Impex MARCY MWB 758 Owner's Manual

Impex MARCY MWB 758 Owner's Manual

Impex owner manual weight bench mwb 758
Hide thumbs

Advertisement

Quick Links

NOTE:
Please read all instructions
carefully before using this
product
Safety Notice
Hardware Identifier
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
MWB 758
Retain This
Manual for
Reference
07-12-01
OWNER'S
MANUAL
MARCY WEIGHT BENCH
IMPEX FITNESS PRODUCTS
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: (800) 999-8899 Fax: (626) 961-9966
www.impex-fitness.com
info@impex-fitness.com
MWB 758

Advertisement

loading

Related Manuals for Impex MARCY MWB 758

Summary of Contents for Impex MARCY MWB 758

  • Page 1 Please read all instructions carefully before using this product Safety Notice Hardware Identifier Assembly Instruction Parts List Warranty Ordering Parts Model MWB 758 Retain This Manual for Reference 07-12-01 OWNER'S MANUAL MARCY WEIGHT BENCH MWB 758 IMPEX FITNESS PRODUCTS 14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746 Tel: (800) 999-8899 Fax: (626) 961-9966 www.impex-fitness.com...

  • Page 2: Table Of Contents

    WARRANTY...… 10 ORDERING PARTS... 10 BEFORE YOU BEGIN Thank you for selecting the MARCY 758 Bench by IMPEX FITNESS PRODUCTS. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction.

  • Page 3: Important Safety Notices

    PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.

  • Page 5: Assembly Instructions

    ASSEMBLY INSTRUCTION Tools Required to Assemble the Machine: Two Adjustable Wrenches and Allen Wrenches. NOTE: It is strongly recommended this machine to be assembled by two or more people to avoid possible injury. STEP 1 (See Diagram 1) A.) Connect the Left and Right Upright Beams (#1) & (#2) by a Cross Brace (#4) in the mid- span.
  • Page 6 STEP 2 (See Diagram 2) A.) Attach the back of Main Seat Support (#3) to the Cross Brace (#4). Secure it with one Bracket (#23), two M10 x 2 ¾” Carriage Bolts (#41), two M10 Aircraft Nuts (#49). B.) Attach the Front Stabilizer (#6) to the front of the Main Seat Support (#3). Secure it with two M10 x 1”...
  • Page 7 STEP 3 (See Diagram 3) A.) Attach the Leg Developer (#5) to the bracket on the Front Stabilizer (#6). Secure it with an Axle (#43), two 5/8” Washers (#51), and M8 x 5/8” Allen Bolts (#44). B.) Attach the Handle Bracket (#10) to the Leg Developer (#5). Secure it with a 2 ¾” L- shaped Pin (#21) and a Spring Clip (#48).
  • Page 8 A.) Attach the Seat Bracket (#18) to the short pivot on the Main Seat Support (#3). Secure it with a M10 x 4 ¾” Allen Bolt (#42) and M10 Aircraft Nut (#49). Attach the Seat Support Bar (#9) to the pivot on the Seat Bracket (#18). Secure it with a M10 x 4 ¾” Allen Bolt (#42) and M10 Aircraft Nut (#49).

  • Page 10: Parts List

    PARTS LIST KEY NO. DESCRIPTION Left Upright Beam Right Upright Beam Main Seat Support Cross Brace Leg Developer Front Stabilizer Crutch Arm Curl Stand Seat Support Bar Handle Bracket Olympic Sleeve Backrest Adjustment Bar Backrest Incline Bar Weight Plate Holder Backrest Support Foam Tube Handle Tube...

  • Page 11: Warranty

    IMPEX. IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the product or other damages with respect to any economic loss, loss of property, loss of revenues or profits, loss of enjoyments or use, costs of removal, installation or other consequential damages or whatsoever natures.
