Summary of Contents for Philips Specialist FC9130

  • Page 3 ENGLISH 4...
  • Page 4: General Description

    26 Type plate 14 Storage position Important Only use Philips Sydney+ double-layer paper dustbags, Philips s-bag` double-layer paper dustbags or the re-usable dustbag, if provided (some versions only). Never suck up water or any other liquid. Never suck up flammable substances and do not suck up ashes until they are cold.
  • Page 5 ENGLISH Tube Button coupling Connect the tube to the handgrip by pressing the spring- loaded lock button on the handgripand inserting the handgrip into the tube. Fit the spring-loaded lock button into the opening in the tube (‘click’). To disconnect the tube from the handgrip, press the spring- loaded lock button and pull the handgrip out of the tube.
  • Page 6 ENGLISH Carpet setting: Push the rocker switch again to make the brush strip disappear into the nozzle housing.The wheel will be lowered automatically. The opening at the front of the nozzle allows you to effectively suck up larger particles. Crevice tool, small nozzle and small brush Connect the crevice tool (1), the small nozzle (2) or the small brush (3) directly to the handgrip or to the tube.
  • Page 7 The scent granules have been specially developed for use in your Philips vacuum cleaner. Only use the s-fresh` scent granules from Philips in your vacuum cleaner. If the vacuum cleaner is equipped with Active Fragrance Control, keep it out of the reach of children. Don't let children play with the appliance.
  • Page 8 ENGLISH Using the appliance Infrared remote control Place the batteries in the battery compartment. Make sure the - and + poles are pointing in the right direction. With the infrared remote control you can set the suction power to one of 5 different suction power settings.When you switch the appliance on, it will always start running at the highest suction power setting.
  • Page 9 ENGLISH Storage You can put the appliance in upright position and attach the nozzle to the appliance by inserting the ridge on the nozzle into the slot. Always put the Tri-Active nozzle in carpet setting when you store it and prevent the side brushes from becoming bent. Replacement The dustbag Replace the dustbag as soon as the dustbag-full indicator...
  • Page 10 The mains cord If the mains cord of this appliance is damaged, it must always be replaced by Philips or a service centre authorised by Philips, as special tools and/or parts are required. Cleaning and maintenance of filters...
  • Page 11 ENGLISH Press the filter holder with the clean filter firmly into place to ensure that it fits properly at the bottom. Place the dustbag holder with the dustbag back into the appliance. Motor Outlet Filter The AFS Micro Filter located in the back of this appliance filters a large part of the smallest particles from the exhaust air by means of its electrostatically charged fibres.
  • Page 12: Ordering Accessories

    Information & service If you need information or if you have a problem, please visit the Philips Web site at www.philips.com or contact the Philips Customer Care Centre in your country (you will find its phone number in the worldwide guarantee leaflet).
  • Page 13: Troubleshooting Guide

    ENGLISH Troubleshooting guide The suction power is insufficient: Check if the suction power control is in the required position (see 'Using the appliance'). Check if the dustbag is full. If necessary, replace the dustbag. Check if the filters need to be replaced. Check if the nozzle, tube or hose is blocked up.
  • Page 14 Tri-Active Sydney+...
  • Page 15 Tri-Active Tri-Active ‚ Ï ‚...
  • Page 18 Standby...
  • Page 21 Sydney+ HR6999 s-bag` FC8021 432200493290 FC8030 FC8025...
  • Page 22 www.philips.com...
  • Page 23 2003/04...
  • Page 24 4222 000 49911...
