- Page 1 UNIQ UP-680/UP-680CL B/W Digital CCD Camera User's Manual 091-0680 V.1.3 07-22-04...
-
Page 2: Table Of Contents
Table of Contents Warning ......................... 2 Precautions ......................2 Limited Warranty ....................2 1. Introduction ....................... 3 2. Camera Setup ..................... 5 3. Camera Functions ....................5 4. RS-232C Communication Control ......…........10 5. Digital Interface Timing ..................12 6. Camera Functional Timing ................. 13 7. -
Page 3: Warning
WARRANTY WILL BE VOIDED. PRECAUTIONS Do dot attempt to disassemble, modify, or repair the camera. Contact UNIQ for help. Do not point the camera at bright objects, such as the sun, for a long period. It may cause CCD blooming and permanent damages. -
Page 4: Introduction
1. Introduction 1.1 General Description The UP-680/UP-680CL is a 10-bit, 659 x 494 full frame resolution digital CCD camera using progressive scanning interline-transfer technology. The square pixels are especially suitable for processing, measuring, and analyzing tasks. High speed moving objects can easily be captured with the external asynchronous capture control. -
Page 5: Camera Specifications
1.5 Camera Specifications Model UP-680 UP-680CL CCD Sensor 1/2” Hyper HAD progressive scan interline-transfer CCD Chip Size 7.48 mm x 6.15 mm Effective Pixels (H x V) 659 x 494 Unit Cell Size (H x V) 9.9 µm x 9.9 µm... -
Page 6: Camera Setup
Figure 1. Camera and Frame Grabber System Setup 3. Camera Functions 3.1 12-Pin Connector The 12-pin Hirose connector is located on the Pin No. UP-680 UP-680CL rear panel of the camera. All ground signals on pin 1, 3, 5, and 8 are common grounds. +12V DC input +12 V DC input is recommended on pin 2, but this camera should withstand +12 V ±... - Page 7 3.2 Mode Switches Selection Designation: NS-Functional select DS-Shutter speed select NR- RS-232C communication Enable RI- Rear switch control Enable NP- Reserved for custom options PS- Reserved for custom options Figure 3. Mode switches NM-Normal mode AM-Asynchronous mode Timing details of the mode switches are shown in section 6. 3.3 Shutter Speed Dial Switch Shutter speed dial switch is located on the rear panel and there are 16 different positions.
- Page 8 36 dB. Adjusting the gain potentiometer located on rear panel will change the gain value. Automatic gain control (AGC): AGC is not available and it is not recommended to use. Contact UNIQ for further details. Figure 6. Gain potentiometer...
- Page 9 3.6 Digital Output Pinout and Connector 3.6.1 40-Pin D-Sub Connector SIGNAL NOTE SIGNAL NOTE +12VIN/OUT RESERVED RESERVED CLK+ RS644/LVDS CLK- RS644/LVDS FEN+ RS644/LVDS VD / VINT FEN- RS644/LVDS RESERVED LEN+ RS644/LVDS LEN- RS644/LVDS RESERVED DATA0+ RS644/LVDS DATA1+ RS644/LVDS DATA0- RS644/LVDS DATA1- RS644/LVDS DATA2+...
- Page 10 3.6.2 26-Pin Camera Link Connector: PIN NO. CAMERA LINK UNIQ CAMERA FUNCTION SYMBOL SYMBOL 1, 14 INNER SHIELD SHIELD Inner shielding 2, 15 X0-, X0+ DATA0-, DATA0+ Video, LEN and FEN data output 3, 16 X1-, X1+ DATA1-, DATA1+ Video, LEN and FEN data output...
-
Page 11: Rs-232C Communication Control
4. RS-232C Communication Control 4.1 Hyper Terminal Program UNIQ does not provide its own software program for RS-232C communication. In order to use RS- 232C interface, a Hyper Terminal software program must be installed and applied. The following shows how to run and use of Hyper Terminal. - Page 12 Reference decrease will be added to stored reference. bn### Reference number Note: It’s very uncommon to change reference level, contact UNIQ for further details. Note: 1. Command must be in “lower case.” 2. All numbers have to be in “hex” format, use a PC calculator to convert between hex and decimal numbers if necessary.
-
Page 13: Digital Interface Timing
5. Digital Interface Timing 5.1 Pixel Clock 5.2 Line Enable 5.3 Frame Enable 5.4 Frame Enable for Vertical Binning Note: 1. Pixel clock = 25MHz 2. 1 N = 40 nsec. 3. 1 H = 793 N... -
Page 14: Camera Functional Timing
6. Camera Functional Timing 6.1 Free Run (shutter speed position 0, 60 fps) 6.2 Free Run (shutter speed position from 1 to F) 6.3 Asynchronous Capture (shutter speed position 0) 6.4 Asynchronous Capture (shutter speed position from 1 to E) 6.5 Asynchronous Capture with Pulse Width Control (shutter speed: F) - Page 15 6.7 Integration (via 12-pin Hirose connector ONLY) The UP-680/UP-680CL camera can be integrated up to 2 seconds without severe noise or dark current effect. To start integration, pin #11 (same as pin #27 of 40-pin digital connector) of the 12-pin connector must be connected to GND or 0V. The integrated video will be shifted out following the next vertical drive after pin #11 goes back to high or 5V level, as shown in figure 9 below.
-
Page 16: Camera Accessories
Contact UNIQ for vendor list. 7.2 Lens C-mount lens is the standard lens for UP-680/UP-680CL camera. There are a variety of C-mount lenses in the market that works with UP-680/UP-680CL camera. Make sure the quality and specification of the lens match the camera's application. Some of the most popular lenses in the market, such as Cosmicar, Fujinon, Rodenstock, and Schneider, are recommended. -
Page 17: Camera Malfunction
If it fails to show any good images, check the interface cable pinouts, both camera and frame grabber end, consult UNIQ or frame grabber manufacturer if necessary. Also, make sure the UP- 680/UP-680CL camera configuration file is correct. -
Page 18: Technical Support Information
If RS-232C is via 9-pin D-sub connector at PC end, make sure to short or connect pin # 4 and #6, and then short or connect pin # 7 and #8, but do not connect all 4 pins together. 9. Technical Support Information For technical assistance, contact UNIQ Technical Support or Applications Engineer at Phone: (408) 330-0818 Fax:...
