- Page 1 MONITOR WITH DVD RECEIVER KVT-526DVD KVT-556DVD INSTALLATION MANUAL © B54-4749-00/00 (EW/QW)
- Page 2 (i.e., it will not turn on and off along with the ignition). If you want to link the unit’s power with the ignition, connect the ignition wire to a power source that can be turned on and off with the ignition key. KVT-526DVD/KVT-556DVD...
-
Page 3: Connecting Wires To Terminals
Connecting Wires to Terminals Connector Function Guide 2WARNING Pin Numbers for Cable Colour Functions Connecting the ISO Connector ISO Connectors The pin arrangement for the ISO connectors depends on External Power the type of vehicle you drive. Make sure to make the proper Connector connections to prevent damage to the unit. - Page 4 When this terminal is not in use, leave its cap on. Mute wire (Brown) Connect to the terminal that is grounded when either the telephone rings or during conversation. To connect the Kenwood navigation system, consult your navigation manual. Power control/ Motor antenna control wire (Blue/White) Connect either to the power control terminal when using the optional power amplifier, or to the antenna control terminal in the vehicle.
- Page 5 Cooling fan Antenna Cord FM/AM antenna input (JASO) Wiring harness (Accessory 1) Wiring harness (Accessory 2) Audio/Visual input / Rear View Camera Input • Visual input (Yellow) AV IN • Audio left input (White) • Audio right input (Red) REAR VIEW CAMERA Audio/Visual Output •...
-
Page 6: Optional Accessory Connection
(Included in the Navigation System) (Optional Accessory) Navigation System (Optional Accessory) Connection cable (Included in the TV tuner) ⁄ Navigation units that can be connected to this unit. (As of December, 2009): KNA-G620T For latest information, access the www.kenwood.com/cs/ce/. KVT-526DVD/KVT-556DVD... -
Page 7: Installation/Removing The Unit
Installation/Removing the Unit Installation Bend the tabs of the mounting sleeve with a screwdriver or similar utensil and attach it in place. Make sure that the unit is installed securely in place. If the unit is unstable, it may malfunction (eg, the sound may skip). English... -
Page 8: Removing The Unit
2. When the lower level is removed, remove the upper two locations. ⁄ • Be careful to avoid injury from the catch pins on the removal tool. 4. Pull the unit all the way out with your hands, being careful not to drop it. KVT-526DVD/KVT-556DVD...
