oven dimensions
A
Flush fit
600
Proud fit
565
Cupboard door
C = from face of cabinet/door to rear of enclosure.
Cabinet construction for your appliance
For the best integration within a kitchen, install this appliance in a standard 600mm wide cupboard that gives a
flush fit with the surrounding cupboard fronts. A recess of 20mm is ideal.
It can also be installed using a proud fit with the surrounding cupboard.
Flush fit (top view)
Infill panel recessed 20mm
from external cabinet/door
to accommodate for a flush fit
All measurements in millimetres.
Current as at Dec 2006.
© 2006 Electrolux Home Products Pty Ltd. CDIMEXCOVENS
electric wall ovens with separate grill
A
C
9mm clearance required
min. 650mm
B
C
893
581 min
20mm
885
560 min
595mm
9mm clearance required
20mm
Cupboard door
595mm
installation guide
models: EXC614 (S/W), EXC624 (S/W)
561mm
B
881mm
Cupboard door
Proud fit (top view)
Cupboard door
Cupboard door
546mm
20mm
mounting
holes
888mm
565mm
595mm
Cupboard door
565mm
Cupboard door
Cupb
