Mercury SMDC401UK User Manual

Function:

This compact, energy efficient switch-mode power supply gives up to 1000mA with a variable
output of 3V to 12V. Suitable for most low power electronic products such as MP3 players, PDA etc.
Comes supplied with 8 adaptors
Uses 25% less power making it more energy efficient
Materials used and manufacturing process are more environmentally friendly

Technical data:

Input Voltage: AC 100 - 240V 50/60Hz
Output Voltage: DC 3V to 12V
Output current: 1000mA max. (all voltages)
Output power: 12W

Instructions:

1. Please read these instructions fully before using this apparatus.
2. For office equipment use only.
3. Check the housing for damage.
4. Connect the unit to be powered, select the correct polarity, voltage and connector size,
failing to do this, could result in damage to your equipment.
The unit to be powered must not draw more current than the maximum continuous
5.
current of the power supply, in order to prevent overload. (The continuous current draw,
should be no more than 80% of the output current max.).
6. Plug the power supply into a wall outlet.
7. The Red LED will light.
Variable Voltage Switch-mode Power Supply
SMDC401UK
Item ref: 661.401UK
User Manual
