Patent Pending
Model No. IMTL99000
USER'S MANUAL
Serial No.
Write the serial number in the space
above for future reference.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are commit-
ted to providing complete
customer satisfaction. If you have
questions, or if there are missing
parts, we will guarantee complete
satisfaction through direct assis-
tance from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained technicians
on our Customer Hot Line will
provide immediate assistance, free
of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Visit our website at
Read all precautions and instruc-
tions in this manual before using
www.imagefitness.com
this equipment. Save this manual
new products, prizes,
for future reference.
fitness tips, and much more!
