PHICOMM FD-364N User Manual

150mbps wireless n adsl2/2+ modem router
Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual

150Mbps Wireless N
ADSL2/2+ Modem Router
FD-364N
User Manual / V2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FD-364N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PHICOMM FD-364N

Summary of Contents for PHICOMM FD-364N

  • Page 1: User Manual

    User Manual 150Mbps Wireless N ADSL2/2+ Modem Router FD-364N User Manual / V2.0...

  • Page 2: Copyright Statement

    All the photos and product specifications mentioned in this manual are for references only, as the upgrading of software and hardware, there will be changes. And if there are changes, PHICOMM is not responsible for informing in advance. If you want to know more information about our products, please visit our website at www.phicomm.com.

  • Page 3: Table Of Contents

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com CONTENTS Chapter 1: Introduction ..........1 Product Overview ....................1 Main Features ....................... 2 Chapter 2: Hardware Installation ........3 Front Panel ......................3 Rear Panel ......................4 Physical Connection ..................5 Chapter 3: Quick Installation ........7 Configure Your PC ....................
  • Page 4 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com NAT ............................31 ADSL ............................33 QoS ............................33 PortBinding ..........................36 Access Management ..................36 SNMP ............................37 UPnP ............................37 DDNS ............................38 ACL ............................39 Filter ............................40 CWMP ............................41 Maintenance ......................
  • Page 5 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Chapter5: Specification ..........49 Appendix A: Troubleshooting ........50 Appendix B: Certification .......... 52 FCC Statement ....................52 CE Mark Warning ..................... 53 Appendix C: Glossary ..........54 Table of Contents...

  • Page 6: Chapter 1: Introduction

    Chapter 1: Introduction Product Overview Thank you for choosing PHICOMM FD-364N Wireless N ADSL2+ Modem Router. This product is designed to provide a simple and cost-effective ADSL internet connection for a private Ethernet network. It is connected to network devices via standard Ethernet ports. The ADSL connection is made using ordinary telephone line with standard connectors.

  • Page 7: Main Features

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Main Features Complies with IEEE 802.11n to provide a wireless data rate of up to 150Mbps  Provides 1 RJ11 DSL port, 4 RJ45 LAN ports  Up to 24Mbps downstream speed ...

  • Page 8: Chapter 2: Hardware Installation

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Chapter 2: Hardware Installation Front Panel The front panel of the wireless ADSL2+ Modem Router includes one power indicator and eight function indicators, as explained in table below: Status Indication Power is on...

  • Page 9: Rear Panel

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com The wireless function is enabled WLAN The wireless function is disabled Blinking Sending or receiving data over wireless network The Modem Router is synchronized Blinking The Modem Router is synchronizing Green A successful PPP connection has been built...

  • Page 10: Physical Connection

    • PHONE: Connect to the phone sets. • MODEM: Connect to the DSL port of FD-364N. Plug one end of the twisted-pair ADSL line into the DSL port on the rear panel of FD-364N. Connect the other end to the MODEM port of the external splitter.
  • Page 11 Step 2: Connect the Ethernet cable. Attach one end of a network cable to your computer’s Ethernet port or a regular hub/switch port, and the other end to the LAN port on the FD-364N. Step 3: Attach the power adapter. Connect the AC power adapter to the PWR connector on the rear of the device and plug in the adapter to a wall outlet or power extension.

  • Page 12: Chapter 3: Quick Installation

    Chapter 3: Quick Installation Configure Your PC After you directly connect your PC to FD-364N or a Hub/Switch which has connected to the Wireless Modem Router, we suggest you set your computer to obtain IP address automatically For Windows XP/2000 1) Click Start >...
  • Page 13 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com 2) Select and double click Network Connections. 3) Right click Local Area Connection and then select Properties. Chapter 3: Quick Installation...
  • Page 14 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com 4) Select Internet Protocol (TCP/IP) and click Properties. 5) Select Obtain an IP address automatically and Obtain DNS server address automatically. Then click OK. Chapter 3: Quick Installation...
  • Page 15 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com For Windows Vista/7 1) Click Start>Control Panel. 2) Click Network and Internet. Chapter 3: Quick Installation...
  • Page 16 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com 3) Click Network and Sharing Center. 4) Go to Change Adapter Settings (win7)/Manage Network Connections (Vista). Chapter 3: Quick Installation...
  • Page 17 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com 5) Right click Local Area Connection, choose Properties. 6) Select Internet Protocol Version 4 (TCP/IPv4) and click Properties. Chapter 3: Quick Installation...

  • Page 18: Install Your Modem Router

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com 7) Select Obtain an IP address automatically and Obtain DNS server address automatically. Then click OK. Install Your Modem Router To configure the device, you can either run the Resource CD or run the Web based Setup Wizard.
  • Page 19 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Step 3: Go to Quick Start tab, and then click RUN WIZARD. Step 4: Click NEXT. Step 5: If you want to change the login password, put in the new password in this page.
  • Page 20 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Step 6: Choose your time zone, and then click NEXT. Step 7: Choose the connection type provided by your ISP (take PPPoE/PPPoA as an example here), and then click NEXT. Step 8: Put in Username, Password, VPI, VCI and Connection Type provided by your ISP. If you are not sure about the information, please confirm with your ISP.
  • Page 21 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Step 9: Click NEXT. Step 10: Click CLOSE. Note:  Wait a moment, if the configuration is successful, the Internet LED light will finally turn green.  The Internet light will not light on if the Wireless Modem Router works as bridge, please set up a broadband connection on your computer in that condition.

  • Page 22: Chapter 4: Software Configuration

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Chapter 4: Software Configuration This User Manual recommends using the Quick Installation Guide for first-time installation. For advanced users, if you want to know more about this device and make use of its functions adequately, maybe you will get help from this chapter to configure the advanced settings through the Web based Setup Wizard.

  • Page 23: Internet

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Internet ATM VC: ATM settings are used to connect to your ISP. Your ISP provides VPI (Virtual Path Identifier), VCI (Virtual Channel Identifier) settings to you. In this Device, you can totally setup 8 VCs on different encapsulations, if you apply 8 different virtual circuits from your ISP.
  • Page 24 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com 1. Dynamic IP· Select this option if your ISP provides you an IP address automatically. This option is typically used for Cable services. Please enter the Dynamic IP information accordingly. Encapsulation: Select the encapsulation mode for the Dynamic IP Address, it is provided by your internet service provider.
  • Page 25 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com 2．Static IP Select this option if your ISP provides static IP information to you. You should set Static IP Address, IP Subnet Mask, and Gateway on the screen below. Note: Each IP address entered in the fields must be in the appropriate IP form, which is four IP octets separated by a dot (x.x.x.x), such as 192.168.1.100.
  • Page 26 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com 3. PPPoA/PPPoE Select this option if you have a username and password to access internet. This option is typically used for DSL services. Select Dynamic to obtain an IP address automatically for your PPP connection.
  • Page 27 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Static/Dynamic IP Address: For PPPoA/PPPoE connection, you need to specify the public IP address for this ADSL Router. The IP address can be either dynamically (via DHCP) or given IP address provided by your ISP. For Static IP, you need to specify the IP address, Subnet Mask and Gateway address.

  • Page 28: Lan

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Router Local IP: These are the IP settings of the LAN interface for the device. These settings may be referred to as private settings. You may change the LAN IP address if necessary. The LAN IP address is private to your internal network and cannot be seen over internet.
  • Page 29 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com DHCP: Select Enabled, then you will see the screen. The Router will work as a DHCP server, it becomes the default gateway for DHCP clients connected to it. DHCP stands for Dynamic Host Control Protocol. The DHCP Server gives out IP addresses when a device is booting up and request an IP address to be logged on to the network.

  • Page 30: Wireless

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Server IP: Enter the DHCP server IP address runs on WAN side. Note: If you select Disabled, the DHCP function will not take effect. DHCP Relay may be no use if default route is not dynamic or static routing mode! Add DHCP Reservation: Assign a static IP for some certain computer.
  • Page 31 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Channel: Select the channel you want to use from the drop-down List of channel. This field determines which operating frequency will be used. It is not necessary to change the wireless channel unless you notice interference problems with another nearby access point.
  • Page 32 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com SSID: Refer to your wireless network name, you can change it to anything you want. The SSID must be identical for all devices in the wireless network. It is case-sensitive and must not exceed 32 characters.
  • Page 33 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Note: This feature is available only when OPEN, WPA-PSK, WPA2-PSK or WPA/WPA2-PSK mode is • configured. To build a successful connection by WPS, you should also do the corresponding • configuration of the new device for WPS function meanwhile.

  • Page 34: Advanced Setup

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Wireless MAC Address Filter: Wireless access can be filtered by using the MAC addresses of the wireless devices transmitting within your network’s radius. To filter wireless clients by MAC Address, either deny or allow access. If you do not wish to filter users by MAC Address, select Deactivated.

  • Page 35: Firewall

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Firewall Firewall: Select this option can automatically detect and block Denial of Service (DoS) attacks, such as Ping of Death, SYN Flood, Port Scan and Land Attack. SPI: If you enable SPI, all traffics initiated from WAN would be blocked, including DMZ, Virtual Server, and ACL WAN side.

  • Page 36: Nat

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Gateway IP Address: Enter the IP address of the gateway. The gateway is an immediate neighbor of your ADSL Router that will forward the packet to the destination. On the LAN, the gateway must be a router on the same segment as your Router; over Internet (WAN), the gateway must be the IP address of one of the remote nodes.
  • Page 37 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com DMZ Host IP Address: Enter the specified IP Address for DMZ host on the LAN side. Note: For security reasons, you should avoid using the default DMZ server feature. When a computer is designated as the default DMZ server, it loses much of the protection of the firewall, and is exposed to many exploits from the Internet.

  • Page 38: Adsl

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Local IP Address: Enter the IP Address for the virtual server in LAN side. Virtual Server Listing: This displays the information about the virtual servers you establish. ADSL You can select the ADSL Mode and ADSL Type on the next screen. The ADSL feature can be selected when you meet the physical connection problem.
  • Page 39 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com QoS: Select this option to Activate/Deactivate the IP QoS on different types. Discipline: Choose WRR or Strict Priority WRR weight: Set the priority weight. Rule: Configure the rules for QoS. If the traffic complies with the rule, then the Wireless Modem Router will take the corresponding action to deal with it.
  • Page 40 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com well as differentiated Internet services by giving network resource and usage control to the network operator. IP Precedence Range: Enter the IP precedence range that the Router takes to differentiate the traffic. Type of Service: Select the type of service that the Wireless Modem Router takes to deal with the traffic.

  • Page 41: Portbinding

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com PortBinding Active: To active or deactive this function. Group Index: Show the index of rules. ATM VCs & Ethernet & WLan: Choose the PVCs, Ethernet port, WLan that controlled by the rule. PortBinding Summary: Display the summary of PortBinding.

  • Page 42: Snmp

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com SNMP The SNMP (Simple Network Management Protocol) is used for exchanging information between network devices. Get Community: Set the password for the incoming get and get next requests from the management station. Set Community: Set the password for incoming set requests from the management station.

  • Page 43: Ddns

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com DDNS The router offers a DDNS (Dynamic Domain Name System) feature. The feature lets you use a static host name with a dynamic IP address. Please type the host name, user name and password assigned to your ADSL Router by your Dynamic DNS provider.

  • Page 44: Acl

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com You can specify the client to access the ADSL Router once setting its IP as a Secure IP Address through selected applications. ACL: If Activated, the IP addresses which are contained in the Access Control List can access to the Router.

  • Page 45: Filter

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Filter The filtering feature includes IP/MAC Filter, Application Filter and URL Filter. The feature makes it possible for administrators to control user's access to internet, protect the networks. Filter Type Selection: Select the filter type for the configuration below.

  • Page 46: Cwmp

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Protocol: TCP, UDP or ICMP in the drop-down list for the connection between the Source IP address and Destination IP address. IP/MAC Filter Listing: This displays the information about the IP Filter rules.

  • Page 47: Maintenance

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Path: Enter the path that connects to the ACS server. User Name/Password: Enter the User Name and Password that provided the ACS server to login the router. Periodic Inform: Activate or deactivate the function. If Activated, the information will be informed to ACS server periodically.
  • Page 48 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com NTP server is set, you will only need to set the time zone. If PC’s Clock is selected, the device will get the PC’s Clock by way of the system time. 1. NTP Server automatically Select NTP Server automatically as the synchronize time, please choose the time zone.

  • Page 49: File Upgrade

    Or click the Browse button to locate the update file. Step 3: Click UPGRADE. Note: New firmware versions are posted at www.phicomm.com and can be downloaded for free. If • the router is not experiencing difficulties, there is no need to download a more recent firmware version, unless the version has a new feature that you want to use.
  • Page 50 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com When you upgrade the router's firmware, you may lose its current configurations, so please • back up the router’s current settings before you upgrade its firmware. Do not turn off the router or press the Reset button while the firmware is being upgraded.

  • Page 51: Sysrestart

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com SysRestart You can select to restart the device with current settings or restore to factory default settings in this page. Diagnostic You can view the test results for the connectivity of the physical layer and protocol layer for both LAN and WAN sides in this page.

  • Page 52: Device Info

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Device Info You can view the device information, including LAN, WAN and ADSL in this page. The information will vary depending on the settings of the Wireless Modem Router configured on the Interface Setup screen.

  • Page 53: System Log

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com System Log You can query the logs of the Wireless Modem Router in this page. Statistics You can view the network traffic over network in this page. Interface: You can select Ethernet, ADSL and WLAN to view the corresponding network traffic over different ports.

  • Page 54: Chapter5: Specification

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Chapter5: Specification Basic Standards IEEE 802.11n ,IEEE 802.11g, IEEE802.11b, IEEE802.3, 802.3u Interfaces 1 x RJ11 DSL Port, 4 x RJ45 LAN Port LED Indicators Power, LAN1-LAN4, WPS, WLAN, DSL, Internet Data Rate Downstream: Up to 24Mbps, Upstream: Up to 1Mbps...

  • Page 55: Appendix A: Troubleshooting

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Appendix A: Troubleshooting 1. How do I restore my Wireless Modem Router’s configuration to factory default settings? With the router powered on, press the Reset button on the rear panel, keep holding it for about 5 seconds then release it.
  • Page 56 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com make sure the VPI/VCI, Connection Type, username and pass word are correct. If there are any mistakes, please correct the settings and try again. 6. The computer cannot connect to the internet wirelessly.

  • Page 57: Appendix B: Certification

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Appendix B: Certification FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 58: Ce Mark Warning

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com This equipment should be installed and operated with a minimum distance of 20 • centimeters between the radiator and your body. CE Mark Warning Marking with the above symbol indicates compliance with the Essential Requirements of the R&TTE Directive of the European Union (1999/5/EC).

  • Page 59: Appendix C: Glossary

    150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com Appendix C: Glossary ATM (Asynchronous Transfer Mode): ATM is a cell based transfer mode that requires variable length user information to be segmented and reassembled to/from short, fixed length cells. It uses two different methods for carrying connectionless network interconnect traffic, routed and bridged Protocol Data Units (PDUs), over an ATM network.
  • Page 60 150Mbps Wireless N ADSL2/2+ Modem Router www.phicomm.com VCI (Virtual Channel Identifier): The identifier of the VC contained in the ATM cell header. VPI (Virtual Path Identifier): The identifier of the VP contained in the ATM cell header. VLAN (Virtual Local Air Network): Logical subgroups that constitute a Local Area Network (LAN).
  • Page 61 Shanghai Feixun Communication Co., Ltd. E-mail: support@phicomm.com Website: www.phicomm.com Copyright © 2011 Shanghai Feixun Communication Co., Ltd. All rights reserved.
