www.gracobaby.com

To Remove Existing Harness Tongues and Buckle and Attach Replacement Buckle

1
To loosen straps, lift lever
and pull harness straps.
4
Remove chest clip.
DO NOT DISCARD the
chest clip.
7
Slide NEW buckle onto
harness straps. MAKE
sure not to twist straps.
10
Re-insert straps back onto splitter plate.
See carseat owner's manual for inserting the
splitter plate into the correct set of loops for
your child.
Comfort Sport
2
5
Unbuckle harness by
tilting top of buckle
down, press top of red
tongues out of buckle.
8
Re-attach chest clip.
MAKE sure not to
twist straps.
Classic Ride
®
Buckle Replacement Guide
Remove harness
strap loops from
splitter plate.
button, and pull
9
Re-insert straps through slots
in seat pad and seat back.
See carseat owner's manual for inserting
the straps into the correct set of harness
Turn page over to
finish the rest of
the assembly
Steps 11 to 19
for the buckle
replacement.
Ready Ride
®
©2014 Graco PD272718A 2/14
3
Pull harness straps
through seat back and
seat pad.
6
Remove and discard
tongues.
slots for your child.
®
