CONTENTS 1. DESCRIPTION OF SYMBOLS 7. ATTACHMENT SETUP 2. SAFETY RULES 8. EXAMPLE OF FUEL-MIXING 3. PARTS IDENTIFICATION 9. STARTING, OPERATION, STOPPING 4. TECHNICAL DATA 10. TRIMMING 5. ACCESSORIES 11. MAINTENANCE 6. EXPLANATION OF TERMS 12. DECLARATION OF CONFORMITY -1. DESCRIPTION OF SYMBOLS Read and follow this operator’s manual.
2. SAFETY RULES 2-1. Notes when using the nylon-cutting head and 3 teeth blade. 1. The grass trimmer was designed to cut grass and small, soft vegetation. Never use the trimmer for any other purpose. 2. Only use nylon cutting heads that meet the trimmer rotation rate requirements. Use nylon cords designated for the nylon cutting heads. 3.
7.ATTACHMENT SETUP 7-1. Attach the Engine to the shaft tube 1. Put engine and shaft tube on the ground then assemble as shown in Fig.1. 2. Ensure the M6x30 screws are tightened to prevent them coming loose during operation. Fig.1 7-2.
Page 8
7-5. Lead wire Connect the 2 lead wires from the throttle trigger to the corresponding 2 wires from the engine as in Fig.6. Fig.6 Fig.7 7-6. Wearing the double-shoulder harness Pass your arms through the straps as if putting on a coat. Buckle the harness at the front of your body. Set the shoulder pads properly.
For the blade cutting attachment 1. Match the hole in the side of the cutting attachment guard with the hole in the side of the gear housing. 2. Then insert a 4mm Allen wrench into the holes to stop the clamp moving. Fig.11 3.
9. STARTING, OPERATION, STOPPING 9-1 Before starting the engine Check for loose screws and nuts and fill with properly mixed fuel. Place the engine on stable ground with the engine stand (fuel tank) and the guard resting on the ground. 9-2 To start a cold engine Fig.
9-6 When the engine does not start If the engine does not start or flames flow back through the muffler even though you have pulled the starter many times, remove and check the spark plugs. 1. If the spark plugs are dry, no fuel has been fed into the cylinder. Check the fuel pipe and carburetor. 2.
11-2. Lubricating the gear housing with grease The gear housing has a greasing port. Remove the greasing ports screw and feed grease into the port. Grease the port after every 20 hours of operation. Fig. 23 Fig.23 Fig.24 11-3. Checking the gear housing mounting screws Loose gear housing fixing screws are very dangerous even though they have covers to prevent them from coming off.
Page 13
11-9. Storage for engine Drain the fuel tank completely and pull the recoil starter handle several times to remove fuel from the carburetor. Remove the spark plug and pour 7cc (1/4 oz) of fresh, clean, two–stroke engine oil into the cylinder through the spark plug hole. Place a clean cloth over the spark plug hole.
Page 14
12. PARTS DIAGRAMS AND LISTS 12.1 THPK27L – Gear Case Part No. Description Part No. Description TH172-1 Gear Case Assembly Incl. 2-23 TH172-13 TH172-2 Gear Case TH172-14 Circlip S9 TH172-3 Bevel Pinion TH172-15 Circlip R24 TH172-4 Bevel Gear TH172-16 Circlip R28...
We,Importer Handy Distribution SN3 4NS Declare that the product Designation: 27cc BRUSH CUTTER Model: THPK27L Complies with the following directives: 2006/42/EC- Machinery Directive 2004/108/EC- Electromagnetic Compatibility Directive 2000/14/EC amended by 2005/88/EC- Noise Emission in the Environment by Equipment for Use Outdoors Directive.
Page 23
EC Declaration of Conformity We,Importer Handy Distribution SN3 4NS Declare that the product Designation: 35cc BRUSH CUTTER Model: THPK35CH Complies with the following directives: 2006/42/EC- Machinery Directive 2004/108/EC- Electromagnetic Compatibility Directive 2000/14/EC amended by 2005/88/EC- Noise Emission in the Environment by Equipment for Use Outdoors Directive.
Page 24
