Motherboard Connectors

Motherboard Connectors
Motherboard Connectors
Motherboard Connectors
Motherboard Connectors
PCI connectors
ISA connectors
Wake up LAN
connector
Seconary E-IDE connector
Primary E-IDE connector

Power Supply Connector

1-4

Figure 2. Motherboard connectors

The power supply converts AC power from a wall outlet to the DC voltages
required by motherboard and devices in your system. The power supply has a
large motherboard connector and several internal device (hard disk, CD-ROM,
and floppy disk drive, etc.) connectors.
The power supply should match the physical configuration of the chassis. Before
attaching all components, make sure the proper voltage has been selected. Power
supplies often can run on a wide range of voltages and must be set (usually via a
switch) to the proper range.
IrDA connector
AGP connector
CD audio connector
Back Panel I/O connectors
Front panel connectors
FDD connector
CPU fan connector
Power supply connector
Motherboard Description
