Mercury 650.659UK User Manual

Function:

The CB-R range of power supplies are ideal for powering CB radios.
This range of power supplies feature electronic voltage control and short-circuit protection. Ideal
for powering CB Radios, communication transceivers and other appliances. Sturdy case fitted with
a mains lead and plug.

Technical data:

Input Voltage: AC 230V 50Hz
Output Voltage: DC 13.8 V
Output current: 650.659UK (15A max.) / 650.661UK (20A max.)
650.662UK (30A max.) / 650.664UK (40A max.)
Output power: 650.659UK (207W) / 650.661UK (276W)
650.662UK (414W) / 650.664UK (552W)

Instructions:

1. Please read these instructions fully before using this apparatus.
2. Check the housing and the mains cable for damage.
3. Connect the unit to be powered to the Red and Black terminals (Red +, Black -).
4. The unit to be powered must not draw more current than the maximum continuous
current of the power supply, in order to prevent overload. (The continuous current draw,
should be no more than 80% of the output current max.).
5. Plug the power supply into a wall outlet.
6. Switch the unit on via the power switch. The Red LED indicator will light.

Warning:

1. For indoor use ONLY.
CB-R Range
Bench Top Power Supplies
User Manual
