The Dragon Mobile Furnace is an indirect fired furnace providing heated air for water damage restoration,
structural drying, construction, event shelters and other temporary heating applications.
R E A D A N D S A V E T H E S E I N S T R U C T I O N S

Safety Information

Read this document carefully to learn how to properly
operate and service your Dragon Mobile Furnace. This
manual should be kept with the unit and remain with the
Dragon for the life of the product.
WARNING
WARNING! Do not alter or modify your Dragon in
any way. Use only replacement parts authorized by
Dri-Eaz Products, Inc. Modifications or use of
unapproved parts could create a hazard and will
void your warranty. Contact your authorized Dri-Eaz
distributor for assistance.
WARNING! Failure to comply with the instructions
and precautions provided in this Owner's Manual
can result in death, serious bodily injury, and/or
property loss or damage from hazards of fire,
explosion, burn, asphyxiation, carbon monoxide
poisoning, and/or electrical shock.
WARNING! Check the Dragon for proper air-to-fuel
ratio at each location. Failure to adjust for altitude
changes could cause injury, permanent damage to
the unit and secondary damage when ducting into a
structure. It may also void the Dri-Eaz warranty.
Refer to "Adjusting for Altitude," p. 5, for
instructions.
WARNING! Breathing Hazard. Fuel exhaust contains
deadly carbon monoxide gas. Operate the Dragon
only outdoors in open area. NEVER operate indoors
or in enclosed spaces.
07-01810A 2012-10 Warranty 07-00424
Owner's Manual
Dragon Mobile Furnace
Model F507
DRI-EAZ PRODUCTS, INC.
15180 Josh Wilson Road, Burlington, WA 98233
Phone: 800-932-3030 Fax: 360-757-7950 www.Dri-Eaz.com
• Do not stand closer than 8 ft. (2 m) from the outlet of
the heater. Do not lean or sit on the heater.
• Keep children and pets away.
• Make sure there is sufficient air circulation around
the unit during operation.
• Only do repair and maintenance after the heater has
cooled sufficiently and the heater is disconnected
from the electric power.
WARNING! Fire and Explosion Hazard
• Burner produces sparks and flame and unit
becomes hot during use. Hot surfaces can ignite fuel
vapors.
• Keep away from flammable vapors, such as those
from gasoline, paint thinner or solvents.
• Keep all flammable material away from the heater,
including combustible dusts, such as coal dust or
sawdust.
• Keep unit at least 8 ft. (2 m) away from any com-
bustible material.
• Diesel fuel is flammable and can be explosive.
• Do not smoke while operating, servicing, or refueling
the Dragon.
• Before refueling, turn the unit off, allow it to cool, and
then unplug.
WARNING! Electric Shock Hazard
• Unit must be grounded. Use only with 3-hole
grounded outlet.
• Never modify plug or use an adaptor. If an extension
cord is needed, it must have a three-prong
grounding plug and be rated for outdoor use.
• Never operate the Dragon in pooled or standing
water. If electrical components become wet, allow
them to dry before using.
1
Dri-Eaz Products, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F507 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dri-Eaz F507

  • Page 1: Safety Information

    It may also void the Dri-Eaz warranty. Refer to “Adjusting for Altitude,” p. 5, for instructions. WARNING! Breathing Hazard. Fuel exhaust contains deadly carbon monoxide gas.
  • Page 2: Electrical Requirements

    You can learn these skills in an IICRC-certified Applied Structural Drying (ASD) course. To learn more about ASD courses, contact the Dri-Eaz Education Department at 800-932-3030. Electrical requirements The Dragon Mobile Furnace is designed to operate on a 115V/60 Hz electrical connection.
  • Page 3: Before First Use

    CAUTION: Do not fill the tank while the unit is operating. rolling. Choose a location away from high-traffic areas, children and pets, and ensure there are no obstructions to the air intake. 07-01810A 2012-10 Warranty 07-00424 Dri-Eaz Products, Inc.
  • Page 4 Remote Thermostat” for instructions. To prevent adapter to fit the specific opening. overheating of the drying environment, we recommend using the thermostat at all times. 07-01810A 2012-10 Warranty 07-00424 Dri-Eaz Products, Inc.
  • Page 5: Special Instructions

    If the heat exchanger reaches 356°F (180°C), the limit switch will shut down the Dragon and the OVERHEAT light will glow amber (Fig. 2). In this case, the burner will automatically turn off 07-01810A 2012-10 Warranty 07-00424 Dri-Eaz Products, Inc.
  • Page 6: Recommended Maintenance Intervals

    START. It may require several tries until sufficient fuel is qualified HVAC technician. Contact your local distributor drawn through the fuel line. or the Dri-Eaz Service Department at 800-932-3030 for Tip: If the unit will not restart after several attempts, the location of a service center near you.
  • Page 7: Specifications

    1 25 ft. section of 12 in. (7.6 m × 30 cm) high- 360-757-7776. Copies of the Dragon manual and related temperature ducting. One end is fitted with a cuff and information are available at www.Dri-Eaz.com. Go to integrated belt and buckle. warranty.Dri-Eaz.com to register your purchase.
  • Page 8 Install both wheels. Place a washer on either side of the wheel hub and secure the wheel with the cotter pin. Bend tips of cotter pin around axle as shown below to secure it the wheel. Follow this procedure for both wheels. 07-01810A 2012-10 Warranty 07-00424 Dri-Eaz Products, Inc.
  • Page 9 Install rear stand. First, attach top of stand to the back edge of the tank using the fasteners provided. Secure the front of the stand over the fuel drain plug with the nut provided. 07-01810A 2012-10 Warranty 07-00424 Dri-Eaz Products, Inc.
  • Page 10 Exhaust flue installation Slide flue down over exhaust flange as shown. Ensure all fasteners are properly tightened and secure. The Dragon is now ready for use. 07-01810A 2012-10 Warranty 07-00424 Dri-Eaz Products, Inc.
  • Page 11 Orient the assembly as shown in the next frame, and use the jam nut to hold the assembly in place. Ensure that the assembly is tightened firmly over the foam seal. 07-01810A 2012-10 Warranty 07-00424 Dri-Eaz Products, Inc.
  • Page 12 Attach a quick-disconnect socket to the top nipple. Attach a quick-disconnect plug to the bottom nipple. Attach an adapter to each of the fuel line ends and tighten. Ensure that the compression fittings have bottomed out inside the adapter. 07-01810A 2012-10 Warranty 07-00424 Dri-Eaz Products, Inc.
  • Page 13 Attach a 90° fitting thru the filter bracket into the filter. Rotate the fitting so that it points directly out from the heater as shown: Attach the filter adapter (removed in the first step) to the 90° fitting. 07-01810A 2012-10 Warranty 07-00424 Dri-Eaz Products, Inc.
  • Page 14 2. Screw in the pickup tank cover/hose assembly and tighten. The conversion is now complete. To use the unit with the fuel pickup, simply disconnect the two fuel lines from the onboard tank and attach them to the pickup fuel lines. 07-01810A 2012-10 Warranty 07-00424 Dri-Eaz Products, Inc.
  • Page 15 Fig. 4: Electrical Schematic 07-01810A 2012-09 Warranty 07-00424 Dri-Eaz Products, Inc.
  • Page 16 D A T E M A I N T E N A N C E E F F E C T U É E E F F E C T U É E P A R 07-01810A 2012-09 Warranty 07-00424 Dri-Eaz Products, Inc.
