENTLY ASKED QUESTIONS (FAQs) Please check our website at http://batcaddy.com/pages/FAQs.html for FAQs For Technical Support please contact one of our Service Centers. Contact info at http://batcaddy.com/pages/Contact-Us.html Check our website www.batcaddy.com Bat-Caddy is a registered trademark of SpaCom LLC...
