Page 1: Wireless Lan
IBM High Rate Wireless LAN Mini-PCI Adapter User’s Guide... - Page 2 IBM may make improvements or changes in the products or the programs described in this publication at any time. It is possible that this publication may contain reference to, or information about, IBM products (machines and programs), programming, or services that are not announced in your country.
-
Page 3: Safety: Read First
Vor der Installation dieses Produkts die Sicherheitshinweise lesen. Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza. Lees voordat u dit product installeert eerst de veiligheidsvoorschriften. Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet. © Copyright IBM Corp. 2002... - Page 4 Antes de instalar este produto, leia as Informações sobre Segurança. Pred inštaláciou tohto zariadenia si pečítaje Bezpečnostné predpisy. Antes de instalar este producto lea la información de seguridad. Läs säkerhetsinformationen innan du installerar den här produkten. IBM High Rate Wireless LAN Mini-PCI Adapter: User’s Guide...
-
Page 5: Table Of Contents
About the IBM High Rate Wireless LAN Mini-PCI Adapter . Product registration . Product description Installing the Mini-PCI Card Installing the device driver © Copyright IBM Corp. 2002 . iii . 1-1 . 1-1 . 1-1 . 1-2 . 1-10... - Page 6 IBM High Rate Wireless LAN Mini-PCI Adapter: User’s Guide...
-
Page 7: About The Ibm High Rate Wireless Lan Mini-Pci Adapter
Your feedback is valuable to us in developing products and services that are important to you, as well as in developing better ways to communicate with you. Register your option on the IBM Web site at: www.ibm.com/pc/register... -
Page 8: Installing The Mini-Pci Card
Installing the Mini-PCI Card Note: Use only the Mini-PCI Card provided by IBM. If your computer is a wireless upgradable model, and you are installing the Mini-PCI Card for the first time, follow the procedure below. For ThinkPad R32 Series computer If you are using ThinkPad R32 Series computer, do as follows: 1. - Page 9 Card. 6. Align the contact edge of the Mini-PCI Card with the corresponding socket contact of the computer 1 . Connect the cables to the new Mini-PCI Card 2 . ® About the IBM High Rate Wireless LAN Mini-PCI Adapter...
- Page 10 1. Turn off the computer. Then disconnect the ac adapter and all cables from the computer. 2. Remove the battery and the keyboard. (For information on removing the battery and the keyboard, refer to the ThinkPad X30 Series Service and Troubleshooting Guide.) IBM High Rate Wireless LAN Mini-PCI Adapter: User’s Guide...
- Page 11 4. Connect the cables to the new Mini-PCI Card. Note: Plug the gray cable with the tab marked MAIN into jack J1, and the black cable with the tab marked AUX into jack J2. ® About the IBM High Rate Wireless LAN Mini-PCI Adapter...
- Page 12 When attaching the Card, route the antenna cables to go under the cable guide as in a , and place the tabs as indicated by arrow b as in this figure. IBM High Rate Wireless LAN Mini-PCI Adapter: User’s Guide...
- Page 13 2. Close the computer display, and turn the computer over. 3. Remove the battery. (For information on removing the battery, refer to the ThinkPad T30 Series Service and Troubleshooting Guide.) ® About the IBM High Rate Wireless LAN Mini-PCI Adapter...
- Page 14 Note: If a Mini-PCI Card has been installed in your computer, and you remove the Card and do not install a new one, put the cables in the cable holder after disconnecting them from the Card. IBM High Rate Wireless LAN Mini-PCI Adapter: User’s Guide...
- Page 15 7. Pivot the card until you can snap it into place by pressing the upper side of the connectors as shown. Make sure that the card is firmly fixed in the slot and does not move easily. ® About the IBM High Rate Wireless LAN Mini-PCI Adapter...
-
Page 16: Installing The Device Driver
CD, or refer to the following instructions. The device driver files are in the following directory: C:\DRIVERS\WIN\WLLANINT Note: On some computers, the device driver files are in the following directory instead: C:\IBMTOOLS\DRIVERS\WLLANINT 1-10 IBM High Rate Wireless LAN Mini-PCI Adapter: User’s Guide... - Page 17 C:\i386, or, on the Windows NT CD-ROM, X:\i386.) 17. Follow the instructions on the screen. 18. When the installation is complete, click the Finish button. ® Windows ® ® About the IBM High Rate Wireless LAN Mini-PCI Adapter ® 98, Windows Me, 1-11...
- Page 18 25. Select High Rate Wireless LAN Mini-PCI Adapter with Modem II. 26. Click the OK button. 27. Click the Close button. 28. Follow the instructions on the screen. 29. When asked whether you want to restart the system, click Yes. 1-12 IBM High Rate Wireless LAN Mini-PCI Adapter: User’s Guide...
- Page 20 Part Number: 22P7713 Printed in U.S.A. (1P) P/N: 22P7713...
