Imation S-Class Specification Sheet

+
Taking SSDs to a New Level
Imation S-Class Solid State Drives combine powerful technology with a
superior design to help users change the way they look at computing. The S-
Class SSD delivers lightning-fast boot times, applications that load in a fraction
of the time, and the power to run graphics, design and game programs the
way they were meant to run.
Available in 32GB, 64GB and 128GB capacities, Imation S-Class Solid State
Drives provide data storage without motors or moving parts. SSDs are fast,
robust, reliable, reduce heat and noise generation, and have durability and
shock resistance.

Features and Benefits

+ HiGH PerForMaNCe
Imation S-Class Solid State Drives enable users to boot up faster,
find applications and files quicker and run more efficiently than hard
disks.
+ rUGGed deSiGN
Designed to withstand wear and tear, Imation S-Class SSDs feature
a rugged design for extreme endurance and performance in harsh
environments.
+ eaSY iNStallatioN
Designed for easy installation, Imation S-Class Solid State Drives
includes detailed, simple-to-follow instructions that assist users in
upgrading their notebook or desktop computer to high-performance
Solid State Drives. Imation S-Class SSDs are available with an
upgrade kit to streamline migration from a hard disk to an Imation
Solid State Drive.

Product Description

+ PriMarY
ordering UPC description
27519 S-Class SSD 2.5" SATA II 32GB
27522 S-Class SSD 3.5" SATA II 32GB
27523 S-Class SSD 3.5" SATA II 64GB
27524 S-Class SSD 3.5" SATA II 128GB
SSd + Upgrade Kit
27527 SSD 3.5" SATA II 64GB + Upgrade Kit
27528 SSD 3.5" SATA II 128GB + Upgrade Kit
© Imation Corp 2009 Imation Enterprises Corp 1 Imation Way Oakdale, MN 55128-3414 Ph: 651.704.4000 Fax: 651.537.4675 www.imation.com
Imation and the Imation logo are trademarks of Imation Corp. All other trademarks are the property of their respective owners. 52-0003-8275-5
S-ClaSS Solid
2.5" and 3.5" SLC-based Solid State Drives
UPC Size (lxWxH)
051122275197 7.4375 x 5.8125 x 2.5"
051122275227 7.4375 x 5.8125 x 2.5"
051122275234 7.4375 x 5.8125 x 2.5"
051122275241 7.4375 x 5.8125 x 2.5"
051122275272 7.44 x 5.88 x 2.6"
051122275289 7.44 x 5.88 x 2.6"
State drive

Technical Specifications

CaPaCitieS
32GB, 64GB, 128GB
ForM FaCtor
2.5" or 3.5"
SeQUeNtial read
130MB/s*
SeQUeNtial Write
120MB/s*
SeQUeNtial Write ioPS
51,000
SeQUeNtial read ioPS
83,000
raNdoM Write ioPS
130
raNdoM read ioPS
19,000
iNterFaCe
SATA II – 3.0Gbps
traNSMiSSioN ModeS
PIO mode (0-4), DMA mode (0-2), Ultra
DMA mode (0-6)
iNPUt voltaGe
5VCC+/-5%
oPeratiNG teMPeratUre
0-70°C (32-158°F)
CaSe FiNiSH
Stainless Steel
WarraNt
5 years limited
*As tested on a 32GB SSD; performance
varies by capacity and performance.
+ MaSter CartoN
Weight UPC Size (lxWxH)
.7 lbs 50051122275192 10.688 x 7.75 x 6.5
1.1 lbs. 50051122275222 10.688 x 7.75 x 6.5
1.1 lbs. 50051122275239 10.688 x 7.75 x 6.5
1.1 lbs. 50051122275246 10.688 x 7.75 x 6.5
0.95 lbs.
50051122275277 12.25 x 7.0 x 8.5"
0.95 lbs.
50051122275284 12.25 x 7.0 x 8.5"
Introducing
Weight Units
4.75 lbs. 4
5.25 lbs. 4
5.25 lbs. 4
5.25 lbs. 4
5.4 lbs 4
5.4 lbs. 4
