NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Identifier
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
PHC 265
Retain This
Manual for
Reference
08-07-02
OWNER'S
MANUAL
POWERHOUSE BENCH
IMPEX FITNESS PRODUCTS
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: (800) 999-8899 Fax: (626) 961-9966
www.impex-fitness.com
info@impex-fitness.com
PHC -265
Advertisement
Table of Contents
Related Manuals for Impex PHC -265
Summary of Contents for Impex PHC -265
- Page 1 Parts List Warranty Ordering Parts Model PHC 265 Retain This Manual for Reference 08-07-02 OWNER'S MANUAL POWERHOUSE BENCH PHC -265 IMPEX FITNESS PRODUCTS 14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746 Tel: (800) 999-8899 Fax: (626) 961-9966 www.impex-fitness.com info@impex-fitness.com...
-
Page 2: Table Of Contents
WARRANTY...…………. 10 ORDERING PARTS...………… 10 BEFORE YOU BEGIN Thank you for selecting the POWERHOUSE PHC 265 BENCH by IMPEX FITNESS PRODUCTS. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction. -
Page 3: Important Safety Notice
AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT. SAVE THESE INSTRUCTIONS. IMPORTANT SAFETY NOTICE IMPEX INC. -
Page 5: Assembly Instruction
ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Two Adjustable Wrenches. NOTE: It is strongly recommended two or more people assembling this machine to avoid possible injury. STEP 1 (See Diagram 1) A.) Connect the two Rear Upright Beams (#1) by the Cross Brace (#2) in the mid-span. Align the holes then secure each end of Cross Brace with one Bracket (#13), two M10 x 2 3/8”... - Page 6 A.) Attach the rear of the Main Seat Support (#3) to the Cross Brace (#2). Secure it with one Bracket (#13), two M10 x 2 3/8” Hex Bolts (#25), four Aircraft Nuts (#30). B.) Attach the front of the Main Seat Support (#3) to the Front Support (#4). Secure them with two M10 x 1”...
- Page 7 A.) Attach the front holes on the Backrest Supports (#7) to the pivot on the Main Seat Support (#3). Place the other end of the Backrest Supports (#7) on the Backrest Adjustment Bar (#6). Place the Backrest Board (#8) onto the Backrest Supports (#7). Secure it with four M6 x 1 3/8”...
- Page 8 A.) Attach the Leg Developer (#10) to the front of Main Seat Support (#3). Secure it with a Hex Socket Axle (#23) and Hex Socket Screw (#24). Attach one Spring Clip (#14) onto the weight post on the Leg Developer. B.) Insert the two Foam Roll Tubes (#11) halfway through the holes on the Leg Developer.
-
Page 10: Parts List
PARTS LIST KEY NO. DESCRIPTION Rear Upright Beam Cross Brace Main Seat Support Front Support Diagonal Support Backrest Adjustment Bar Backrest Support Backrest Board Seat Pad Leg Developer Foam Roll Tube Foam Roll Bracket Spring Clip 1” Sleeve Left Safety Hook Right Safety Hook Bushing 1 ½”... -
Page 11: Impex Inc
IMPEX Customer Service Department at 1-800-999-8899. All freights on products returned to IMPEX must be prepaid by the customer. This warranty does not extend to any product or damage to a product caused by or attributable to freight damage, abuse, misuse, improper or abnormal usage or repairs not provided by an IMPEX authorized service center or for products used for commercial or rental purposes.
