Model No. IMTL22993
Serial No.
Write the serial number in the space
above for future reference.
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guarantee
complete satisfaction through di-
rect assistance from our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this man-
ual for future reference.
Serial
Number
Decal
®
USER'S MANUAL
Visit our website at
www.imagefitness.com
new products, prizes,
fitness tips, and much more!
Patent Pending
Advertisement
Table of Contents
Related Manuals for Image IMTL22993
Summary of Contents for Image IMTL22993
- Page 1 Model No. IMTL22993 Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are...
-
Page 2: Table Of Contents
To protect the floor or carpet from damage, place a mat under the treadmill. ture and dust. Do not put the treadmill in a garage or covered patio, or near water. - Page 3 6. Keep children under the age of 12 and pets away from the treadmill at all times. 7. The treadmill should not be used by persons weighing more than 250 pounds. 8. Never allow more than one person on the treadmill at a time.
-
Page 4: Before You Begin
The model number of the treadmill is IMTL22993. The serial num- ber can be found on a decal attached to the treadmill (see the front cover of this manual for the location). -
Page 5: Assembly
This is a normal condition and does not affect treadmill performance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner. -
Page 6: How To Use The Heart Rate Monitor
If heart rate readings do not appear until you begin perspiring, re-wet the electrode areas. • As you walk or run on the treadmill, position your- self near the center of the walking belt. For the console to display heart rate readings, the user must be within arm’s length of the console. -
Page 7: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT Your treadmill features a walking belt coated with PERFORMANT LUBE , a high-performance lubricant. IMPORTANT: Never apply silicone spray or other substances to the walking belt or the walking plat- form. They will deteriorate the walking belt and cause excessive wear. -
Page 8: Console Diagram
When the manual mode is selected, the speed and incline of the treadmill can be changed with a touch of a button. As you exercise, the LED track and the four displays will provide continuous exercise feedback. -
Page 9: How To Use The Manual Mode
START button. Adjust the incline of the treadmill as desired To change the incline of the treadmill, press the INCLINE buttons. Each time one of the buttons is pressed, the incline will change by 0.5%. The but- tons can be held down to change the incline quickly. - Page 10 HOW TO USE WORKOUT PROGRAMS The three speed programs automatically control the speed of the treadmill as they guide you through effec- tive workouts; the three incline programs automatically control the incline of the treadmill. Follow the steps below to use a workout program.
- Page 11 A moment after the START button is pressed, the walking belt will begin to move. (If an incline pro- gram is selected, the treadmill will also adjust to the first incline setting for the program, unless it is already at the first setting.) Hold the handrails and carefully begin walking.
-
Page 12: Trouble-Shooting
PROBLEM: The power turns off during use SOLUTION: a. Check the circuit breaker located on the treadmill near the power cord (see c. above). If the circuit breaker has tripped, wait for five minutes and then press the switch back in. - Page 13 1/4 of a turn each. Be careful not to overtighten the walking belt. Plug in the power cord, insert the key and run the treadmill for a few minutes. Repeat until the walking belt is centered. b. If the walking belt has shifted to the right, first re- move the key and UNPLUG THE POWER CORD.
- Page 14 PROBLEM: The heart rate monitor does not function properly SOLUTION: a. If the heart rate monitor does not function properly, see HEART RATE MONITOR TROUBLE- SHOOTING on page 6. b. If the heart rate monitor still does not function properly, the battery should be changed.
-
Page 15: Conditioning Guidelines
CONDITIONING GUIDELINES WARNING: Before beginning any exercise program, consult your physi- cian. This is especially important for individu- als over the age of 35 or individuals with pre- existing health problems. The heart rate monitor is not a medical de- vice. -
Page 16: Ordering Replacement Parts
If possible, place the treadmill near your telephone for easy reference when calling. IMAGE is a registered trademark of ICON Health & Fitness, Inc. ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase. - Page 17 REMOVE THIS EXPLODED DRAWING AND PART LIST FROM THE MANUAL Save this EXPLODED DRAWING and PART LIST and the USER’S MANUAL for future reference. Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of the User’s Manual.
- Page 18 PART LIST—Model No. IMTL22993 Note: To identify the parts listed below, refer to the EXPLODED DRAWING attached in the center of this manual. Key No. Qty. Description Console Base Screw Belly Pan Screw Handrail Cap Nylon Washer Incline Bolt/Motor Bolt...
- Page 19 EXPLODED DRAWING—Model No. IMTL22993 R1200A...
