ThinkPad 770 - withdrawn
IBM ThinkPad :
Processor type/path Pentium MMX 200/66 or 233/66MHz
Processor features No upgrade / processor, L2 cache, and MTXC (North Bridge) on Intel MMO
L2 cache 512KB / write-back / direct mapped / 7ns data; 15ns tag / sync pipelined burst
Diskette (removable) 3.5" 1.44MB / in encased enclosure / use in UltraBay II or attach externally
External FDD port External diskette port (use std cable to attach diskette drive externally)
CD-ROM (removble) Option: 5.25" CD-ROM / 20X-8X
EIDE (ATAPI) / PIO Mode 4 for W95; DMA Mode 2 for NT / use in UltraBay II
DVD (removable) Option: DVD-ROM drive / 8 x to 16 x spd / CAV / use in UltraBay II / (DVD5/4.7GB)
requires DVD and Enhanced Video Adapter for movie playback / sw enb AC-3 port
Type - model 9548-40U
Processor 200/66MHz
Display (diagonal) 13.3" XGA
Disk (removable) 3.2GB
Preload (see side) W95 OSR2
DVD and Enh Vid Ad Optional
Modem Opt PC Card
Avail / withdrawn date October 1997 / September 1998
Memory - std / max 32MB / 256MB
Memory - upgrade 2 sockets available for two JEDEC 144 pin EDO or SDRAM SO-DIMMs
Sockets accessed by removing screw on bottom / can mix SDRAM w/ 760-supported EDO
Display - size (colors) XGA color / 640 x 480 (16M), 800 x 600 (16M), or 1024 x 768 (65,536 siml colors)
Display - techology Active Matrix TFT - 100 to 1 contrast ratio / 180 degree tilt
Graphics - controller Trident CYBER9397 / 64-bit SVGA accelerator / 2MB SGRAM / 83MHz
Graphics - arch PCI 2.1 / Direct3D, DirectDraw, DirectVideo, ActiveMovie support / ZV interface
Graphics - features 3D hardware accelerator / interpolation in X and Y axis / color space conversion
Graphics - external External SVGA to 1280 x 1024 w/ 256 colors (75Hz) or 1024 x 768 w/ 65,536 colors
Disk (removable) Left side / removable via 3 methods: latch, coin screw, security tool / SMART
Disk controller Enhanced IDE / busmaster / PCI 2.1 / 430TX South Bridge / PIIX4 / supports two
internal disks (16.2GB max) / DMA Mode 2, Ultra DMA/33, or PIO Mode 4
Keyboard / Fn keys Full size alp/num / 7 Fn key functions / integrated palm rest
Keyboard slope Flat keyboard (does not lift up) / rear legs pop up (5.5 degrees slope)
Pointing device TrackPoint / Press-to-Select / Release-to-Select / dragging / click pace/
center click button for scrolling or magnifying glass / suspension top
Dimensions 1AU: 12.3 x 10 x 2.2" (270 cubic in) / 7.8 pounds (3.55 kg) with battery/diskette
Weight 2 Others: 12.3 x 9.5 x 2.2" (257 cubic inches) / 7.4 pounds (3.35 kg) with batt/diskette
Battery - type Lithium Ion / intelligent / left side
Battery - life (1 batt) 1AU: 3.5 hrs (7 hrs with second battery in UltraBay II) / Others: 4 hrs (8 hr w/ 2 batt)
Charge time - on / off 2 to 3 hrs / 1.5 to 2.5 hrs
Architecture ISA (audio, modem, diskette, serial, parallel, infrared, ext expansion)
PCI 2.1 / 32-bit / 33Mhz (EIDE, graphics, CardBus, MPEG, USB, ext expansion)
Intel 430TX PCIset / TI PCI1250 for CardBus / LM75 digital thermometer
Port replicator SelectaBase 770 / PC Card Enabler
Docking Station SelectaDock III / SelectaDock I and II
PC Card Std slots 2 Type I, 2 Type II, or 1 Type III / CardBus 32-bit PCI / PCMCIA 2.1 / Zoomed Video
USB / serial / parallel One USB / one 9 pin serial; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional)
Other features APM-aware BIOS / AC Adapter barrel, 3 prong (56 watts) / Selectable boot
Video in/out 1AU or option: Video in/out (composite and S-Video) / SAA7111A NTSC/PAL
1AU or option: MPEG-2 / IBM MPEGCD1M / 2MB SDRAM; 100MHz
MPEG decoder
Data/fax modem 1AU: 33.6Kbps (56Kbps upgradeable via x2
Audio support 16-bit / CS4237B / SRS 3D audio / FM synthesis / software decodes AC3 into stereo
Int stereo speakers (front) / 1 watt / rotary volume control (right) / int microphone
Jacks Input jack (3.5 mm) / Output jack (3.5 mm) / full duplex
Infrared ports Infrared ports (front and back) / IrDA 1.1 compatible / up to 4Mbps
Security Power-on password / Hard disk password / Supervisor password / security keyhole /
personalization / phillips-head screws on base for battery and UltraBay II bays
Limited warranty 11 3 year - ThinkPad EasyServ (depot repair service) or carry-in / international
15
Service options On-site, M-F, 8-5, next bus day (72 cities) / warranty extension to 5 years
DVD and Enhanced Video Adapter provides
(standard in 1AU; optional all others):
- MPEG-1, MPEG-2 HHR, and full MPEG-2
hardware decoder (audio decoded via software)
- DVD movie playback (MPEG-2 decoding;
decryption and audio decoding via software)
- Video in (composite and SVHS) (NTSC or PAL) for
video capture (capture and digitize video from a TV
or VCR), still image capture (capture and digitize
still photo images), and overlay
- Video out (composite and SVHS) to TV
(connect to video out port; NTSC or PAL);
or record on VCR the screen of ThinkPad
- Dolby Digital AC-3
Digital signal from AC-3 connector; CSA8404A);
requires external AC3 decoder/amplifier
- Three ports - video in,
- Includes video in/out cable
ThinkPad EasyServ : customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business day average turnaround).
5
9548-30U
233/66MHz
13.3" XGA
4
/ PIO4 4GB / PIO4
W95 OSR2
Optional
Opt PC Card
3 non-parity / 3.3v / SDRAM / 83 or 100MHz
integrated Mwave 3780i DSP / international programmable DAA
6
(outputs undecoded Dolby
video out, AC-3
1
(Tillamook) / 64bit to L2 and memory
or 24X-10X 5 speed / CAV / bootable / hot swapping
9548-31U 9549-1AU
233/66MHz 233/66MHz
13.3" XGA 14.1" XGA
4GB / DMA33 5.1GB / PIO4
NT 4.0 SP3 W95 OSR2
Optional Standard
Opt PC Card 33.6Kbps (upg) Opt PC Card
8 ) / 14.4Kbps fax / telephony /
- 5.1GB disk, 12ms, Ultra DMA/33
- 8.1GB disk, 12ms, Ultra DMA/33
- 2nd Disk Adapter (for 760/770 disks) 11J8836
- SelectaBase 770
- SelectaDock I 18
18
- SelectaDock II
- SelectaDock III 18
- SelectaBase PC Card Enabler
- 760 UltraBay Tray for SD III
- 56 watt AC Adapter (barrel; 3 prong) 83H6739
- 20X-8X CD-ROM Drive (UltraBay II) 11J8933
- 24X-10X CD-ROM Drive (UltraBay II) 02K0516
- DVD CD-ROM Drive (UltraBay II)
- DVD and Enh Video Adapter
- 16MB SO DIMM 3.3v NP SDRAM
- 32MB SO DIMM 3.3v NP SDRAM
- 64MB SO DIMM 3.3v NP SDRAM
- 56K PC Card Modem Kit
- ThinkPad 770 Li-Ion Battery
WINDOWS 95 PRELOAD
- Microsoft Windows 95 OSR2 (FAT16)
- Online User's Guide
- ThinkPad Configuration Program
- Diskette Factory Utilities
1. Puma TranXit; 2. IBM AntiVirus
3. Asymetrix Digital Video Producer (1AU)
4. RingZero Ring Central (1AU only)
5. Intelliquest Registration Mailer
6. Voyetra Audiostation
7. Artisoft ConfigSafe
9548-32U (AAP)
8. IBM Internet Connection services with
233/66MHz
Netscape Navigator web browser
13.3" XGA
9. Intel LANDesk Client Manager
None
10. Intel Video Phone (receive) (1AU only)
Blank (no disk)
11. ThinkPad PointCast
Optional
12. NetMeeting 2.0
13. Ergonomics; 14.ThinkPad on the NET
15. NetFinity for Windows 95
- Recovery CD-ROM with boot diskette
- Windows 95 CD-ROM (no installation)
- Internet Explorer 4.0 CD-ROM
WINDOWS NT 4.0 PRELOAD
- Windows NT Workstation (FAT16)
- Advanced NT extensions:
- Power management
- UltraBay Plug and Play
- DVD (storage only; no DVD movies)
- Hot Plug PC Card; MPEG-2 playbck
- 3D graphics (OpenGL)
- Video capture
- Online User's Guide
- ThinkPad Configuration Program
1. IBM AntiVirus
2. IBM Internet Connection services with
Netscape Navigator web browser
3. Intel LANDesk Client Manager
The right bay (UltraBay II) has LED on
release latch to provide status; it supports
hot swapping; it supports:
std diskette;
optional CD-ROM;
optional 2nd battery;
ThinkPad Proven VST Zip 100 drive;
Easy-Setup is entered by holding F1 when
turning on.
Screens are 150 nits (90 nits on battery)
ThinkPad 770 supported disks:
- 3.2GB 13ms read/14ms write
17 mm PIO Mode 4 or DMA Mode 2
- 4.0GB 13ms read/14ms write
12.5 mm PIO Mode 4 or Ultra DMA/33
- 5.1 and 8.1GB 12ms read/13ms write
17 mm PIO Mode 4 or Ultra DMA/33
- All 760 supported disks (requires opt adaptr)
FEATURES OF 770 MODELS
Wired for Management 1.1a
11J8947 PC 97 compliant
02K0517 DMI 1.1 compliant
DMI instrumentation (thermal monitoring)
83H6735 Wake-on-LAN via SelectaDock III
3547001 C: is 1.99 GB, D: is up to 1.99 GB, etc.
3547002 Quick Setup Guide (single page)
3547003 LCD indicator panel
83H6741 Plug and Play 1.0a
11J8839 Discharge battery via mouse click
Non-disruptive battery exchange
Standby, suspend, safe suspend, and
hibernation modes
11J8950 ENERGY STAR compliant
11J8957 International Warranty Service
76H0293 IBM SystemXtra
76H0294 24 hour / 7 day telephone, bulletin
76H0295 board, fax, electronic, and Internet
04K0052 (www.ibm.com/pc/us) support
83H6738 IBM and dealer warranty/service
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(770)
16
optional DVD drive;
optional 2nd disk;
optional
14
IBM Corp. August 1998
