- Page 1 Oper ator ′ s manual Please read the oper ator’s manual carefully and make sure you understand the instructions before using the machine. GR2026L/CL, GR2032L...
-
Page 2: Key To Symbols
KEY TO SYMBOLS Symbols Only use non-metallic, flexible cutting WARNING! Clearing saws, brushcutters attachments, i.e. trimmer heads with and trimmers can be dangerous! Careless trimmer cord. or incorrect use can result in serious or fatal injury to the operator or others. It is extremely important that you read and understand the contents of the operator’s manual. -
Page 3: Table Of Contents
CONTENTS Contents Note the following before starting: KEY TO SYMBOLS Please read the operator’s manual carefully. Symbols ............... CONTENTS WARNING! Long-term exposure to noise can Contents ..............result in permanent hearing impairment. So Note the following before starting: ........ always use approved hearing protection. INTRODUCTION Dear Customer, ............ -
Page 4: Introduction
If you will sell this machine, make sure that the buyer will get the operator′s manual. Good luck on using your Jonsered machine! Jonsered has a policy of continuous product development and therefore reserves the right to modify the design and appearance of products without prior notice. -
Page 5: What Is What
WHAT IS WHAT? ¥ What is what? 1 Trimmer head 15 Air purge 2 Grease filler cap, bevel gear 16 Air filter cover 3 Bevel gear 17 Clutch cover 4 Cutting attachment guard 18 Handle adjustment 5 Shaft 19 Locking nut 6 Loop handle 20 Support flange 7 Throttle control... -
Page 6: General Safety Precautions
GENERAL SAFETY PRECAUTIONS Important WARNING! Listen out for warning signals or shouts when you are wearing hearing protection. Always remove your hearing IMPORTANT! protection as soon as the engine stops. The machine is only designed for trimming grass. HEARING PROTECTION The only accessories you can operate with this engine unit Wear hearing protection that provides adequate noise are the cutting attachments we recommend in the chapter... -
Page 7: Machine's Safety Equipment
GENERAL SAFETY PRECAUTIONS Machine′ ′ ′ ′ s safety equipment Press the throttle lockout and make sure it returns to its original position when you release it. This section describes the machine′s safety equipment, its purpose, and how checks and maintenance should be carried out to ensure that it operates correctly. - Page 8 GENERAL SAFETY PRECAUTIONS Cutting attachment guard Regularly check the vibration damping units for cracks or deformation. Check that the vibration damping element is undamaged and securely attached. WARNING! Overexposure to vibration can This guard is intended to prevent loose objects from being lead to circulatory damage or nerve damage thrown towards the operator.
-
Page 9: Cutting Equipment
GENERAL SAFETY PRECAUTIONS Cutting equipment If the muffler on your machine is fitted with a spark arrestor mesh this must be cleaned regularly. A blocked mesh will cause the engine to overheat and may lead to serious This section describes how to choose and maintain your damage. -
Page 10: Assembly
ASSEMBLY Fitting the loop handle Assembling the cutting equipment WARNING! When fitting the cutting attachment it is • Unscrew the knob and plastic cover from the handle extremely important that the raised section mounting. on the drive disc/support flange engages correctly in the centre hole of the cutting attachment. -
Page 11: Fitting Other Guards And Cutting Attachments
ASSEMBLY Assembling and dismantling the • Fit the nut (G). Tighten the nut to a torque of 35-50 Nm (3.5-5 kpm). Use the socket spanner in the tool kit. Grasp two-piece shaft (GR 2026CL) the handle of the spanner as close to the trimmer guard as possible. -
Page 12: Fuel Handling
• The transport guard must always be fitted to the cutting • For best results and performance use JONSERED two- attachment when the machine is being transported or in stroke engine oil, which is specially formulated for our air- storage. -
Page 13: Fuelling
FUEL HANDLING Mixing Fuelling • Always mix the petrol and oil in a clean container intended for fuel. • Always start by filling half the amount of the petrol to be used. Then add the entire amount of oil. Mix (shake) the fuel mixture. -
Page 14: Starting And Stopping
STARTING AND STOPPING Check before starting Cold engine Ignition: Set the stop switch to the start position. Choke: Set the choke control in the choke position. • Check that the support flange is not cracked due to fatigue or due to being tightened too much. Discard the support flange if it is cracked. - Page 15 STARTING AND STOPPING Starting Hold the body of the machine on the ground using your left hand (CAUTION! Not with your foot!). Grip the starter handle, slowly pull out the cord with your right hand until you feel some resistance (the starter pawls grip), now quickly and powerfully pull the cord.
-
Page 16: Working Techniques
WORKING TECHNIQUES General working instructions 6 Always hold the machine with both hands. Hold the machine on the right side of your body. IMPORTANT! This section takes up the basic safety precautions for working with a trimmer. If you encounter a situation where you are uncertain how to proceed you should ask an expert. -
Page 17: Grass Trimming With A Trimmer Head
WORKING TECHNIQUES Grass trimming with a trimmer head Sweeping • The fan effect of the rotating cord can be used for quick and easy clearing up. Hold the cord parallel to and above the area to be swept and move the tool to and fro. Trimming •... -
Page 18: Maintenance
MAINTENANCE Carburettor Basic setting • The basic carburettor settings are adjusted during testing Your Husqvarna product has been designed and at the factory. The basic setting is richer than the optimal manufactured to specifications that reduce harmful setting and should be maintained for the first few hours the emissions. -
Page 19: Muffler
MAINTENANCE Fine adjustment of the idle speed T Correctly adjusted carburettor Adjust the idle speed using the idle adjustment screw T, if it is When the carburettor is correctly adjusted the machine will necessary to readjust. First turn the idle adjustment screw T accelerate without hesitation and burble a little at maximum clockwise until the cutting attachment starts to rotate. -
Page 20: Cooling System
However, before using the machine you should check that the bevel gear is filled 3/4 full with grease. Use JONSERED special grease. The grease in the bevel gear does not normally need to be changed except if repairs are carried out. -
Page 21: Spark Plug
MAINTENANCE Spark plug The spark plug condition is influenced by: • Incorrect carburettor adjustment. • An incorrect fuel mixture (too much or incorrect type of oil). • A dirty air filter. These factors cause deposits on the spark plug electrodes, which may result in operating problems and starting difficulties. -
Page 22: Maintenance Schedule
MAINTENANCE Maintenance schedule The following is a list of the maintenance that must be performed on the machine. Most of the items are described in the Maintenance section. The user must only carry out the maintenance and service work described in this Operator’s Manual. More extensive work must be carried out by an authorised service workshop. -
Page 23: Technical Data
TECHNICAL DATA Technical data Technical data GR 2026L/CL GR 2032L Engine Cylinder displacement, cm 26,9 30,8 Cylinder bore, mm Stroke, mm Idle speed, rpm 2700 2700 Recommended max. speed, rpm 11000-11700 11000-11700 Speed of output shaft, rpm 10000 10000 Max. engine output, acc. to ISO 8893, kW/ rpm 0,9/9000 1,1/8400 Catalytic converter muffler... -
Page 24: Ec-Declaration Of Conformity
(Applies to Europe only) We, Jonsered, SE-561 82 Huskvarna, Sweden, tel: +46-36-146500, declare that the clearing saws Jonsered GR2026L/CL and GR2032L with serial numbers dating from 2002 onwards (the year is clearly stated on the rating plate, followed by the serial number), comply with the requirements of the COUNCIL’S DIRECTIVE:... - Page 25 Poly Trim <20mm >20mm 6 Nm X 10...
- Page 26 8,5 m 10 cm 4" 4,2 m "Clic" 15 cm 6"...
- Page 27 4,25 m 4,25 m 15 cm 6" 15 cm 6"...
- Page 28 Tap n’ Go 35 8,5 m 10 cm 4" 4,3 m "Clic" 15 cm 6"...
- Page 29 Auto 32 4,0 m 15 cm ~2,0 m 6 " 6,5 ' 15 cm 6 "...
- Page 30 ´®z+R06¶6\¨ ´®z+R06¶6\¨...
- Page 32 1150162-26 ´®z+R06¶6\¨ ´®z+R06¶6\¨ 2006-08-18...
