Mobile Digital Video System
User Manual
(104CF-V3)
Please read this user manual completely before operating this DVR system and keep it in a safe
place for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 104CF-V3 and is the answer not in the manual?

Questions and answers

Summary of Contents for 10-8 Video Digital Evidence Solutions 104CF-V3

  • Page 1 Mobile Digital Video System User Manual (104CF-V3) Please read this user manual completely before operating this DVR system and keep it in a safe place for future reference.

  • Page 2: Safety Instructions

    Caution! You, as the driver, are solely responsible for the safe operation of your vehicle and the safety of your passengers according to the US and local traffic regulations. . Do not use any features of this system to the extent it distracts you from safe driving. Your first priority while driving should always be the safe operation of your vehicle.
  • Page 3 Quick Install Overview The installation of the 10-8 Patrol Car video system breaks down to some very simple steps. The basic connection for video and audio are very similar to a VCR or DVD player. The one area that differs from what you may have done in the past is the connections for the alarm inputs (see separate addendum).
  • Page 4 Basic Wiring Diagram To: Ign On Power To: Ground 1. CF Card installation Insert the CF card Face-up into the CF card slot of the DVR. 2. Audio output connection Connect audio output to external speaker (Optional). 3. Video connection Connect the monitor to Video output terminal.
  • Page 5 Addendum: Power Distribution Block The power distribution block is included for your convenience and is not required that you use it. It makes it easy to power the 4 components in our system with just one power and one ground from the vehicle. It uses ¼” male spades for the input and ¼” female spades for the output.
  • Page 6 Addendum: Emergency Lights & Manual Switch Important: When you are setting up the ‘recorder options’, you must go in to the ‘schedule record’ screen and change all of the ‘c’s to ‘a’s. ‘A’ tells the recorder to record when an alarm triggers. (‘C’ tells the recorder to record continuously.) There are 3 leads coming from the sensor harness.

  • Page 7: Table Of Contents

    TABLE OF CONTENTS Table of Contents ……………………………………………………………………… Introduction …………………………………………………………………………….. Important Safety Information ………………………………………………………… Unpacking Your System ……………………………………………………………… Control Panel and Function ……………………………………………….…………. Installation ……………………………………………………………………………… Before Operation ……………………………………………………………………… Operation ………………………………………………………………………………. OSD (On Screen Display) Menu Setting Operation Process ………………….. Key and function for operation ………………………………………….………… OSD Setting Operation …………………………………………………………….

  • Page 8: Introduction

    INTRODUCTION Thank you for purchasing our unique 10-8 Video system. To ensure that you realize the full capabilities of this product, please read this user’s manual before proceeding. Be sure to keep this manual for future reference in case any problems or questions should arise. We hope you enjoy your new 10-8 system. IMPORTANT SAFETY INFORMATION When using your 10-8 equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and personal injury.

  • Page 9: Unpacking Your System

    UNPACKING YOUR SYSTEM Your 10-8 system will include the following: 1 x DVR 1 x Remote Control 1 x User’s Manual 1 x Mirror Monitor Wireless Microphone System Front View Camera CF Memory Card (in DVR) Power Dist. Block Camera Windshield Mount...

  • Page 10: Control Panel And Function

    CONTROL PANEL AND FUNCTION Front Panel 1. Power indicator 2. CF card slot 3. CF card busy 4. IR remote control receiver Rear Panel 5. Power On/Off switch 9. DC Input socket 6. Audio output terminal 10. RS-232 signal to DVR socket 7.
  • Page 11 Remote Control Power On/Off button Menu button Record button PTZ button Up key (Camera 1) Down key (Camera 3) Left key (Camera 2) Right key (Camera 4) Select button Play button Fast forward button Fast back button Pause button Audio 1 button Audio 2 button Audio Mute button Zoom in button...

  • Page 12: Installation

    Installation DVR Installation Please refer to the installation process per the following drawing: 1. CF Card installation Insert the CF card into the CF card slot of the DVR. 2. Audio output connection (optional) Connect audio output to monitor audio input. 3.
  • Page 13 The power supply with built-in delay circuit board is designed for the DVR to delay switch-on time for 10 seconds to avoid the DVR working on unstable voltage. It can also delay switch-off time from 10 minutes to 60 minutes selected by switch depending on the user requirement.

  • Page 14: Before Operation

    BEFORE OPERATION (1) The system will auto detect the hardware and enter Recording mode while hardware is in normal condition. (2) The system will show [UNKNOW HDD] then enter [Format Menu] within 3 seconds when a new unformatted CF card is inserted. Please select [FORMAT HDD YES] to format the CF card.

  • Page 15: Operation

    OPERATION The system is preset [KEY LOCK] to [OFF], when the system setting for [KEY LOCK] mode is [ON], the screen will show: PASSWORD: **** Please key in the security code by remote control number keys OSD (On Screen Display) Menu Setting Operation Process 1.
  • Page 16 Go Down (Down Key) (Left Key) Go Left (Right Key) Go Right (Enter Key) ENTER next page Play operation key Operation Remarks PLAY PLAY FAST FORWARD FAST BACK PAUSE / STOP REC operation key Operation Remarks RECORD PTZ control key operation (only with PTZ camera installed) Operation Remarks 1.
  • Page 17 The DVR system is preset to work wit h one channel. If you want to ch ange it for more channels, please do the following step When the DVR system is power ON a nd on record mode, 1. Press FF key two times, FB key tw o times and (Select) key two times.

  • Page 18: Osd Setting Operation

    OSD Setting Operation 1. Title Setup Operation A. Press key to enter menu selection mode. MAIN TITLE SETUP DATE/TIME VIDEO SETUP MOTION DETECT EVENT LIST AUTO SEQUENCE RECORD SETUP SYSTEM SETUP PERIPHERAL SETUP KEY LOCK:OFF NETWORK CF /HDD LOCK: ON B.

  • Page 19: Date / Time & Daylight Saving Time Setting

    2. Date / Time & Daylight Saving Time Setting A. Date/Time Setting a. Press key to enter menu selection mode. b. Use key to select [DATE/TIME] setting section. c. Press key to enter [DATE/TIME] setting mode. DATE/TIME SETUP DATE/TIME DAYLIGHT SAVING TIME d.

  • Page 20: Video Setup

    DAYLIGHT SAVING TIME TURN: OFF START TIME MONTH : 04 : 02 HOUR : 02 END TIME MONTH : 04 : 03 HOUR : 02 G. Use key to select area for setting. H. Use key to select value for setting. I.

  • Page 21: Motion Detect Setting

    VIDEO SETUP CH1 BRIGHTNESS: (00~63) CONTRAST: 36 (00~63) SATURATION: 36 (00~63) HUE: 36 (00~63) APPLY TO ALL a. Brightness: Brightness is adjustable, “00” = the darkest, “63” = the lightest. b. Contrast: Contrast is adjustable, “00” = maximum, “63” = minimum. c.

  • Page 22: Event List Selection

    MOTION DETECTION_CH1 TURN:ON (or OFF) RELAY OUTPUT: ON (or OFF) F. Press key to exit for select other setting mode or press key and keep more than 2 seconds to exit OSD setting operation. 5. Event List Selection A. Press key to enter menu selection mode.

  • Page 23: Auto Sequence Setting

    6. Auto Sequence Setting (For use when more than 1 camera is installed). A. Press key to enter menu selection mode. B. Use key to select [AUTO SEQUENCE] setting section. C. Press key to enter [AUTO SEQUENCE] select mode. AUTO SEQUENCE CH01: ON CH02: ON CH03: ON CH04: ON TIME INTERVAL: 5.0...
  • Page 24 Press Key to enter selected section for setting, then use key to select the section for setting and use key to select the value. a. Record Mode set up: 3 record modes For patrol car installations, this section should be set to all ‘A’s for Alarm Mode. SCHEDULE RECORD 10 11 16 17 18 19 20 21...
  • Page 25 c. Alarm / Motion Record: for set-up 4 level record quality, 10 kinds frame rate and duration for record while detect alarm or motion. A good starting point for patrol cars is: 2CIF, 8fps, High ALARM/MOTION RECORD RESOLUTION: CIF QUALITY: STANDARD REC TIME: 60 REC RATE: 30_FPS SENSITIVITY: 04...

  • Page 26: System Setup Operation

    * Set “ALARM/MOTION RECORD” mode and then select “PRE-RECORD: ON”. The system will record 100 images in the hard disk before alarm was activated. F Press key to exit menu or press key and hold more than 2 seconds to exit. 8.
  • Page 27 b. Password: to change password. (defaultl password: 0000) PASSWORD: c. PTZ: for setting protocol, baud rate when a pan/tilt/zoom camera is installed PROTOCOL: PELCO_D BAUD RATE: 9600 * Protocol: PELCO_D / PELCO_P * Baud Rate: 2400 / 4800 / 9600 / 19200 d.
  • Page 28 * Device: GPS / DIAL * Baudrate: 2400 / 4800 / 9600 / 14400 / 19200 / 38400 / 57600 / 115200 * Dial mode: TONE / PULSE g. DVR ID: for setting DVR ID number. Use for for Car or Officer ID DVR ID ID TYPE: ID: 0000...

  • Page 29: Peripheral Setting Operation

    9. Peripheral Setting Operation A. Press key to enter menu selection mode. B. Use key to highlight peripheral setup section. C. Press key to enter [PERIPHERAL SETUP] select mode. a. Buzzer: Select when you want the audio beep to be activated. We recommend setting ‘ON’ the ‘Alarm In’...

  • Page 30: Network Setting Operation

    11. Network Setting Operation (optional) Not Used.. (This function is available when the DVR is connected with LAN) A. Press key to enter menu selection mode. B. Use key to select “Network” section and press key to enter for setting. NETWORK REMOTE CONNECT: OFF (or ON) RESOLUTION: 2CIF...

  • Page 31: Play Back Record Data

    PLAY BACK RECORD DATA There are four ways to playback the record data. 1. Play begin file: Select this row to play back 1 file. 2. Play end file: Select this row to play back the final file. 3. Playback by date: Press the “Play”...

  • Page 32: Ptz Camera Setting And Control

    PTZ CAMERA SETTING AND CONTROL 1. Introduction: Connect the Signal I/O box to the DVR. The signal I/O box has RS485 ports for PTZ camera control. 2. Installation: 2.1 Setting PTZ camera control protocol: Follow PTZ camera user manual to choose and setting control protocol, all the camera need to choose same protocol type.

  • Page 33: Pc Player Software Operation

    4. PTZ control: How to move PTZ camera? The process is as follows: 1. Press PTZ button. 2. Select Channel to control. 3. Press Up key to move camera up. 4. Press Down key to move camera down. 5. Press Left key to move camera left. 6.
  • Page 34 3. How to play a recording: (1) Click on ‘Open New File’ Button (2) Click on Browse and select the file location. If the files are already on the hard drive, just select the location or if on a CF card, select the drive letter associated with your card reader.
  • Page 35 (3) Select the file by click on file with a .DVR extension and then selecting ‘Open’. Select the file on the next screen and select ‘Open’ to play. Or select ‘Search All Event’ to bring up a screen with all events that were recorded sorted by date and time.
  • Page 36 You will now be in the main player screen ready to play your video. Press the large ‘PLAY’ button to begin the video. Clicking on the speaker icon will mute the audio. Click again to un-mute the audio and use the sliding volume control and your speaker volume to adjust the volume.
  • Page 37 Select the path and file name you want the video saved to. Be sure and leave the .DVR extension on the file. Move the slider to the time in the video you wish to begin recording and then select the ‘Set time’ button next to the Start time window. For finer adjustment, use the left and right arrow buttons.
