SERVICE SECTION II

4. The user memory values can only be changed through the Remote Programmer by

first modifying the temporary memory values and then by saving them in the user

memory where they become the user program. The Remote Programmer is acti-

vated by pressing the POWER key when the chair is in neutral. The chair cannot be

driven when the LCD display is illuminated. The display will turn itself OFF after 45

seconds. It can also be turned OFF by pressing the POWER key. The following is a

description of the operation of each of the keys:

POWER Key

The POWER key turns on and off the LCD display. Press the

POWER key once and the display will come ON. Press the POWER

key again and the display will turn OFF.

MENU Key

The MENU key returns the LCD display to the previous screen. If a

function is being adjusted, pressing the MENU key returns the display

to the Performance Menu. Pressing the key again will cause the

display to change to the Main Menu.

and

Keys

These keys are used to move the selection arrow on the LCD up

and down or adjust a value up or down. An adjusted value is not

saved unless the SAVE key is pressed.

SELECT Key

The SELECT key chooses the item to which the selection arrow on

the LCD is pointing and displays the appropriate next screen.

SAVE Key

The SAVE key causes the Save screen to appear or causes the values

that have been modified in temporary memory to be permanently

stored in the driving program specified by the selection arrow.
