- Page 1 Sonoma Breeze F100 Series User manual READ AND SAVE INSTRUCTIONS...
-
Page 2: Table Of Contents
CONTENTS Welcome For your safety Placement and specifications Design and Function Parts and Assembly Operating Instructions Time for a service Troubleshooting Warranty Contact us... -
Page 3: Welcome
(VOCs). Unlike other air filtration systems our technology removes air pollutants without emitting hazardous material such as ozone. Every space is different, and the speed that your Sonoma Breeze ® cleanses the air is related to the size of the room and the rate that VOCs are emitted into the environment. -
Page 4: Safety Precautions
• This unit purifies air, do not use as a substitute for ventilation. • Do not operate with wet hands or near standing water. • Do not open the Sonoma Breeze without turning off power ® to the unit. •... -
Page 5: Specifications
® ® intake air, place your unit a minimum of 8 inches (20.3 cm) away from any walls, or furniture. Do not place the Sonoma Breeze ® near doors or windows. The SonomBreeze needs to be placed ®... -
Page 6: Design And Function
Design and Function The Sonoma Breeze SB-100 is comprised of one front load- ® ing Macro-Particulate Filter, two germicidal UV lamps, three PCO- Purifier Cores or TCO-Purifier Cores, three Flow-Netic fans and an innovative formaldehyde sensor system. Our Macro-Particulate Filter coated with activated carbon absorbs dust, pollen, smoke and particles 3 µm or larger. -
Page 7: Parts And Assembly
Parts and Assembly Open side access door. Unpack the box 1. Loosen screws 2. Pull door out and up to remove from frame Slide in UV lights Slide in PCO core or TCO core . Close side access door . Connect power cord 1. -
Page 8: Operating Instructions
Operating Instructions 1. Follow all safety precautions listed above 2. Plug the power cord into wall outlet (115-240 V AC for USA) (100-120 V AC) 3. Press power switch Follow the light Our engineers have designed a multi-functional dis- play coded to tell you how effectively and efficiently your unit is operating. - Page 9 Keeping track There is one VOC LED display located next to the fan knob and below the status lights. This monitor indicates both VOC levels and formaldehyde levels present in the environment. Formaldehyde and other volatile organic compounds are measured in parts per billion (ppb), a measure of 1000 ppb is equivalent to 1 part per mil- lion (ppm).
-
Page 10: Time For A Service
Time for a service In order to keep your Sonoma Breeze functioning optimally it is ® essential to replace the filters and UV lights when they begin to deteriorate. How quickly each part deteriorates is dependent on the air pollution as well as the usage. We suggest that you... - Page 11 Replacing PCO/TCO Cores and UV Lights Remove used PCO or TCO Cores Disconnect power. Open side-access-panel door 1. Using the screw- driver provided, turn screws coun- terclockwise to loosen 2. Pull door out and up to remove Remove used UV bulbs Install new UV light bulb Press red button to release light bulb...
-
Page 12: Troubleshooting
Troubleshooting Q. I opened the unit while it was operating... A. For your safety we installed a safety mechanism that dis- ables the fans if opened while in us. Turn off the power, close all access panels, and turn the unit on. Q. -
Page 13: Warranty
Innovative Labs, LLC SB-40, SB-100, SB-200 Limited Warranty Innovative Labs, LLC warrants that all models of the Sonoma Breeze® including the SB-40, SB-100 and SB-200 will be free of defects in material and workmanship during normal operational use for one year from the date of purchase provided that the lights and filters are replaced as described in this manual. -
Page 14: Limited Warranty
Innovative Labs, LLC PCO/TCO Purifier Core Limited Warranty Innovative labs, LLC warrants that all models of the PCO/TCO purifier cores will be free of defects in material and workmanship during normal com- mercial or residential use for one- year from the date of purchase. Damage caused by accident, misuse or abuse is not covered by this warranty includ- ing, but not limited to, incorrect placement, obstruction of ventilation, fire, flood, or “acts of nature.”... - Page 15 Innovative Labs, LLC Germicidal UV Lamps Limited Warranty Innovative labs, LLC warrants that all models of the Germicidal UV lamps will be free of defects in material and workmanship during normal commercial use for one- year from the date of installation. Damage caused by accident, misuse or abuse is not covered by this warranty including, but not limited to, incorrect placement, incorrect voltage, fire, flood, damage caused by power surges from power outages or “acts of nature.”...
-
Page 16: Contact Us
Contact Us If you have any questions or concerns after reading this man- ual or contacting your distributor, please do not hesitate to contact our customer service department by calling toll free 1 (888) 706-0080. If you lose or damage your copy of this user manual, you can locate an electronic copy online at our web- site www.ino- labs.com. - Page 17 Innovative Labs, LLC 2012 The information contained herein is subject to change without notice. The only warranties for Innovative Labs, LLC products and services are set forth in the express warranty statements. Innovative Labs, LLC shall not be liable for technical or editorial errors or omissions contained herein.
