- Page 1 TCH1 RNET® Touchpoint Installation Manual...
-
Page 2: Safety Instructions
The apparatus shall not be exposed to dripping damaged; or or splashing liquids and no objects filled with B. Objects have fallen, liquid has been spilled liquids, such as vases, shall be placed on the into the appliance; or apparatus. Russound TCH1 Installation Manual... -
Page 3: Table Of Contents
Installation connections ..................6-7 Configuration ......................8-11 Firmware update ....................12 User interface ......................13 Zone selection and settings ................14 Source selection....................15 Technical specifications ..................16 Warranty ........................17 Agency Approvals - TCH1 Touchpoint Station Russound TCH1 Installation Manual... -
Page 4: Product Overview
The TCH1S • Zone volume control with mute option serves up web pages for display and control of the Russound multiroom system over the WiFi network to an iPhone™ or iPod Touch® whose web •... -
Page 5: Front And Rear Views
IP address back to factory USB - Use supplied adapter to connect default to the controller's RS232 serial port DC - Connect interface power supply and plug into 120VAC outlet TCHS1 rear view (with antenna attached) Russound TCH1 Installation Manual... -
Page 6: Installation Connections
There may be a delay before the LED lights to show a change in state. Controller USB/Serial adapter Serial extender cable TCHS1 Interface Home Network Router CAT-5 cable LAN Ports LAN Port USB Port Recommended configuration (CAT-5 connection between Network Router and TCHS1) Russound TCH1 Installation Manual... - Page 7 CAT-5 Ethernet Cable WiFi Serial cable Antenna TCHS1 Interface USB/Serial adapter TCH1 Power Supply USB Port Home network router Computer Alternate configuration Computer connection for initial setup (If TCHS1 location prevents wired connection to Network Router) Russound TCH1 Installation Manual...
-
Page 8: Configuration
User name: admin, Password: russound. under System Preferences, select Network. To set up the TCH1 from your computer, make sure it is on the 192.168.1.x network. You may have to temporarily change this on your computer to first configure the IP address of the TCHS1 to the required settings of the local area network. - Page 9 IP Address- Enter an unused static address on your network. Netmask - Mask indicates what addresses are included in your LAN. Default Gateway - Enter your home network IP address. Save Changes - must be clicked to save information Russound TCH1 Installation Manual...
- Page 10 Click Save Changes. Wireless Interface - Choose Channel - Choose appropriate "On" to use wireless connectivity to the home router ESSID - Must match home network Save Changes - Must be clicked to implement Russound TCH1 Installation Manual...
- Page 11 No duplicates Save Changes Enter names - No duplicates Source Type Must be clicked to save Save Changes (Not shown) Choose appropriate - information Must be clicked to save information enter "Standard IR" for non-RNET sources Russound TCH1 Installation Manual...
-
Page 12: Firmware Update
The TCHS1 may be field upgraded to provide additional features and functionality. It may also be restored to factory default settings. To update the TCH1 you will need the Firmware Image file from the Russound Document Center, and a PC, MAC, or Linux computer connected to your home network. -
Page 13: User Interface
IR devices and iBridge Russound RNET sources (except Selects previous playlist SMS3 and iBridge) + Selects next playlist |< Plays previous song in playlist |> Plays next song in playlist >|| Pause/Unpause Russound TCH1 Installation Manual... -
Page 14: Zone Selection And Settings
Zone Settings - Touch for the menu to view/change zone audio settings and mode status (Master, Party, DND, and Shared) DND - Change zone or source to Do Not Disturb Party - Turn on, exit or participate in Party Mode Russound TCH1 Installation Manual... -
Page 15: Source Selection
Audio / Mode Option - Touch to control Done - Saves setting and returns Source Name - Touch to to Zone Edit page select Source Previous / Next - Goes to previous or next zone setting Russound TCH1 Installation Manual... -
Page 16: Technical Specifications
Wireless Transmission Speed: 54Mbps Transmission Speed Details: 54Mbps Auto-fallback IEEE 802.11g6Mbps Interfaces/Ports: 4 x RJ45 10/100Base-TX LAN1 x RJ45 10/100Base-TX Connectivity Media: 10/100Base-TX Category 5 Twisted Pair Wired Data Transfer Rate: 100Mbps Fast Ethernet Serial Interface: 19200 Baud Russound TCH1 Installation Manual... -
Page 17: Warranty
WARRANTY Warranty Before returning a unit for repair, call Russound at (603) 659-5170 for a The Russound RNET Touchpoint (TCH1) is fully guaranteed against all Return Authorization number. Write this number on the shipping label defects in materials and workmanship for two (2) years from the date of and ship to: purchase. - Page 18 NOTES Russound TCH1 Installation Manual...
- Page 19 NOTES Russound TCH1 Installation Manual...
- Page 20 All trademarks are the property of their respective owners. tel 603.659.5170 • fax 603.659.5388 iPhone and iPod touch are registered trademarks of Apple, Inc. email: tech@russound.com www.russound.com Specifications are subject to change without notice. Russound is not responsible for typographical errors or omissions. 28-1344 05/01/09...
