TIA-527
Balanced Optical/Electrical Converter

Operating Instructions

Terahertz Technologies Inc.169 Clear Road Oriskany NY 13424 (315) 736-3642 FAX (315) 736-4078
E-mail sales@terahertztechnologies.com
6/2011

Advertisement

Table of Contents
loading

Summary of Contents for TTI TIA-527

  • Page 1: Operating Instructions

    TIA-527 Balanced Optical/Electrical Converter Operating Instructions Terahertz Technologies Inc.169 Clear Road Oriskany NY 13424 (315) 736-3642 FAX (315) 736-4078 E-mail sales@terahertztechnologies.com 6/2011...
  • Page 2: Table Of Contents

    Contents Introduction ........................1 Unpacking and Inspection ....................1 Battery Replacement ...................... 2 Controls .......................... 2 Operating Considerations ................... 3, 4 Spectral Response ......................4 Typical Waveforms ......................5 Specifi cations ......................... 6 Limited Warranty ......................7 Repair Information ......................7...
  • Page 3: Introduction

    The TIA-527 has selectable transimpedances of 1.4 KΩ and 14 KΩ plus a post amplifi er with select- able gains of 1 or 10. Thus the overall responsivity ranges from approximately 1, 000 V/W to 100, 000 V/W at the peak of the detector response curve.
  • Page 4: Battery Replacement

    25 % ( 8 hours) of that of the much higher capacity Lithium types. TTI can supply these batteries if de- sired. Replacement of the battery may be accomplished by removing the four 2-56 Philips fl at head screws that retain the bottom cover of the TIA-527.
  • Page 5: Operating Considerations

    Operating Considerations The TIA-527 is comprised of two fi ber coupled detectors and two amplifi er stages. The fi rst ampli- fi er is a transimpedance stage which converts the net detector output current to a voltage by passing it through a resistor of 1 400 or 14 000 ohms. Additional amplifi cation is optionally provided by the second stage which also serves to provide 50 ohm drive capability.
  • Page 6: Spectral Response

    Operating Considerations continued The following table summarizes the operation of the unit under various operating conditions. Setting AC/DC Coupling 2nd Stage Signal Small Signal on large DC Components 1.4K X1, X10 As Needed High Frequency signal, >35 MHz 1.4K X1, X10 As Needed Low Level Signal<35 MHz X1, X10 As Needed Low Level, High Frequency Signal...
  • Page 7: Typical Waveforms

    Typical Waveforms Optical Input Output; T = 1.4 K, Gain = 1 Optical Input Output; T = 14 K, Gain = 1 Optical Input Output; T = 1.4 K, Gain = 10...
  • Page 8: Specifi Cations

    Output Offset Voltage +/- 0.1 Volt Noise Level 3.6 pW/ root-Hz TTI reserves the right to change specifi cations without notice. Maximum Output Voltage 4 V pk-pk, no load, 2 V pk-pk with 50 Ohm Load Power Requirements 9 V Battery or supplied universal wall-mount power supply...
  • Page 9: Limited Warranty

    For IN-WARRANTY REPAIRS, call us to obtain a Returned Material Authorization number, (RMA Number). All products are to be returned to TTI with freight charges pre-paid. Those products sent under warranty will be returned to our customers pre-paid. We cannot be responsible for returned products that do not reference the TTI RMA number.
