- Page 1 ® DIAMOND DIGITAL DV1772FD / DV1772FDB Colour Monitor 17” (43 cm) CRT Size 16” (40.6 cm) Viewable Area User’s Manual...
- Page 2 Diamond Digital is a registered trademark of Mitsubishi Electric Australia Pty. Ltd. Microsoft and Windows are registered trademarks of Microsoft Corporation. Apple and Macintosh are registered trademarks of Apple Computer, Inc. All other trademarks remain the property of their respective owners. UG/MON1770H/0102/1...
-
Page 3: Table Of Contents
Table of Contents Important Safety Instructions .......... 1 Features ................2 Unpacking the Monitor ............. 3 Installation ................. 4 Drivers for Windows 95, 98, 2000, XP and Millennium Edition..Adjusting the Monitor ............6 Selecting Functions and Making Adjustments ....... Contrast Hotkey ................ -
Page 4: Reference Information
For future reference, write the following information about your monitor in the space below. The serial number is on the back of the product or on the bottom of its stand. Monitor Information Product Name: DV1772FD / DV1772FDB Serial Number: Date of Purchase: Dealer Information Dealer:... -
Page 5: Important Safety Instructions
Important Safety Instructions Please read the following safety instructions before installing or cleaning your Diamond Digital monitor: This monitor must be operated from the type of power source indicated on the rating label. If you are not sure of the type of power available in your area, consult your dealer or local electricity supply company. -
Page 6: Features
The monitor supports VESA standard graphics signals with flicker-free refresh rates at resolutions up to 1024 x 768 pixels at 85Hz. ♦ Larger Viewable Size With its 40.6 cm (16”) diagonal viewable screen size, the DV1772FD offers a larger viewable screen area than many other 17” CRT monitors. -
Page 7: Unpacking The Monitor
Unpacking the Monitor Please check that the following items are included with your monitor. If they are missing or damaged, please contact your place of purchase immediately. ♦ Monitor with attached signal cable ♦ Tilt/swivel base ♦ Power cord ♦ User’s manual Locate the model name and the serial number label on the back of your monitor and write the details of the monitor and your place of purchase in the space on page (ii) of this manual for future reference. -
Page 8: Installation
100 to 240 Volts AC at a frequency of 50 to 60 Hz. Install Remove Connecting Cables Power Cord Signal Cable To install your Diamond Digital DV1772FD monitor: 1. Make sure that the computer system’s power is turned off. -
Page 9: Drivers For Windows 95, 98, 2000, Xp And Millennium Edition
Drivers for Windows 95, 98, 2000, XP and Millennium Edition Windows will detect the Diamond Digital DV1772FD monitor the first time you turn the computer on after installing it. The Add New Hardware wizard will prompt for drivers. Install the standard Windows Plug & Play Monitor driver. -
Page 10: Adjusting The Monitor
Adjusting the Monitor You can adjust the monitor using its On-Screen Display (OSD) menu system. There are 4 buttons that control the monitor: 1. Power To turn the monitor on and off OWER NDICATOR Activates OSD function or function adjustment MENU confirmation Moves to another menu item or increases the... -
Page 11: Selecting Functions And Making Adjustments
Selecting Functions and Making Adjustments Contrast Hotkey ‘>‘ 1. Press to open the contrast adjustment display. 2. Press < or > to adjust the contrast level. 3. Press the MENU button to save your changes. Brightness Hotkey ‘<‘ 1. Press to open the brightness adjustment display. -
Page 12: The Main Menu
The Main Menu The Diamond Digital DV1772FD’s controls are accessed by pressing the MENU button, to open the OSD (On-Screen-Display). The main menu will be displayed as follows. Making Adjustments H: 68.8KHz V: 85Hz Contrast 6500 9300 1024 × 768... - Page 13 The description for functional control icons CONTRAST Adjust the picture contrast. BRIGHTNESS Adjust the picture brightness. H-CENTER Adjust the horizontal position of the picture. H-SIZE Adjust the picture’s horizontal size. V-CENTER Adjust the vertical position of the picture. V-SIZE Adjust the picture’s vertical size. ZOOM Adjust the picture’s horizontal and vertical size simultaneously.
- Page 14 13. 6500°K/9300°K (COLOR TEMPERATURE ) The color temperature for 6500°K is x=0.313, y=0.329 and 9300°K is x=0.283, y=0.297. It presents two different color sets on the screen. You can select 9300°K or 6500°K by pressing MENU Key. 14. USER COLOR ( Red / Blue ) If the 9300°K normal white or 6500°K warmer white do not satisfy your desire, properly adjust RGB GAIN controls to obtain your optimum whiteness level.
-
Page 15: Timing And Refresh Rate Setting
The monitor will automatically save the changes that you make and use the new settings whenever you turn it on. The Diamond Digital DV1772FD monitor can accept horizontal scanning frequencies ranging from 30 kHz to 72 kHz and vertical frequencies from 50 Hz to 160 Hz. -
Page 16: Troubleshooting
Troubleshooting If you encounter any trouble using the Diamond Digital DV1772FD monitor, make sure that your monitor is properly installed. (For hardware installation, see Chapter 4 of this manual.) If the problems persist, please check this chapter for possible solutions before calling Mitsubishi Electric or one of our Authorised Service Centres. - Page 17 Remove any magnetic objects that are near the monitor. These include speakers and power supplies (AC adaptors). Colours are impure. Check that the cable is securely connected to the computer. Check the VGA signal cable for damage. If any pins are bent or broken off, contact your dealer or an authorised Mitsubishi Electric service agent (see Chapter 8 for details).
-
Page 18: Specifications
Specifications Model DV1772FD Display Characteristics Display Type 17” (43.2 cm) diagonal cathode ray tube Maximum Viewable Size 16” (40.6 cm) diagonal Dot pitch 0.25 mm (0.21 mm horizontal dot pitch) Surface coating Anti-Glare, Anti-Reflective, Anti- Static coating Graphics Signals Maximum Resolution... -
Page 19: User Interface
User Interface Mains power switch, On-Screen Controls Display with 4 control buttons On-Screen Display Functions: Contrast; Brightness; Horizontal Position; Horizontal Size; Vertical Position; Vertical Size; Zoom; Pincushion, Balance, Trapezoid, Parallelogram, Rotate; 6500°K; User Colour; 9300°K; Degauss; Moire; Exit; OSD Language; Physical Characteristics VESA DPMS, Energy Star Power Management... -
Page 20: Service Contacts
Service Contacts If problems remain after checking this manual, please contact your place of purchase or contact Australian Service Contacts Visit the Mitsubishi Electric Australia web site at www.mitsubishielectric.com.au For details of your nearest Mitsubishi Electric Authorised Service Centre or contact the Service Department for your state: New South Wales and Australian Capital Territory 348 Victoria Road... - Page 21 Victoria and Tasmania 4 / 303 Burwood Hwy East Burwood, Vic, 3151 Telephone: (03) 9262-9899 Fax: (03) 9262-9850 Western Australia 5 / 329 Collier Road Bassendean, WA, 6054 Telephone: (08) 9377-3411 Fax: (08) 9377-3499...
