C2-7000 Series
Dual Channel
Video Processor
Operation Manual
Version 1.5
C2-7100 & C2-7200 Dual Channel
Video Processor Operation Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C2-7000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TV One C2-7000 Series

  • Page 1 C2-7000 S ERIES PERATION ANUAL C2-7000 Series Dual Channel Video Processor Operation Manual Version 1.5 C2-7100 & C2-7200 Dual Channel Video Processor Operation Manual...
  • Page 2 C2-7000 S ERIES PERATION ANUAL C2-7000 Series Dual Channel Video Processor Operation Manual Version 1.5...
  • Page 3: Table Of Contents

    C2-7000 S ERIES PERATION ANUAL Table of Contents DISCLAIMER..................... 1 Regulatory Agency Acceptance................1 FCC Statement....................1 IMPORTANT SAFETY INSTRUCTIONS...........3 CAPABILITY, TERMS OF REFERENCE AND OVERVIEW SUMMARY 13 Device Capabilities .................... 13 Terms of Reference................... 14 Device Overview....................15 Models available....................
  • Page 4 C2-7000 S ERIES PERATION ANUAL MENU TOPOGRAPHY AND ADJUSTMENT METHODOLOGY ..... 35 The High Level Menu Structure ................. 36 Group Names and Descriptions................. 37 Items Associated with the Device mode group........... 37 Items Associated with the Adjust outputs group..........37 Items Associated with the Adjust windows group..........
  • Page 5 C2-7000 S ERIES PERATION ANUAL 12.2 Edge-blending requirements................82 12.3 Basic setup of the two projectors ............... 83 12.4 Connections to the scaler(s) and projectors............83 12.5 Initial setup ......................84 12.6 Edge-blending activation..................85 12.7 Edge-blending overlap / size................85 12.8 Edge-blending guide lines..................
  • Page 6 C2-7000 S ERIES PERATION ANUAL 14.9 The picture on the video display is black and white.......... 105 14.10 The picture on the video display is green............105 14.11 The RGB input is selected but the image is rolling or pink....... 106 14.12 The video signal from my DVD player does not appear to work.
  • Page 7: Disclaimer

    C2-7000 S ERIES PERATION ANUAL 1.0 DISCLAIMER This product is intended for professional and/or home use. This product is not intended for use in a medical environment and does not have the required certifications for such use. Similarly, use aboard any aircraft or spacecraft while in flight or as an adjunct to any surface, airborne or marine navigation system or any offshore marine activity, including control of any watercraft, or any use similar to those specifically herein mentioned is prohibited.
  • Page 8 Caution: This equipment is intended for use in the manner prescribed in the Instruction Manual. Any user changes or modifications not expressly approved by TV One Multimedia Solutions could void the user’s authority to operate the equipment. Connecting this equipment to external devices requires no specially shielded cabling for FCC compliance.
  • Page 9: Important Safety Instructions

    C2-7000 S ERIES PERATION ANUAL 2.0 IMPORTANT SAFETY INSTRUCTIONS To insure the best from this product, please read this manual carefully. Keep it in a safe place for future reference. To reduce the risk of electric shock, do not remove the cover from the unit. No user serviceable parts inside.
  • Page 10 C2-7000 S ERIES PERATION ANUAL 2.5 Ventilation Slots and openings in the sides of the unit are provided for ventilation. To ensure reliable operation, avoid obstruction of these openings and ensure the unit is installed in a well-ventilated area. 2.6 Intellectual property Some IC chips in this product include confidential and/or trade secret property.
  • Page 11 C2-7000 S ERIES PERATION ANUAL 2.0 IMPORTANT: CONSIGNES DE SECURITE Afin de tirer le meilleur de ce produit, merci de lire attentivement ce manuel. Gardez-le dans un endroit sûr pour pouvoir le consulter à nouveau. Afin de réduire le risque de choc électrique, ne retirez pas l’unité de sa protection.
  • Page 12 C2-7000 S ERIES PERATION ANUAL 2.3 Entretien général Ne forcez pas les boutons ou connexions externes. Lorsque vous déplacez l’unité, déconnectez d’abord les connexions de ports en série puis le câble d’alimentation et enfin les câbles de connexion avec d’autres appareils. N’essayez pas de nettoyer l’unité...
  • Page 13 C2-7000 S ERIES PERATION ANUAL 2.0 INSTRUCCIONES IMPORTANTES DE SEGURIDAD Para sacar el mejor provecho de este producto, léase este manual con detenimiento. Guárdelo en un lugar seguro para poder hacerle referencia en el futuro. Para reducir el riesgo de calambre, no quite la cubierta del aparato. No hay piezas utilizables dentro.
  • Page 14 C2-7000 S ERIES PERATION ANUAL 2.3 Cuidado general No forzar interruptores o conexiones externas. Al mover el aparato, desconecte las conexiones del puerto en serie primero, luego el cable de electricidad y finalmente los cables interconectados a otros aparatos. No intente limpiar el aparato con disolventes químicos o productos de limpieza aerosol, ya que podrían dañar el aparato.
  • Page 15 C2-7000 S ERIES PERATION ANUAL 2.0 WICHTIGE SICHERHEITSVORSCHRIFTEN Lesen Sie diese Bedienungsanleitung bitte sorgfältig, um Ihr Produkt optimal nützen zu können, und bewahren Sie sie zum späteren Nachschlagen an einem sicheren Ort auf. Entfernen Sie bitte keinesfalls die Abdeckung, um der Gefahr eines Stromschlags vorzubeugen.
  • Page 16 C2-7000 S ERIES PERATION ANUAL 2.3 Allgemeine pflege Wenden Sie bei der Handhabung von Schaltern und Anschlüssen keine Gewalt an. Beim Umstellen des Geräts entfernen Sie zuerst die seriellen Anschlüsse, dann das Stromkabel und zum Schluss die Verbindungskabel zu anderen Geräten.
  • Page 17 C2-7000 S ERIES PERATION ANUAL 2.0 BELANGRIJKE VEILIGHEIDSINSTRUCTIES Lees deze handleiding zorgvuldig door om het beste uit uw product te halen. Bewaar het op een veilige plek voor raadpleging in de toekomst. Haal nooit het omhulsel van de eenheid af, dit om de kans op een elektrische schok te verminderen.
  • Page 18 C2-7000 S ERIES PERATION ANUAL 2.3 Algemeen onderhoud Forceer schakelaars of externe aansluitingen nooit. Bij verplaatsing van de eenheid, de seriële poortaansluitingen eerst loskoppelen, dan de voedingskabel en als laatste de snoeren naar andere apparaten. Probeer de eenheid nooit met chemische oplosmiddelen of schoonmaakmiddelen in een spuitbus schoon te maken, omdat dit de eenheid kan beschadigen.
  • Page 19: Capability, Terms Of Reference And Overview Summary

    In addition, the C2-7200 range also supports SDI and HD-SDI. Throughout this manual, any feature or function relating present on all C2- 7000 units will be referred to by ‘C2-7000 series’. Any unit-specific functions or features will be mentioned by specific product name.
  • Page 20: Terms Of Reference

    CORIO® Console allows a user to control the unit from hardware, mimicking a classic video switcher device. Terms of Reference In order to operate the C2-7000 series, agreement on terminology is required. To avoid confusion as you read through this manual, here are the terms of reference used throughout.
  • Page 21: Device Overview

    Device Overview The C2-7000 series provides a means for the user to select sources from the inputs and present them to the two outputs in various ways. The imagery on the outputs is comprised of the video layers of live (moving) video plus static video sources such as internally stored logos and testcards.
  • Page 22: Models Available

    PERATION ANUAL Models available There are different models in the C2-7000 series – either incorporating a number of SDI inputs / output or not, or using a 10-way programmable button panel or 48-key non-programmable front panel. The following pictures detail the differences between the units: C2-7100 &...
  • Page 23: Input Sources

    Within the nomenclature that follows, the Windows will be associated with one or both of the two Outputs as explained in the section detailing Modes of Operation. Windows are an integral part of the C2-7000 series and play a central part in understanding how to operate the device.
  • Page 24: Layers

    6 layer. The image layers are given designators for the purposes of identification when operating the C2-7000 series. The designators are case sensitive. The letters and their meanings are as follows: Window Description Logo “a”...
  • Page 25: Modes

    Should layer “A” be made fully transparent, then it would seem to disappear completely. The powerful Keyer function of the C2-7000 series takes advantage of this feature to superimpose portions of one window over another. Portions of a layer are made semi-transparent or invisible.
  • Page 26: Independent Mode

    C2-7000 S ERIES PERATION ANUAL 7000 series allows the movement of the image from Output 2 to Output 1 to be either instantaneous or the new Output 1 image can gradually replace the previous image on Output 1 via a cross fade or a wipe. The time available for the cross-fade or wipe can be up to 5 seconds, controlled in .1-second increments.
  • Page 27 C2-7000 S ERIES PERATION ANUAL From a practical standpoint, this means that there is only one lock source available and both outputs will contain the same lock source imagery. The Keyers can adjust the components of each Window independently so as to make a portion of the underlying Window pierce the overlaying Window and the logos can be used as desired in the Output imagery.
  • Page 28: Unpacking And Installation

    1 Rack-mount Kit, 2 Ears and 8 Screws 1 DVI-A to 5 BNC If any items are missing or defective, contact your supplier. If you are unable to resolve the problem with your supplier, contact TV One via the web at http://www.tvone.com/support for prompt replacement.
  • Page 29: Functional Check

    If you did not receive the correct cable, DO NOT attempt to modify the incorrect cable. Instead, immediately contact your dealer or contact TV One at the sales office nearest to your geographic location and request the proper cable.
  • Page 30: Factory Reset

    Firmware update is the only way to perform a complete factory reset Initial Operation Check Using Factory Default Settings The C2-7000 series can be operated via the Front Panel Buttons, an LCD display and a Rotary Encoder or multi-directional switch (depending on your front panel version), via a Windows based utility or via a dedicated CORIO®...
  • Page 31 Next, take the cable from the PC monitor (using another of the supplied DVI to HD15 adapter) and connect it to the C2-7000 series’ DVI-I/RGB1 output. Then connect the AC Power Cable to a working AC outlet, turn on the PC, monitor and then the C2-7000 series.
  • Page 32: Controls And Connections

    ERIES PERATION ANUAL 6.0 CONTROLS AND CONNECTIONS The C2-7000 series comes with one of two types of front panel: CORIO® STD – 10 button programmable. CORIO® EXP – 48 button non-programmable. 10-button programmable panel Front panel buttons 1 through 10, plus the Shift button, govern what inputs are applied to the C2-7000 series’...
  • Page 33 C2-7000 S ERIES PERATION ANUAL Button C2-7100 C2-7200 Number default default RGB1 RGB1 RGB2 RGB2 RGB3 SDI1 SDI2 All buttons except the Shift button and Power Button can be reassigned; however, buttons “1” and “2” should not be changed since such a change will make operation of the unit via the Rotary Encoder Control more difficult.
  • Page 34: 48-Button Non-Programmable Panel

    C2-7000 S ERIES PERATION ANUAL 48-button non-programmable panel All 48-key front panels have the same button arrangement on the left and right sides of the front panel, with the main input selection buttons differing between units as shown below: C2-7110: C2-7210: C2-7260:...
  • Page 35 ANUAL With these front panels, you can directly select the inputs to route to the two outputs of the C2-7000 series unit. Depending on the Mode you’re in (Switcher, Independent and Dual PIP), the input selection button will have different effects:...
  • Page 36: Inputs And Outputs

    Z, the Lock source. Not all selections are valid – this depends on the operational mode. Inputs and Outputs The C2-7000 series has three DVI-I inputs (which can be used for DVI-D, RGBHV, RGsB, RGBS, YUV or YPbPr sources) three Composite video inputs and three YC (S-Video) inputs.
  • Page 37: Changing The Operating Mode

    Factory Reset has been performed. Operating the Unit as a Video Switcher When the C2-7000 series is initially turned on the first time (and after any Factory Reset), it will be in the Switcher mode. If a mode change is made to...
  • Page 38: Switching An Input

    Factory Default condition. At this time, perform the Factory Reset as explained in section 5.2 above. After the system resets, the initial screen will be as follows: CORIO2 C2-7100 TV One Move to the next menu item and change it until it appears as follows: Device Mode Mode Switcher] Note: There is no Preview available in the Independent mode.
  • Page 39: Operating The Unit In Picture In Picture Mode (Dual Pip)

    Factory Reset as explained in section 5.2 above. After the system resets, the initial screen will once again be as follows: CORIO2 C2-7100 TV One Change the Mode to Dual PIP as shown below: Device mode Mode Dual PIP] 7.3.1 Selecting Inputs for the Individual Windows...
  • Page 40 Window “B”. Changing Window A’s size, or simply pressing PIP on the 48 key panel, will then let you see Window B behind Window A. Later we’ll be exploring the menu structure used in the C2-7000 series. It’s within the various yet-to-be explained menus elements that we’ll gain access to all the...
  • Page 41: Menu Topography And Adjustment Methodology

    You’ll be using the Front Panel controls and the Integrated LCD Display to control the C2-7000 series. You’ll turn the rotary encoder (10 key panel) or move the multi-directional switch left or right (48 key panel) and the LCD display will show you where you are in the menu.
  • Page 42: The High Level Menu Structure

    Buttons and LCD display. With these explanations and cautions in mind, let’s look at the C2-7000 series menu. The High Level Menu Structure...
  • Page 43: Group Names And Descriptions

    C2-7000 S ERIES PERATION ANUAL Group Names and Descriptions Menu Group Name Group Description Device mode Allows selection of switcher, independent and pip mode Adjust outputs Controls output parameters Adjust windows Controls characteristics of the pip windows Adjust keyers Controls the luminance keyer and chroma keyer Adjust sources Controls signal input parameters Adjust logos...
  • Page 44 C2-7000 S ERIES PERATION ANUAL Genlock The output video will be “Genlocked” to the selected lock source. The output signal will be synchronous to the input sync and adjustable but there will still be no lock source visible. Lock & Mix The output video will be locked to the selected source, the syncs will be locked (but with an additional internal video processing delay) and the background for the output will be...
  • Page 45: Items Associated With The Adjust Windows Group

    C2-7000 S ERIES PERATION ANUAL and needs to follow a Lock source’s input – hence it should be turned Off it the CV/YC outputs are going to be used. Adjust outputs Out std [NTSC / PAL] This menu item is only available when the Output resolution is set to PAL or NTSC.
  • Page 46 C2-7000 S ERIES PERATION ANUAL When parameter ‘Aspect Adjust’ later in this sub-menu is set to ‘Advanced’, this display is made accessible. It allows the independent setting of the horizontal and vertical zoom values. The third number (1.333 in the example) is the Aspect Ratio resulting from the adjustments, which is automatically calculated for you based on the incoming resolution and the H &...
  • Page 47 C2-7000 S ERIES PERATION ANUAL Adjust windows Shrink H/V % [100] [100] 1.333 When parameter ‘Aspect Adjust’ in the System Menu structure is set to ‘Advanced’, this display is made accessible. It allows the setting of different Horizontal and Vertical ‘shrink’ sizes. The third number (1.333 in the example) is the Aspect Ratio resulting from the adjustments, which is automatically calculated for you based on the output resolution (the actual pixels &...
  • Page 48 C2-7000 S ERIES PERATION ANUAL Med. Enough for most situations such as thin line drawings High Highest amount of flicker reduction. Will cause loss of vertical detail in some images. Adjust windows Image smoothing [Auto] Image smoothing reduces the jagged-edges sometimes seen within an output image by softening it.
  • Page 49: Items Associated With The Adjust Keyers Group

    C2-7000 S ERIES PERATION ANUAL ‘abABZ’ will change to allow visualization of the layer stack. Note that layer 6 the Background Color is not shown as its layer position can not be altered – it will always be the background. Items Associated with the Adjust keyers group Please note that not all units have this sub-menu –...
  • Page 50: Edge Blend Items Within The Adjust Keyers Group

    C2-7000 S ERIES PERATION ANUAL (XGA is 1024x768) You will see that the Swap between foreground and background has no effect on the output resolution as this is always set by the Lock source. Adjust keyers Y Key min/max [ 0] [ 32] The Min/Max parameters are used to select what range of Y (luminance/grey- scale) values are made transparent within the selected window/lock source.
  • Page 51 C2-7000 S ERIES PERATION ANUAL Adjust keyers Edge blend [None] This menu item controls which of the 4 edges are blending into the background. In general, only the left or right are blending, but the unit allows you to control the edge blending for any number of edges. If any edges are set (e.g.
  • Page 52: Items Associated With The Adjust Logos Group

    C2-7000 S ERIES PERATION ANUAL Items Associated with the Adjust logos group Logos are like miniature Testcards, for ‘labeling’ of a video channel. Logos are loaded into the unit via the Windows based control utility and once in the device they can be called up for insertion as required. Horizontal and Vertical Position plus Fade Level are all controlled using this menu group.
  • Page 53: Items Associated With The Adjust Borders Group

    C2-7000 S ERIES PERATION ANUAL Items Associated with the Adjust borders group The adjust borders menu allows the border function of your unit to be enabled – with one border being available for each Window, Logo and Lock source. Note that the layer priority of the Border is the same as the Window source that it is ‘attached’...
  • Page 54: Items Associated With The Adjust Sources Group

    C2-7000 S ERIES PERATION ANUAL 8.10 Items Associated with the Adjust sources group The ‘Adjust Sources’ menu group accesses the parameters associated with the processing amplifiers used for each input (RGB, CV, YC, etc.). They allow you to fine-tune an incoming signal to optimize its color, brightness or even sharpness.
  • Page 55 C2-7000 S ERIES PERATION ANUAL Source: RGB1 BR size adj. 0] [ 0] This menu item allows manual positioning of the Bottom and Right portion of the image. These settings are often used to correct the position of a PC signal on an input, or to eliminate any undesired noise at the top or bottom of a PAL or NTSC video source.
  • Page 56 C2-7000 S ERIES PERATION ANUAL Source: RGB1 RGB input type [RGBHV] There are several types of signals that are called RGB signals as a generic term. Each has slightly different characteristics that set it apart from similar RGB signals – such as how the synchronization signal is sent. This menu item lets you set the input type to use.
  • Page 57: Cv & Yc Source Menu Items

    C2-7000 S ERIES PERATION ANUAL 8.10.2 CV & YC Source Menu Items Of the above Source Menu items, the Autoset sense and Autoset status functions, RGB type and Pixel phase are specific to RGB signals only. The rest of the Source menu items function with RGB, CV or YC type signals. In addition, there are four additional Menu items that are only used with CV or YC type signals and these are explained below: Source: YC1...
  • Page 58: Items Associated With The Adjust Transitions Group

    C2-7000 S ERIES PERATION ANUAL Used to select the Testcard from memory to use as a source for the Testcard currently selected. The Windows Control Panel can be used to upload user- defined Testcards. 8.11 Items associated with the Adjust transitions group Please note that not all units have this sub-menu –...
  • Page 59: Items Associated With The Adjust Buttons Group

    C2-7000 S ERIES PERATION ANUAL 8.12 Items Associated with the Adjust buttons group This menu group is only available for units with programmable front panel buttons. The Adjust Buttons sub menu allows the reassignment of the factory default button associations. For instance, if you do not want button 3 to be associated with RGB input number 1, you can redirect the button to another input or feature.
  • Page 60: Items Associated With The Adjust Resolutions Group

    C2-7000 S ERIES PERATION ANUAL automatically default to Ethernet and control via RS-232 is disabled whilst that connection is maintained. Adjust ethernet IP add. [ 10] 1 Enter 4 numbers one by one to form the IP address you wish to assign to the unit.
  • Page 61 C2-7000 S ERIES PERATION ANUAL Menus”. Turn the function ‘On”, exit the Systems menu and return to this menu structure. The Resolution Database is used by your unit to identify any incoming video signal and is also used to create an output resolution. It is therefore a very important part of the unit’s infrastructure.
  • Page 62 C2-7000 S ERIES PERATION ANUAL The H freq.crse (Horizontal Sync Frequency - Course) adjustment provides the option for changing the Horizontal Sync timing Frequency in 100 Hz steps. 800 x 600 60 Hz H.freq.fine [37.879] kHz Fine Frequency Adjust The H.freq.fine (Horizontal Sync Frequency) adjustment provides the option for changing the Horizontal Sync timing Frequency in 1 Hz steps.
  • Page 63: Items Associated With The System Group

    C2-7000 S ERIES PERATION ANUAL starts on the left side of the monitor without changing the width of the sync pulse itself (another way to control where the image area starts). The two parameters control where the back porch is positioned and they interact to a degree.
  • Page 64 C2-7000 S ERIES PERATION ANUAL System SW: 16, PT: 12, This screen is an informational screen. Should you require technical assistance with your unit, the technical support personnel may request that you read the contents of this screen to them during the support call. The first section, “SW”, is the version of the software that is installed on your unit.
  • Page 65 C2-7000 S ERIES PERATION ANUAL System OSD on power up [On] This parameter controls whether the ‘welcome’ screen is displayed or not on power up for units with an on-screen display – it can be disabled as required. This is useful when a unit is installed as part of an overall system. System Advanced Menus [Off]...
  • Page 66 C2-7000 S ERIES PERATION ANUAL If your units supports Logos or Testcards then this screen will display how many are present in the memory of the units. System Power cycles Power Cycles refers to how many times the unit has been powered since it left the factory.
  • Page 67: Rs232 Port

    C2-7000 S ERIES PERATION ANUAL RS232 PORT Connection Your unit is fitted with a standard ‘D9’ socket allowing it to be controlled from a computer or other type of terminal or console with a similar interface. Most computers fitted with an RS232 port, known as a ‘COM’ port, will have a ‘D9’ plug on them.
  • Page 68: Rs232 / Ip Control Specification

    C2-7000 S ERIES PERATION ANUAL 10.0 RS232 / IP CONTROL SPECIFICATION PLEASE NOTE: Not all units support RS232 and/or IP (Ethernet) communications – check earlier in the manual to see if this feature is present on your unit. This section outlines how to control a unit via an RS232 or Ethernet link (if fitted to your unit), using ASCII-based commands.
  • Page 69: Packet Format

    C2-7000 S ERIES PERATION ANUAL unit will be a 20 byte message with the Write flag (since it is ‘writing’ the value back to the host) and the ACK flag set. The ACK flag will be returned as 0 if the command is invalid for some reason –...
  • Page 70 C2-7000 S ERIES PERATION ANUAL always Writes. Bit 6 = ACK bit. Should be set to 0 for messages to the unit. ACK=1 returned means message was okay. ACK=0 returned means an error was present in the message. Bit 5 = 0 Reserved for future use. Bit 4 = 0 Reserved for future use.
  • Page 71: Function List

    C2-7000 S ERIES PERATION ANUAL 'FFFFF0' is -16 in decimal. ASCII-hex byte that is the (check) sum of all previous bytes (excluding the SOP 'F' character). E.g. The command F0400410082000001C8 has the checksum of 04+00+41+00+82+00+00+01=C8, so the complete command to send is F0400410082000001C8.
  • Page 72 C2-7000 S ERIES PERATION ANUAL Adjust outputs Lock source (connector) 0x10 = RGB1, 0x11 = RGB2, 0x12 = RGB3 0x30 = CV1, 0x31 = CV2, 0x32 = CV3 0x40 = YC1, 0x41 = YC2, 0x42 = YC3 0x50 = SDI1, 0x51 = SDI2 0xD0 = OUT1, 0xD1 = OUT2 0xF0 = TC1, 0xF1 = TC2 Lock method...
  • Page 73 C2-7000 S ERIES PERATION ANUAL 0x40 = YC1, 0x41 = YC2, 0x42 = YC3 0x50 = SDI1, 0x51 = SDI2 0xD0 = OUT1, 0xD1 = OUT2 0xF0 = TC1, 0xF1 = TC2 Window Enable 0..1 = Off, On Zoom level % 100..1000 Zoom level H % 100..1000 (only used in Advanced A/R...
  • Page 74 C2-7000 S ERIES PERATION ANUAL V key Invert 0..1 = Off, On Swap fore / background 0..1 = Off, On Edge Blend Bit 0 = Left edge active Bit 1 = Right edge active Bit 2 = Top edge active Bit 3 = Bottom edge active E.blnd guides 0..2 = Off, Auto, On...
  • Page 75 C2-7000 S ERIES PERATION ANUAL Audio input 10..FF 0D0 0..9 = Channels 1 .. 10 on A2-2000 Audio vol 10..FF 0CF -16..15 (-16=Mute) 10..FF 0D1 -15..15 Input pixel phase 10..5F 091 0..31 RGB input type 10..1F 0C1 0 = Auto 1 = D-RGB 2 = D-YUV 3 = A-RGB...
  • Page 76: Examples

    C2-7000 S ERIES PERATION ANUAL H/V active (V) 64..2047 H/V start (H) 0..1023 H/V start (V) 0..1023 Clks/l 64..4095 Lines/f 64..2047 H/V sync (H) 8..1023 H/V sync (V) 1..1023 Sync polarity 0..3 = ++, +-, -+, -- System SW (Software version) Read only PT (Product type) Read only...
  • Page 77: Reading And Writing Macros

    C2-7000 S ERIES PERATION ANUAL Packet sent Packet returned SOP CMD CHA WIN OUT FUN PAY CS EOP SOP CMD CHA WIN OUT FUN PAY CS EOP Set output 1 window B Source to RGB2 000011 D9 CR 000011 19 CR Set output 1 window A to Enable advanced aspect control Note checksum is ?? for debugging...
  • Page 78: Reading A Previously Stored Macro

    C2-7000 S ERIES PERATION ANUAL Menu text CHA FUNC Range of adjustment (decimal) (Hex) Macro Run macro 0..7 F1 0..1 = Run, Erase macro Number of items within 0..7 F4 Read Only macro Function to adjust 0..7 F2 0..4095 Value 0..7 F3 Value for Function 10.5.1 Reading a previously stored Macro...
  • Page 79: Run And Restore Macros

    C2-7000 S ERIES PERATION ANUAL Clear macro 000001 3A CR 000001 7A CR Write the function for first item in macro 3 = Zoom 000086 C1 CR 000011 01 CR Write data for the first item = 100 000064 9E CR 000011 DE CR Write the function for the second = shrink 000087 C2 CR...
  • Page 80: Common Operations

    11.1 Operation of the Keyer The C2-7000 series has a very powerful Luminance and Chroma keyer and can key on Window “A”, Window “B” and Window “Z” independently. The listing that follows breaks the Keyer operation down to a series of steps that are defined by Operational Mode.
  • Page 81 C2-7000 S ERIES PERATION ANUAL  The Key Min/Max may need to be readjusted after making the softness adjustment.  Touch up any of the previous settings to get a clean key.  At this point, only the key color should be transparent. ...
  • Page 82 C2-7000 S ERIES PERATION ANUAL  Decrease V Key Min until reappears, then increase until it disappears again.  If the edges appear rough, increase the V Key softness.  The Key Min/Max may need to be readjusted after making the softness adjustment.
  • Page 83 C2-7000 S ERIES PERATION ANUAL Dual PIP Mode Method (One or Two Key Channels, Locked) Change mode:  Change Mode to Switcher Setup the lock source  Enter Adjust Outputs menu.  Select Output 1.  Set Lock to Lock & Mix. ...
  • Page 84 C2-7000 S ERIES PERATION ANUAL  The Key Min/Max may need to be readjusted after making the softness adjustment.  Touch up any of the previous settings to get a clean key.  At this point, only the key color should be transparent. ...
  • Page 85: Creating A Macro

    C2-7000 S ERIES PERATION ANUAL 11.2 Creating a Macro On the 10-key front panel units, you can store up to 5 macros and associate them with 5 different buttons of your choosing. It is also a good idea to assign another button to the Restore function.
  • Page 86: Standards Conversion - Ntsc To Pal

    C2-7000 S ERIES PERATION ANUAL  Press and hold the macro button (using SHIFT if needed) until the unit gives a short beep and the display says Info: Added to Macro. This has now added the Shrink position for window 1A to the macro ...
  • Page 87: Edge-Blending Setup

    This guide is intended to summarise how to setup such projectors when used with a suitable number of TV One’s CORIO®2 scaling engines. The C2-7000 series are dual processors and therefore require only a single unit to perform...
  • Page 88: Edge-Blending Requirements

    C2-7000 S ERIES PERATION ANUAL S-curves for left and right projectors, with edges blended. S-curves, when properly overlapping, will add together to result in full brightness. 12.2 Edge-blending requirements To obtain the best edge-blending results, you will need: 1. A perfectly flat projection screen. This is vital, or it will not be possible to perfectly align your two projected images with each other.
  • Page 89: Basic Setup Of The Two Projectors

    12.4 Connections to the scaler(s) and projectors For CORIO®2 units with two scaling engines (such as the C2-7000 series), use outputs 1 and 2 to connect to the left and right projectors respectively. If two single-channel scalers (such as the C2-1000 or C2-2000 series) are used, then connector unit ‘1’...
  • Page 90: Initial Setup

    PERATION ANUAL For use with dual-channel scalers such as the C2-7000 series, connect your video source (e.g. a DVD player or computer) to an input on the C2-7000 unit. It is not necessary to feed two signals – the C2-7000 unit can use the same signal for both outputs.
  • Page 91: Edge-Blending Activation

    2. Go into the ‘Adjust outputs’ menu and ensure that both scaling engines are outputting the same resolutions. (Hint: use Toggle 1 / 2 (Shift-1) to switch between 1A and 2B on the C2-7000 series.) 3. Go into the ‘Adjust windows’ menu and ensure that both scalers are set to the same ‘Source’, which needs to be your original video signal (e.g.
  • Page 92: Edge-Blending Guide Lines

    C2-7000 S ERIES PERATION ANUAL There is a formula for calculating the edge blend size (E) from the zoom value (Z) and horizontal pixel width of the output (H): E = 2 * H * (1 – Z/200) [pixels] For example, with zoom (Z) at 190%, output resolution of 1024x768 (H=1024), we can calculate E as: E = 2 * 1024 * (1 –...
  • Page 93: Alignment Of Projectors

    C2-7000 S ERIES PERATION ANUAL blending. (G marks the green lines, R marks the red, Y marks the yellow, for those reading in black and white.) Outputs 1 and 2 with guide lines shown. G R R G Outputs 1A and 2B partly overlapping. Outputs 1A and 2B perfectly overlapping –...
  • Page 94 C2-7000 S ERIES PERATION ANUAL Too far apart – you need around 15% overlap, such that the red and green lines overlap. Offset – make sure your projectors are perfectly R R G aligned both horizontally and vertically. Key-stoning – ensure your projectors have the same...
  • Page 95: Gamma Correction

    C2-7000 S ERIES PERATION ANUAL Perfect alignment – your red and green vertical lines should overlap to produce yellow ones. 12.10 Gamma correction By now you should have two perfectly aligned projectors, but possibly with a brighter than normal overlap. This is most probably because a projector’s luminance is not perfectly linear and therefore will need to have what’s called ‘gamma correction’...
  • Page 96: Locking Both Outputs Together

    This is best done by locking Output 2 to Output 1. For dual-channel units such as the C2-7000 series, perform the following: 1. Go to ‘Adjust outputs’ 2. Ensure that ‘2B’ is selected – press Toggle 1 / 2 (Shift-1) if not.
  • Page 97 C2-7000 S ERIES PERATION ANUAL E.blnd H 640x480 800x600 1024x768 1280x720 1280x1024 1600x1200 1920x1080i...
  • Page 98: Windows Control Panel

    C2-7000 S ERIES PERATION ANUAL 13.0 WINDOWS CONTROL PANEL A powerful utility is available for the C2 product range and can be downloaded from our support web site or found on the Product CD (where supplied). To install the application click on the setup file and follow the on screen instructions.
  • Page 99: Connecting To A Unit

    C2-7000 S ERIES PERATION ANUAL In the Ethernet section be sure to set the IP address to the same as the address you have set on the unit (units Ethernet menu). The port number used should also reflect the port number on the unit. If there are multiple units on the network then this port number should be the same for all units, only the IP address must be unique.
  • Page 100 C2-7000 S ERIES PERATION ANUAL Figure 4 Detecting a unit Once the application detects and connects to a unit you will be asked if you wish to “synchronize with the unit”, this will read all the settings from the connected unit and update the application. Figure 5 Synchronize application Once synchronized any changes made on the unit or on the application will be reflected on the unit and the application.
  • Page 101: Application Menu's

    C2-7000 S ERIES PERATION ANUAL 13.3 Application menu’s 13.3.1 File menu Figure 6 File menu Across the top of the application are the toolbar menu options. The first menu item is File within this menu you can Save and Load previous setups into the application, these setups contain all the settings of the unit.
  • Page 102: Tools Menu

    C2-7000 S ERIES PERATION ANUAL The Program Resolutions menu will program the resolutions into the unit as defined on the resolutions Tab. The Program Settings menu will program all adjustments into the unit 13.3.3 Tools menu Figure 8 Tools menu The tools menu provides access to the scripting tool, image loader and show settings.
  • Page 103: Image Loader

    C2-7000 S ERIES PERATION ANUAL Figure 10 Scripting button screen Up to 24 buttons/functions can be defined, and each of these buttons/functions can perform multiple actions. Figure 11 Script editor In order to edit or create a script select Script->Edit from the menu, this will then present the script editor as shown above.
  • Page 104: Loading Testcards

    C2-7000 S ERIES PERATION ANUAL 13.5.1 Loading Testcards Figure 12 Testcard loader To program a Testcard into the unit select the ‘Testcards’ tab from the image programmer screen and then press Load Image. You can select JPEG, BMP and GIF images. The image will be loaded and shown on the screen.
  • Page 105: Loading Logos

    C2-7000 S ERIES PERATION ANUAL 13.5.2 Loading Logos Figure 13 Logo Loader To program a logo into the unit select the ‘Logos’ tab from the image programmer screen and then press Load Image. You can select JPEG, BMP and GIF images. The image will be loaded and shown on the screen.
  • Page 106: Maximum Image Size - How Large Can My Logo / Testcard Be

    C2-7000 S ERIES PERATION ANUAL 13.5.3 Maximum Image size – how large can my logo / Testcard be? The image size for a logo or Testcard is limited by the amount of memory available in the unit; this is approximately 128K Bytes of compressed image for a Testcard and approximately 32K Bytes for a Logo.
  • Page 107 C2-7000 S ERIES PERATION ANUAL the minimum information of Horizontal and Vertical size and the desired refresh rate. It’s also possible to constrain the Vertical size of the resolution by selecting a custom, 4:3 or 16/9 aspect ratio and then left clicking your mouse on the Vertical Resolution box which will then automatically calculate the Vertical Resolution for the given Horizontal Resolution and Aspect Ratio.
  • Page 108 C2-7000 S ERIES PERATION ANUAL Figure 16 Add resolution to table Once your new resolution is added, you can program the resolution into the Scaler using the Communications menu and then selecting Program into unit and then selecting Program Resolutions. The application will proceed to program all the resolutions on the list into the scaler.
  • Page 109 C2-7000 S ERIES PERATION ANUAL Figure 17 Resolution editor - advanced timings In order to modify an existing resolution simply click on the resolution table at the bottom of the screen and it parameters will be editable within the Timings tab.
  • Page 110: Troubleshooting And Technical Support

    C2-7000 S ERIES PERATION ANUAL 14.0 TROUBLESHOOTING AND TECHNICAL SUPPORT If problems are experienced, please read through the symptom topics below in order to resolve the problem. After doing so, if you still need to, contact Technical Support at http://www.tvone.com/support. Please have the following details of the problem handy: Whether the problem happens only at specific times or has only just started occurring (and what other things have changed at the same time).
  • Page 111: There Is Excessive Flicker On The Output

    C2-7000 S ERIES PERATION ANUAL 14.4 There is excessive flicker on the Output. Try using a different Flicker reduction mode. Turning the contrast down and the brightness up on the output device can have a large effect on flicker. Or try adjusting the brightness and contrast of the source input by selecting the Input adjust menu.
  • Page 112: The Rgb Input Is Selected But The Image Is Rolling Or Pink

    C2-7000 S ERIES PERATION ANUAL 14.11 The RGB input is selected but the image is rolling or pink. Check the Adjust sources menu and confirm that the input type and sync method is set correctly. (Having YUV input selected, instead of RGBHV often causes this problem).
  • Page 113: Return Procedure

    15.2 To return a unit for repair First contact TV One using the http://www.tvone.com/support website. Support personnel will determine whether a return to the factory is the appropriate solution. If that’s the case, a Return Authorization Number will be issued.
  • Page 114 C2-7000 S ERIES PERATION ANUAL Please clearly state the return number on the outside packaging and on any accompanying documentation. This will greatly speed up processing. IMPORTANT: DO NOT return a unit for warranty repair without first obtaining a Return Authorization Number. No action will be taken on a unit returned in warranty for repair without a Return Authorization Number.
  • Page 115: Warranty Policy

    The liability of TV One with respect to any defective products will be limited to the repair or replacement of such products. In no event shall TV One be...
  • Page 116: Connector Pinouts

    C2-7000 S ERIES PERATION ANUAL 17.0 CONNECTOR PINOUTS 17.1 DVI-I connector PIN# SIGNAL PIN# SIGNAL T.M.D.S DATA 2- HOT PLUG DETECT T.M.D.S DATA 2+ T.M.D.S DATA 0- T.M.D.S DATA 2/4 SHIELD T.M.D.S DATA 0+ Not used T.M.D.S DATA 0/5 SHIELD Not used Not used DDC CLOCK...
  • Page 117: Specification

    C2-7000 S ERIES PERATION ANUAL 18.0 SPECIFICATION 18.1 Video Inputs Composite Video 3 x via BNC Connector S-Video (Y/C) 3 x via 4-PIN Mini-DIN Connector DVI-I 3 x via DVI-I Connector (DVI-I = DVI-D / RGB / YUV) C2-7200/7210/7260: SDI or HD-SDI 2 x via BNC Connector C2-7260: only 2 of the 8 SD/HD-SDI inputs can be used simultaneously.
  • Page 118: Input Rgb Sync

    C2-7000 S ERIES PERATION ANUAL HD-SDI jitter (100kHz) approx. 0.176 +/- 0.02 UI 18.6 Input RGB Sync Type RGBHV, RGBS, RGsB Level / Termination TTL, 10K. Polarity Positive or Negative Maximum Level 5Vp-p 18.7 Output RGB Sync Type RGBHV, RBGS Level / Termination 5Vp-p, 56.
  • Page 119: Contact Information

    PERATION ANUAL 19.0 CONTACT INFORMATION Should you have and questions or require assistance with this product in areas not covered by this manual, please contact TV One at the appropriate location shown below: TV One USA TV One Europe 1350 Jamike Drive...

Table of Contents
