DATA PORT
Ethernet 10/100BT
Fully integrated IEEE 802.3/802.3u
10/100 base T-Physical layer
Auto-negotiation 10/100, Full/Half
Duplex
Adaptive equaliser, Baseline
wander correction
Host USB
2.0 High speed (480 Mbits/s)
FRONT PANEL
4 x 7-segment amber display
1 x IR sensor: 38 kHz
1 x Bicolor LED
3 x Buttons (P+,P-, Standby)
1 x USB 2.0 connector (Type A
Host)
REAR PANEL
1 x RJ45 (Ethernet 10/100BT)
1 x IEC169-24 female (satellite in)
2 x SCART (TV, VCR)
3 x RCA (Stereo L/R, S/PDIF)
1 x HDMI
POWER SUPPLY
External AC/DC adapter
AC: 220-240 V ~50 Hz
Max. Power consumption: < 22 W
Standby mode: < 2 W (standby
inactive)
PHYSICAL SPECIFICATIONS
Receiver:
Size (wxdxh): 310x175x41 mm
Weight: ~0.7 Kg (package: ~1.6 Kg)
Operating temperature: 0°C to +40°
Storage temperature: -25°C to
+65°C
DSI86 HD freesat
ACCESSORIES
1 x External AC/DC adapter (1.2 m)
1 x Power cord
1 x Remote control (range: 7 m)
2 x Saline 1.5 V batteries (AAA type)
1 x HDMI cord (1.5 m)
1 x Installation guide
1 x freesat presentation leaflet
1 x User manual
