CAUTION: DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
WARNING
If the information in these instructions
is not followed exactly, a fire or explo-
sion may result causing property dam-
age, personal injury or death.
WARNING
1. Do not store or use gasoline or other
flammable liquids or vapors in the vi-
cinity of this or any other appliance.
2. An LP cylinder not connected for
use shall not be stored in the vicin-
ity of this or any other appliance.
DANGER
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open lid.
4.
If odor continues keep away from the
appliance and immediately call your gas
supplier or your fire department.
The Outdoor GreatRoom Company • Cook Number Grill CNG-TRAVELER Gas Grill • Rev. A
OWNER'S MANUAL
•
Assembly
•
Operation
•
Maintenance
NOTICE TO INSTALLER AND CONSUMER
• These instructions must be left with the
consumer and the consumer should
retain them for future reference.
Read the following instructions care-
fully and be sure your grill is properly in-
stalled, assembled and maintained.
Failure to follow these instructions may
result in serious bodily injury and/or
property damage. If you have questions
concerning assembly or operation, con-
sult your dealer, gas appliance service
person or your LP gas company.
This outdoor cooking gas appliance is
not intended to be installed in or on recre-
ational vehicles and/or boats.
Installation and service must be performed
by a qualified installer, service agency, or
the gas supplier. In the Commonwealth of
Massachusetts installation must be per-
formed by a licensed plumber or gas fitter.
1
Cook Number Grill
CNG-TRAVELER Gas GRill
™
GAS-FIRED
LISTED
780-920A 5/08
Advertisement
Table of Contents
Related Manuals for Outdoor GreatRoom Company Cook Number Grill
Summary of Contents for Outdoor GreatRoom Company Cook Number Grill
- Page 1 Cook Number Grill ™ CNG-TRAVELER Gas GRill OWNER’S MANUAL • Assembly GAS-FIRED • Operation • Maintenance LISTED CAUTION: DO NOT DISCARD THIS MANUAL NOTICE TO INSTALLER AND CONSUMER • Read, understand and follow • These instructions must be left with the these instructions for safe consumer and the consumer should installation and operation. retain them for future reference. Read the following instructions care-...
-
