Manual
3-Port Multi Monitor Mini DisplayPort
to DisplayPort® MST Hub
MSTMDP123DP
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 06/19/2013
*actual product may vary from photos
Advertisement
Table of Contents
Related Manuals for StarTech.com MSTMDP123DP
Summary of Contents for StarTech.com MSTMDP123DP
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 06/19/2013...
-
Page 2: Fcc Compliance Statement
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby... -
Page 3: Table Of Contents
Table of Contents Product Overview ..................1 Front View ..............................1 Packaging Contents ..........................1 System Requirements ..........................1 Installation ....................2 Microsoft® Windows® Operation ......................2 Apple OS X® Operation ........................... 5 Supported Video Resolutions ....................... 6 Specifications ..................7 Technical Support ..................8 Warranty Information ................8 Instruction Manual... -
Page 4: Product Overview
Product Overview Front View Integrated Mini DP #1 DP #2 DP #3 DisplayPort Cable Packaging Contents • 1x 3-Port Multi Monitor Mini DisplayPort to DisplayPort® MST Hub • 1x Power Adapter • 1x Instruction Manual System Requirements • Mini DisplayPort 1.2 enabled computer system/video card •... -
Page 5: Installation
2. Connect the integrated Mini DisplayPort cable into the Mini DisplayPort connector on the host computer system/video card. 3. Connect the DisplayPort monitor/display device(s) into the DisplayPort #1/#2/#3 connectors on the MSTMDP123DP MST Hub. 4. Power on the monitor/display device(s). 5. Turn on the computer system. - Page 6 NOTE: Each monitor connected is represented by a number displayed under “Change the appearance of your displays”. To determine which number corresponds with each display click the Identify button. 2. To adjust the Resolution, click on the number that corresponds with the monitor you wish to adjust, and select the drop down menu next to “Resolution:”.
- Page 7 3. To Choose whether the Monitor will Duplicate or Extend your main Monitor, select the number that corresponds with the Monitor you wish to adjust, and select the drop down menu next to “Multiple Displays:”. “Extend these displays” will extend your monitor main onto the selected monitor.
-
Page 8: Apple Os X® Operation
With a DisplayPort 1.2 compatible video card Apple OS X® will extend your Desktop onto the secondary monitors, and allow you to span a single Desktop expansion across each monitor connected to the MSTMDP123DP. Adjust Video settings to allow Spanning across all connected monitors in Apple OS X®... -
Page 9: Supported Video Resolutions
3. To place your spanned monitors, select the Arrangement tab. Your Main display will be shown with the spanned monitor next to it. You can click and drag to match your physical Monitor arrangement. Supported Video Resolutions Reduced Resolution Refreshing Rate Pixel Frequency Blanking 2560 x 1600... -
Page 10: Specifications
Specifications Video Signal DisplayPort Number of Ports 1x Mini DisplayPort Male External Connectors 3x DP Female One Display: 2560 x 1600 Maximum Display Resolution Two Displays: 1920 x 1200 Three Displays: 1920 x 1200 Instruction Manual... -
Page 11: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 12 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
