DIAMOND DIGITAL DX-D191P
Colour TFT LCD Monitor
19" (43 cm) LCD Panel Size

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DX-D191P and is the answer not in the manual?

Questions and answers

Related Manuals for DiamondDigital DX-D191P

Summary of Contents for DiamondDigital DX-D191P

  • Page 1 DIAMOND DIGITAL DX-D191P Colour TFT LCD Monitor 19” (43 cm) LCD Panel Size...
  • Page 2 Copyright 2008, Mitsubishi Electric Australia Pty. Ltd. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission.

  • Page 3: Table Of Contents

    IMPORTANT SAFETY INSTRUCTIONS ........iii Disclaimer ..................iv CHAPTER 1 INTRODUCTION............5 1.1 Product Description ............... 5 1.2 Product Features ..............5 1.3 Package Contents ..............6 1.4 Product Care................6 1.5 Product Dimension..............6 1.6 Caution ..................6 CHAPTER 2 OPERATION INSTRUCTIONS ......... 9 2.1 Front Control Panel ..............
  • Page 4 CHAPTER 6 WARRANTY ............20 After Sales Service ..............20 Warranty Does NOT Cover: ............20 Service Contacts ................ 21...

  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8.

  • Page 6: Disclaimer

    Diamond Digital is a registered trademark of Mitsubishi Electric Australia Pty. Ltd. Microsoft and Windows are registered trademarks of Microsoft Corporation.

  • Page 7: Chapter 1 Introduction

    CHAPTER 1 INTRODUCTION Thank you for choosing the Diamond Digital DX-D191P LCD monitor. Your LCD monitor is safe to use and completely free from any X-ray radiation. We hope you enjoy using our product, and would like to provide the following additional information to assist you in obtaining the best results, using the product safely and in complete comfort.

  • Page 8: Package Contents

    1.3 Package Contents Standard package includes the following: 1. 19" TFT LCD Monitor. (Depend on the screen diagonal) 2. Power Adapter. 3. Signal Cable. (VGA Cable) 4. User Manual. 1.4 Product Care 1. To remove dust or dirt from the screen, use a soft clean cotton cloth and wipe gently.
  • Page 9 PRODUCT ● 1. Do not cover or block the ventilation holes in the back of the monitor case. 2. Do not insert any metal objects into the ventilation holes of the monitor case and be careful not to spill liquids over this product as this could result in severe injury.
  • Page 10 POWER CORD AND SIGNAL CABLE ● 1. Do not place anything on the power cord or signal cable. 2. Do not allow any cables from the monitor to lie on the floor in an area where pedestrians are likely to trip, causing injury. 3.

  • Page 11: Chapter 2 Operation Instructions

    CHAPTER 2 OPERATION INSTRUCTIONS 2.1 Front Control Panel 1. Power Switch: press to switch monitor on / off. 2. LED Indicator: power indicator. 3. Mode: press to select input signal. (See ※ Note) 4. Auto: VGA signal auto adjustment. 5. Plus (+): press to increase the value of OSD option selected; press to increase volume.

  • Page 12: Osd Menu

    ※ Note: On the first press, the monitor shows OSD of the current signal. Before the OSD disappears, press the button again to change the input signal source. 2.2 OSD Menu VGA / DVI Signal ● 1. Brightness 2. Contrast 3.
  • Page 13 VIDEO Signal (Composite / S-Video / Component) ● 1. Colour 2. Tint 3. Brightness 4. Contrast 5. Sharpness 6. Volume 7. H-Position 8. Language English ※ 9. Colour Temp. Standard 10 Scan Over 11. PIP 12. PIP Size/Pos. DEF. Hot Key 13.

  • Page 14: Osd Function Table

    2.3 OSD Function Table VGA / DVI ● Brightness Adjust back ground black level of the screen image. Contrast Adjust fore ground white level of the screen image. H-Position Adjust the left or right position of the screen image. V-Position Adjust the up or down position of the screen image.
  • Page 15 VIDEO (Composite / S-Video / Component) ● Colour Adjust the colour density. Tint Adjust the colour tint. (NTSC only) Brightness Adjust back ground black level of the screen image. Contrast Adjust fore ground white level of the screen image. Sharpness Adjust the clarity and focus of the screen image.

  • Page 16: Input Signal Icon

    2.4 Input Signal Icon VGA Signal DVI Signal Composite Signal S-VIDEO Signal Component Signal 2.5 Hot Key Icon Volume Adjustment Contrast Adjustment Brightness Adjustment...

  • Page 17: Chapter 3 Signal Connector And Instruction

    CHAPTER 3 SIGNAL CONNECTOR AND INSTRUCTION Input / Output Interface 1. DC In 2. DC Out: DC 12V / MAX. 1A. 3. VGA In 4. VIDEO In / Out (BNC-TYPE) 5. Y/C In / Out (4-Pin mini-Din) S-Video 6. Audio In / Out (RCA Jack) If you choose a video input without connecting any video signal, “No Signal"...

  • Page 18: Chapter 4 Viewing Angle

    Caution: AVOID directly pulling any cables, when disconnecting devices from the monitor. Always disconnect devices carefully by firmly gripping the metal or plastic connector body and gently easing the connector from its socket. CHAPTER 4 VIEWING ANGLE For the user’s convenience, the LCD screen may be tilted according to viewing requirements.
  • Page 19 RAK191 - RACK MOUNTING BRACKET 【OPTIONAL】 ● CM191 - CEILING MOUNTING BRACKET 【OPTIONAL】 ●...
  • Page 20 WB-191 - WALL MOUNTING BRACKET 【OPTIONAL】 ● ● Base Dismounting Process (Step 1) Remove the Hinge Cover (1-1) Insert a thin tool into the hole of the hinge cover, then pull upward and outward to remove the cover. . (1-2) Pull the cover outward 4~5 mm as indicated by arrow A, then pull the cover upward as indicated by arrow B, then remove the cover.

  • Page 21: Chapter 5 Panel Specification

    CHAPTER 5 PANEL SPECIFICATION Please refer to attach specification sheet. MODEL 19" Pixel pitch 0.294 x 0.294. (H x V mm) VGA / DVI 1280 x 1024 pixels. Max. Resolution VIDEO 500TVL. Dimension 421.2 x 405.6 x 170.0 (W x H x D mm) Packing Dimension 553.0 x 534.0 x 242.0 (W x H x D mm)

  • Page 22: Chapter 6 Warranty

    CHAPTER 6 WARRANTY After Sales Service After this product is unpacked, keep the carton and packing materials to ensure safe transportation in case of any after sales service. The warranty is covered by a 3 year limited warranty, subject to normal conditions of use.

  • Page 23: Service Contacts

    Service Contacts Australian Service Contacts Visit the Customer Support page of Mitsubishi Electric Australia’s web site at; www.mitsubishielectric.com.au Further details of your nearest Mitsubishi Electric Authorized Service Center or to contact a Mitsubishi Electric Service Representative in your state or territory: New South Wales and Australian Capital Territory 348 Victoria Road Rydalmere, NSW, 2116...
  • Page 24 South Australia and Northern Territory 77 Port Road Hindmarsh, SA, 5007 Telephone: (08) 8340-0444 Fax: (08) 8340-0555 Victoria and Tasmania 4 / 303 Burwood Hwy East Burwood, VIC, 3151 Telephone: (03) 9262-9899 Fax: (03) 9262-9850 Western Australia 5 / 329 Collier Road Bassendean, WA, 6054 Telephone: (08) 9377-3411 Fax:...
