Daewoo KOR-6L773S Service Manual

Microwave oven

Advertisement

S/M No. : OR6L773S001
Service Manual

Microwave Oven

Model: KOR-6L773S
Caution
: In this Manual, some parts can be changed for improving,
their performance without notice in the parts list. So, if you
need the latest parts information, please refer to PPL(Parts
Price List) in Service Information Center (http://svc.dwe.co.kr).
Nov. 2011

Advertisement

Table of Contents
loading

Summary of Contents for Daewoo KOR-6L773S

  • Page 1: Microwave Oven

    S/M No. : OR6L773S001 Service Manual Microwave Oven Model: KOR-6L773S Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).
  • Page 2: Table Of Contents

    PRECAUTIONS TO BE OBSERVED BEFORE AND DURING SERVICING TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not operate or allow the oven to be operated with the door open. (b) Make the following safety checks on all ovens to be serviced before activating the magnetron or other micro- wave source, and make repairs as necessary: (1) Interlock operation, (2) Proper door closing, (3) Seal and sealing surfaces (arcing, wear, and other damage), (4) Damage to or loosening of hinges and latches, (5) Evidence of dropping or abuse.
  • Page 3: Safety And Precautions

    SAFETY AND PRECAUTIONS CAUTION This device is to be Serviced only by Properly Qualified Service Personel. Consult the Service Manual for Proper Service Procedures to Assure Continued Safety Operation and for Precautions to be Taken to Avoid Possible Exposure to Excessive Microwave Energy. 1.
  • Page 4: Specifications

    SPECIFICATIONS POWER SUPPLY 230V AC, 50Hz SINGLE PHASE WITH GROUNDING INPUT POWER 1000 W MICROWAVE ENERGY OUTPUT 700 W FREQUENCY 2,450MHz OUTSIDE DIMENSIONS (W 446 x 270 x 319 mm CAVITY DIMENSIONS (W 295 x 219 x 303 mm CAVITY VOLUME 20 L NET WEIGHT APPROX.
  • Page 5: External View

    EXTERNAL VIEW 1. OUTER DIMENSION...
  • Page 6: Features Diagram

    2. FEATURES DIAGRAM 1 Door latch - When the door is closed, it will 8 Viewing screen - Allows viewing of food. automatically shut off. If the door is opened while the The screen is designed so that light can pass oven is operating, the magnetron will automatically through, but not the microwave.
  • Page 7: Installation

    • This appliance is supplied with cable of special type, which, if damaged, must be repaired with cable of same type. Such a cable can be purchased from DAEWOO and must be installed by a qualified person. 6. Examine the oven after unpacking for any damage such as: A misaligned door, broken door or a dent in cavity.
  • Page 8: Operations And Functions

    OPERATIONS AND FUNCTIONS 1. Connect the mains lead to an electrical outlet. NOTE 2. After placing the food in a suitable container, open the oven When setting timer for less than 10 door and put it on the glass tray. The glass tray must always be minutes, turn the timer past 10 minutes in place during cooking.
  • Page 9: Disassembly And Assembly

    DISASSEMBLY AND ASSEMBLY Cautions to be observed when trouble shooting. Unlike many other appliances, the microwave oven is high-voltage, high-current equipment. It is completely safe during normal operation. However, carelessness in servicing the oven can result in an electric shock or possible danger from a short circuit. You are asked to observe the following precautions carefully.
  • Page 10 1. To remove cabinet 1) Remove four screws on cabinet back. 2) Pull the cabinet backward. 2. To remove door assembly 1) Remove two screws which secure the stopper hinge top. 2) Remove the door assembly from top plate of cavity. 3) Reverse the above for reassembly.
  • Page 11 3. To remove door parts. DOOR ASSEMBLY : 3511730190 REF No. PART CODE PART NAME DESCRIPTION Q’TY REMARK 3511730190 DOOR AS KOR-6L7B3S 3512211140 FRAME DOOR HIPS SG-970, HG-1760H 3517007300 BARRIER SCREEN *O PET T0.125 3515204120 STOPPER HINGE *T AS KOR-6L0B1A 3511706130 DOOR PAINTING AS KOR-6L0B1A...
  • Page 12 4. Method to reduce the gap between the door seal and the oven front surface. (1) To reduce gap located on part ‘A’ • Loosen two screws on the stopper hinge top, and then push the door to contact the door seal to the oven front surface.
  • Page 13 5. To remove control panel parts. C/PANEL ASSEMBLY : 3516743110 REF No. PART CODE PART NAME DESCRIPTION QíTY REMARK 3513412340 KNOB VPC SG-0760D, SG-175 3513412350 KNOB SG-0760D, SG-175 3516740390 CONTROL PANEL HIPS SG-970, HG-1760H 3517400510 COUPLER VPC KNOB 7122401211 SCREW TAPPING T2S TRS 4*12 MFZN 3518570400 SWITCH S/A RELAY...
  • Page 14 6. To remove high voltage capacitor. 1) Remove the screw which secure the grounding ring terminal of the H.V. diode and the capacitor holder. 2) Remove the H.V. diode from the capacitor holder. 3) Reverse the above steps for reassembly. High voltage circuit wiring 7.
  • Page 15 8. To remove wind guide assembly. 1) Remove the screw for earthing. 2) Remove the noise filter from the wind guide. 3) Remove the screw which secure the wind guide assembly. 4) Draw forward the wind guide assembly. 5) Pull the fan from the motor shaft. 6) Remove two screws which secure the motor shaded pole.
  • Page 16: Interlock Mechanism And Adjustment

    INTERLOCK MECHANISM AND ADJUSTMENT The door lock mechanism is a device which has been specially designed to completely eliminate microwave radiation when the door is opened during operation, and thus to perfectly prevent the danger resulting from the leakage of microwave. Primary interlock switch...
  • Page 17: Troubleshooting Guide

    TROUBLESHOOTING GUIDE Following the procedure below to check if the oven is defective or not. 1. Check grounding before trouble checking. 2. Be careful of the high voltage circuit. 3. Discharge the high voltage capacitor. 4. When checking the continuity of the switches, fuse or high voltage transformer, disconnect one lead wire from these parts and check continuity with the AC plug removed.
  • Page 18 Does the fan motor work when you shut the door and turn the timer? Does the oven lamp light? Replace or repair oven lamp, Does the turntable turn? turntable motor. Normal reading should be approx. 0 If microwave do not Check continuity Continuity No Continuity...
  • Page 19: Measurement And Test

    MEASUREMENT AND TEST 1. MEASUREMENT OF THE MICROWAVE POWER OUTPUT Microwave output power can be checked by indirectly measuring the temperature rise of a certain amount of water exposed to the microwave as directed below. PROCEDURE 1. A cylindrical container of borosilicate glass is used for the test. It has a maximum thickness of 3mm, an external diameter of approximately 190mm and a height of approximately 90mm.
  • Page 20: Microwave Radiation Test

    2. MICROWAVE RADIATION TEST CAUTION 1. Make sure to check the microwave leakage before and after repair of adjustment. 2. Always start measuring of an unknown field to assure safety for operating personnel from microwave energy. 3. Do not place your hands into any suspected microwave radiation field unless the safe density level is known. 4.
  • Page 21: Component Test Procedure

    3. COMPONENT TEST PROCEDURE • High voltage is present at the high voltage terminal of the high voltage transformer during any cooking cycle. • It is neither necessary nor advisable to attempt measurement of the high voltage. • Before touching any oven components or wiring, always unplug the oven from its power source and discharge the capacitor.
  • Page 22: Wiring Diagram

    WIRING DIAGRAM...
  • Page 23: Exploded View And Parts List

    EXPLODED VIEW AND PARTS LIST 1. DOOR ASSEMBLY Refer to Disassembly and assembly. 2. CONTROL PANEL ASSEMBLY Refer to Disassembly and assembly. 3. TOTAL ASSEMBLY F31 F30 F29 F28...
  • Page 24 REF. NO PART CODE PART NAME DESCRIPTION Q'TY 3511730190 DOOR AS KOR-6L7B3S 3516741190 CONTROL-PANEL AS KOR-6L753S 3510808410 CABINET AS KOR-6L0B1A 3516117410 CAVITY AS KOR-6L0B1A 3516004100 SPECIAL SCREW T1 TRS LR4 POLE 4*10 MFZN 7122401211 SCREW TAPPING T2S TRS 4X12 MFZN 7S312X40A1 SCREW SPECIAL T1 TRS 4*10 SE MFZN...
  • Page 25 DAEWOO ELECTRONICS CORP. 1-2, Jeo-dong 1(il)-ga, Jung-gu, Seoul, Korea C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: “DAEWOOELEC” S/M NO. : OR6L773S001 PRINTED DATE: Nov. 2011...
  • Page 26 V V I I S S I I O O N N C C R R E E A A T T I I V V E E , , I I N N C C . . 서울 종로구 통의동 6 번지 이룸빌딩 4 층 담 당 이수용 님 M O D E L KOR-6L773S (S/M) 접 수 2011.11.22 1차 2차 일...

This manual is also suitable for:

Kor-6l453sKor-6l353sKor-6l353s20Kor-4a070s
