i n s t r u c t i o n m a n u a l
Easy Control System
Editing is handled by the Easy Control System with a backlit
Play Mode
LCD display and touch-sensitive pads. Play Mode gives you
direct access to the most important parameters - perfect for
quick changes on stage.
Edit Mode
Edit Mode o ers more detailed changes to all parameters
that can be saved in 65 patches (presets).
YouPlay Mode
What's really unique about the NUMA is the so called You-
Play Mode, which allows you to create your own velocity
curves and save them to 15 presets. These customized
curves are available to every patch then.
Interactive NUMA
Due to the integrated USB connection, the NUMA can com-
USB <> Computer
municate with a computer. It o ers two modes of operation:
With USB MIDI the NUMA is recognized as a „USB-Audio-
Device" by the computer. More interesting is the USB Virtual
Com mode, enabling the computer to edit and store presets.
Even an update of the NUMA operating system is possible.
Connections
1 x MIDI Out (DIN 5-pin)
2 x Pedal (TS-Jack)
1 x USB
1 x Power Supply (9 V– / 500 mA)
Scope of supply
NUMA Nano keyboard
External power supply
PS -100 Sustain pedal
Perspex music stand
User manual
4 NUMA by Studiologic®
English
3
