PARTS
ITEM
CODE NO.
NO.
1 317-468 GEAR
2 308-361 BEARING HOLDER
3 305-568 SEAL LOCK FLAT HD. SCREW M5X12
4 317-202 SAFETY COVER
5 317-203 RETURN SPRING
6 600-2VV BALL BEARING 6002VVCMPS2L
7 308-362 BEARING COVER
8 308-773 SEAL LOCK FLAT HD. SCREW M3X12
* 9 317-465 WASHER (A2)
* 9 317-466 WASHER (A1)
* 10 990-100 RING D15.9/I.D14.5
* 11 317-452 TCT SAW BLADE 165MM-D20 HOLE-NT40
* 11 317-451 TCT SAW BLADE 165MM-D15.88 HOLE
12 317-467 WASHER (B1)
13 957-749 BOLT (W/WASHER) M7X17.5
14 317-204 LIGHT COVER ASS'Y
15 LABEL (B)
16 NAME PLATE
17 317-211 TERMINAL (C)
18 958-715 TAPPING SCREW D4X10
19 320-996 MOTOR (B)
20 318-347 INNER COVER (A) ASS'Y
21 317-914 SPECIAL BOLT M5
22 317-194 LOCK LEVER
23 609-VVM BALL BEARING 609VVC2PS2L
24 317-195 INNER COVER (B)
25 317-196 NYLOCK BOLT (W/FLANGE) M4X12
26 302-012 NUT M5 (BLACK)
27 317-201 SAW COVER
* 28 CAUTION PLATE
29 HITACHI LABEL (B)
30 317-449 TAPPING SCREW (W/FLANGE) D5X50
31 LABEL (A)
32 321-003 HOUSING
33 961-803 SPRING
34 310-842 CUSHION
35 949-793 FLAT HD. SCREW M5X20 (10 PCS.)
36 949-425 WASHER M6 (10 PCS.)
37 948-167 SUPER LOCK WASHER M6
38 320-998 RESISTOR (A)
39 307-887 MACHINE SCREW (W/WASHER) M3.5X6
40 317-455 RESISTOR
41 980-061 SWITCH (1P SCREW TYPE) W/O LOCK
42 301-631 SPRING (F)
43 317-207 TERMINAL (A)
44 319-904 KNOB
45 321-004 HANDLE COVER
46 305-812
TAPPING SCREW (W/FLANGE) D4X16 (BLACK)
47 959-141 CONNECTOR 50092 (10 PCS.)
48 315-229 LAMP (12V 5W)
49 320-999 SOCKET
--- 2 ---
DESCRIPTION
* ALTERNATIVE PARTS
NO.
REMARKS
USED
1
1
2
1
1
1
1
3
1
1 FOR USA,CAN
1 FOR USA,CAN
1
1 FOR USA,CAN
1
1
1 INCLUD.15
1
1
1
3
1
1 INCLUD.21
2
1
1
1
2
1
1
1 FOR USA,CAN
1
3
1
1
1
1
1
2
2
1
3
1
1
1
1
1
1
5
2
1
1
C 6DC2
6 -- 02
