User Manual
OWNER S MANUAL
REMOTE CONTROLLER
KSIN Series
. .
Please read this Owner's Manual carefully before operation.
Save this manual in a safe place for future reference.
Advertisement
Related Manuals for Klimaire KSIN Series
Summary of Contents for Klimaire KSIN Series
-
Page 1: Remote Controller
OWNER S MANUAL REMOTE CONTROLLER KSIN Series Please read this Owner's Manual carefully before operation. Save this manual in a safe place for future reference. -
Page 2: Remote Controller Specification
Remote Controller Specification RG51M5/(C)EU Model Rated Voltage 3.0V(Dry batteries LR03 2) × Lowest Voltage of CPU 2.0V Emitting Signal Transmission Distance Environment 2 3 F~14 0 F Performance Features 、 、 、 1. Operating Mode: AUTO COOL HEAT(Cooling only model without) and FAN . 2. - Page 3 CONTENTS Remote Controller Specification..........Performance Features------------------------------------------------------- Features of the Remote controller Buttons ......Indicators on Display panel............Operating the Remote Controller..........Warning--------------------------------------------------------------------------...
- Page 4 TEMP Button : Push this button to decrease the indoor temperature setting. TEMP Button : Push this button to increase the indoor temperature setting . MODE Selection Button: Each time the button is pressed, the operation mode is shifted in the direction of the arrow: AUTO COOL HEAT...
- Page 5 TIMER OFF Button: Press this button to initiate the auto-off time sequence. Each press will increase the auto-timed setting in 30 minutes increments. When the setting time displays 10h, each press will increase the auto-timed setting 60 minutes increments. To cancel the auto-timed program, simply adjust the auto-off time to 0.0 LOCK Button: When you press the recessed LOCK button, all current settings are locked in and the remote controller does not...
- Page 6 ON/OFF Indicator: This symbol appears when the unit is turned on by the remote controller, and disappear when the unit is turned off. OPERATION MODE Indicator: When press the MODE button, " ", " "," ", it shows the current operating mode -- AUTO COOL "...
- Page 7 AUTOMATIC OPERATION Switch on the power and the OPERATION indication lamp on the display panel of the indoor unit starts flashing, and turns off after flashes for 6 times. 1. Use the MODE button to select AUTO. 2. Push the TEMP button to set the desired temperature within a range of 62 F ~ 86 F.
- Page 8 DRY Operation 1. Push the MODE button to select DRY. 2. Push the TEMP button to set the desired temperature within a range of 62 F ~ 86 F. 3. Push the ON/OFF button, the OPERATION lamp lights and the air conditioner starts to operate in DRY mode at LOW fan speed.
- Page 9 3. Set the starting & stopping time 3.1 Push the TIMER ON button, the remote controller will show TIMER ON, the last set time for START operation and the signal "h" will be shown on the DIGITAL display area. You are now ready to readjust the TIMER ON to start the operation.
- Page 10 The design an d spe cificat ions are sub ject to chang e with out prior notice for prod uct improvement. Consult with the sales agency or ma nufact urer for details.
