Summary of Contents for 3G Audio AK80
- Page 1 AK80 STEREO AMPLIFIER User's manual ED-3G-MA-060724-001...
- Page 2 PRECAUTIONS Thank you for purchasing our products. Please read this manual carefully for your correct operation of this equipment, and keep this manual for future reference. For your safety please don't open the rack to avoid electric shock due to high voltage inside.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Features Signal Cables INTRODUCTION Front Panel Rear Panel Speaker Cable Connection Input Connection INSTALLATION Speaker Cable Connection In Stereo Mode Speaker Cable Connection In Mono Mode Speaker Cable Connection In Bridge Mode OPERATION Safety Instructions ADDITIONAL Technical Specifications DESCRIPTION Accessories... -
Page 4: Introduction
INTRODUCTION Please read this manual carefully before you begin to use this instrument, and keep the manual for future reference. FEATURES Ultra compact design, convenient for use. Completely concealed adjustment button design, effective for status protection. Adopting the amplification circuit targeting high sound quality, excellent in expressing musical details. -
Page 5: Front Panel
FRONT PANEL 1 Bass Adjustment for L/R Channel Turn this knob clockwise( )/anticlockwise( ) when you feel the bass volume is not enough/too much. 2 HF Adjustment for L/R Channel Turn this knob clockwise( )/anticlockwise( ) when you feel the HF volume is not enough/too much. -
Page 6: Rear Panel
REAR PANEL 1 Power Supply Socket and fuss box Power supply: AC220/50Hz, no other option is suitable Fuss: T250V/IA( 5x20mm) Please purchase parts for maintenance according to the above specifications. 2 Signal Input Socket for L Channel 3 Signal Output Socket for L Channel 4 Positive Terminal for L Channel Power Output 5 Positive Terminal for R Channel Power Output... -
Page 7: Speaker Cable Connection
INSTALLATION SPEAKER CABLE CONNECTION 1.Push down the eject button to open the cable clip and insert the cable end in the hole. 2.Let the clip resume its original status, ensure the cable end is tightened. Select suitable speaker cable before connecting. This amplifier can be connected to two clusters of speakers. -
Page 8: Speaker Cable Connection In Stereo Mode
INSTALLATION SPEAKER CABLE CONNECTION IN STEREO MODE The mode switch must be located to "Stereo " . SPEAKER CABLE CONNECTION IN MONO MODE The mode switch must be located to "Mono " . SPEAKER CABLE CONNECTION IN BRIDGE MODE The mode switch must be located to "Bridge" . - Page 9 OPERATION The amplifier is ready for use when you finish connecting it to speakers and plugging in the signal connector following the manual. Here are the instructions for correct operation of the instrument: 1. Switch on the power (4) (see page 5). 2.
-
Page 10: Safety Instructions
ADDITIONAL DESCRIPTION SAFETY INSTRUCTIONS DO NOT OPEN THE COVER Do not open the cover to avoid the risk of electric shock caused by high voltage parts in the product. Any problems caused by user's wrong actions are out of warranty. DO NOT DAMAGE THE POWER CORD Please hold the plug when pull out or plug in the cord. -
Page 11: Technical Specifications
ADDITIONAL DESCRIPTION TECHNICAL SPECIFICATIONS Distortion Limit Output Power: 2x80W (THD+N: 0.5%, with 8 load, in stereo/mono mode) 2x120W (THD+N: 0.5%, with 4 load, in stereo/mono mode) 240W (THD+N: 0.5%, with 8 load, in bridge mode) Frequency Response: 20Hz~20KHz(+/-3dB)with low-cut switch at GENERAL location 100Hz~20KHz(+/-3dB)with low-cut switch at LOWCUT location Load Impedance: (in mono/stereo mode), 4... - Page 12 STEREO AMPLIFIER www.elderaudio.com...
