OWNER’S MANUAL Slim Blu-ray Disc Writer To enjoy fully all the features and functions of your product, please read this owner’s manual carefully and completely. BT30N...
Safety Instructions The laser used in the writer can damage your eyes. Do not CAUTION: attempt to open the cover. To reduce the risk of electric shock, do not remove the cover (or back). There are no user-serviceable parts inside. Refer servicing to qualified service personnel.
Introduction Drive Description This drive reads and writes to CD, DVD, and BD media. This drive has a 12.7 mm tray form factor. Features of the Drive • 12.7mm height internal slim BD-RE Drive. • CD-R/RW, DVD-R/-R DL/ -RW/ +R/ +R DL/ +RW, DVD-RAM, BD-RE/R read and write compatible.
Using the Drive Front Panel This following is the general figure of the design of the drive. The drive’s appearance and specifications may change without prior notice. 1. E mergency Eject Hole If the disc tray does not open when you press the eject button, power off the computer, insert a pin or unfolded paper clip in the hole and push firmly.
Page 6
Drive Operation Inserting a Disc • Press the eject button. The disc tray will be ejected. • Place the disc in the center of the tray with the label side facing up. • Push disc onto hub until secure. • Push the disc tray by hand and close completely. Removing a Disc •...
Page 7
Emergency Eject The procedure described below can be used to remove a disc from the drive if the eject button is disabled by software or a power failure occurs. 1. Turn the computer off. 2. Insert a small diameter rod or a stiff wire (a straightened paper clip about 1.2 mm [0.047 in] in diameter) into the emergency eject hole and push firmly.
Troubleshooting Please refer to the Introduction section to determine if the drive in your system is a slim device. Symptoms and Solutions Symptoms Solutions 1. Drive is not 1-1. Turn off the system, remove the drive, and re-insert back recognized by system. to the system.
Page 10
Symptoms Solutions 7. Cannot write to disc 7-1. Is the disc loaded in the drive with the read/write surface (for drives with write facing the right direction? The label should be up. If a disc capability). does not have a label, the disc code on the inner side of the disc should be properly oriented for reading when looking from the top of the disc.
Page 12
Specifications Read BD-ROM 6x max Write BD-R 6x max Write BD-RE SATA Gen.1 1.5 G bps (150 MB/s) Burst transfer rate Average access BD-ROM 230 ms typ. time (1/3 stroke) DVD-ROM 200 ms typ. CD-ROM 200 ms typ. Data Buffer 4 MB capacity Reliability...
