IBM ThinkPad 510Cs Reference page 75

IBM
ThinkPad 760XL - withdrawn
         
: : : : :
IBM ThinkPad
Processor type
Processor upgrade
L2 cache
Removable diskette
External FDD port
Removable CD-ROM
Type - model (code)
Preload (see side)
Avail / withdrawn date
Remv disk - size / ms
Disk controller
Display - size and type
Display - techology
Graphics - controller
Graph - arch/data path
Graphics - features
Graphics - external
Memory - std / max
Memory - sockets avail
Memory - features
Keyboard / # of keys
Keyboard slope
Pointing / palm rest
Dimensions
Weight
Battery - type
Battery - life (1 batt)
Charge time - on / off
Architecture
Docking Station
Port replicator
PC Card Standard slots
Serial / parallel ports
Other features
Video in/out
MPEG decoder
DSP function
Data/fax modem
Audio support
Jacks
Telephone
Infrared ports
Security
Warranty
The left bay (UltraBay) supports:
x 2nd disk (requires Second HDD Adapter)
y 2nd battery
z Standard diskette drive
{ 2.88 MB diskette drive
➄ CD-ROM
Maximum internal disk capacity on 760XL is
10.2 GB with two 5.1 GB disks
Easy-Setup is entered by holding F1 when
turning on.
810 MB = DMA Mode 2 or PIO Mode 4
1.08 GB = DMA Mode 2 or PIO Mode 4
1.2 GB = DMA Mode 1 or PIO Mode 3
1.35 GB = DMA Mode 2 or PIO Mode 4
2.1 GB = DMA Mode 2 or PIO Mode 4
3.0 GB = DMA Mode 2 or PIO Mode 4
5.1 GB = Ultra DMA/33 or PIO Mode 4
ThinkPad EasyServ     : customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business day average turnaround).
❍
= Removable
✂ ✂ ✂ ✂ ✂ 760XL
12.1" SVGA TFT - thick
    
Pentium MMX 166/66 MHz (P55CLM) / 64 bit to L2 cache / 64 bit to memory
None
256 KB / write-back / direct mapped / 10 ns / synchronous pipelined burst
3.5" 1.44 MB ❍ / use in UltraBay or attach externally via rear ext FDD port
External FDD port (requires FDD External Attachment Kit 66G3618)
None / can upgrade to 4 x, 6 x, 8 x, or 8-20 x CD-ROM into UltraBay
9547-U9C (Michigan MMX)
Windows 95 OSR2
April 1997 / January 1998
❍
2.1 GB / 13 ms / DMA Mode 2 or PIO Mode 4
EIDE / busmaster / PCI 2.1 / supports two internal disks
12.1 inch SVGA color / 640 x 480, 800 x 600 / 65,536 simultaneous colors
Black Matrix TFT - active matrix / 100 to 1 contrast ratio
Trident CYBER9385 / 64 bit SVGA accelerator / 1 MB EDO DRAM / 70 ns
PCI 2.1 / 32 bit / DCI, DirectDraw, EnDIVE support
Simultaneous LCD and CRT / 180 degree tilt
External SVGA to 1024 x 768 with 256 colors
16 MB / 104 MB
2 sockets available
70 ns / non-parity / 3.3 volt / EDO / supports JEDEC 144 pin SO-DIMMs
8 MB in system; 8 MB on memory module with 2 SO-DIMM sockets
Memory module under disk (not removable) and accessible by opening keyboard
If use 64 MB SO-DIMM, the 8 MB on memory module is disabled via switch
Full size alp/num / 85 (8 Fn key functions)
Automated tilt up keyboard (5.5 degrees)
TrackPoint III / integrated palm rest / ext keyboard support (with option cable)
11.7 x 8.3 x 2.14" (208)
6.7 pounds (3.05 kg)
Lithium Ion / intelligent (optional NiMH battery supported)
2.3 hours (4.6 hours with 2 batteries)
2 to 3 hrs / 1.5 to 2.5 hrs
ISA (audio, diskette, serial, parallel, infrared, ext expansion)
PCI 2.1 / 32 bit / 33 MHz (EIDE, graphics, CardBus, ext expansion)
Intel Mobile Triton 82430MX PCIset / TI PCI1130 for CardBus
Dock I and II / SelectaDock I and II
Port Replicator I and II / SelectaDock Base Model I
2 Type I or 2 Type II or 1 Type III / CardBus 32 bit PCI / PCMCIA 2.1 compatible
One 9 pin; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional)
APM-aware BIOS / Slim AC Adapter 2 prong (35 watts) / Selectable boot
None
Liftable (pop-up) keyboard to access and
None
remove diskette drive, 1st/2nd disk, and
None
1st/2nd battery, and other UltraBay options
None
16 bit audio chip / 20 voice MIDI FM synthesis / ESS1688
Int stereo speakers / .5 watt / slide volume control / internal microphone
Input jack (3.5 mm) / output jack (3.5 mm)
None
Infrared ports (front and back) / IrDA 1.0 compatible / up to 115 kbs
Power-on password / Hard disk password / Supervisor password / Locking
device keyhole (Kensington cable lock) / Security latch for keyboard and
DIMMS (requires Kensington) / PC Card lock / Personalization / Security Plate
3 year - ThinkPad EasyServ (depot repair service) or carry-in
- Second HDD Adapter
- Dock I (1 slot / 1 bay)
- Dock II (2 slot / 2 bay)
- IDE Conversion Card (for Dock II) 46H5994
- SelectaDock I
- SelectaDock II
- SelectaDock III
- Port Replicator I (w/ PCMCIA slots) 66G3510
- Port Replicator II
- SelectaDock Base Model I
- 2.88 MB diskette
- FDD External Attachment Kit
- 35 watt AC Adapter (slim, 4 pin)
- 4 x CD-ROM (UltraBay)
- 6 x CD-ROM (UltraBay)
- 8 x CD-ROM (UltraBay)
- 8-20 x CD-ROM (UltraBay)
- 8 MB SO DIMM 3.3v NP EDO 64 bit 92G7340
- 16 MB SO DIMM 3.3v NP EDO 64 bit 92G7341
- 32 MB SO DIMM 3.3v NP EDO 64 bit 92G7342
- 64 MB SO DIMM 3.3v NP EDO 64 bit 76H0268
9547-U9K (Michigan MMX)
Windows NT Workstation 4.0
April 1997 / January 1998
32 MB / 104 MB
1 socket available (1 socket uses 16 MB)
OPTIONS
WINDOWS 95 PRELOAD
- Microsoft Windows 95 OSR2 (FAT16)
- Online User's Guide
- ThinkPad Features
- Diskette Factory
1. Lotus Organizer
2. CompuServ for Windows
3. Puma TranXit
4. NetFinity for Windows 95
5. Triton CoSession Host
6. IntelliLink Connect
7. IBM AntiVirus
8. IBM Internet Connection Services with
Netscape Navigator web browser
9. Registration Mailer
- Lotus SmartSuite 96 CD-ROM
- Recovery CD-ROM with boot diskette
- Windows 95 CD-ROM (no installation)
WINDOWS NT 4.0 PRELOAD
Microsoft Windows NT 4.0 Workstation
with utilities and device drivers
ThinkPad 760XL supported batteries:
- 760 NiMH Battery (black)
- Li-Ion Battery Pack II (gray)
- Travel Quick Charger
- Car Battery Adapter
ThinkPad 760 supported disks:
- (360/750/755 IDE
- 720 MB HDD II EIDE 12.5 mm 29H9383
- 810 MB HDD II EIDE 12.5 mm 29H9313
- 1.08 GB HDD II EIDE12.5 mm 29H9319
- 1.2 GB (1.96"+ models) 17 mm
- 1.4 GB HDD 3L EIDE12.5 mm 69H8412
- 2.1 GB (1.96"+ models) 17 mm
- 3.0 GB (1.96"+ models) 17 mm
- 5.1 GB (1.96"+ models) 17 mm
29H9333
3545001
3546001
FEATURES OF 760 MODELS
3547001
Quick Setup Guide (single page)
3547002
LCD indicator panel
3547003
Plug and Play 1.0a
Discharge battery via mouse click
66G3520
Non-disruptive battery exchange
39H7405
Standby, suspend, safe suspend,and
66G0108
hibernation modes
66G3618
US EPA Energy Star compliant
76H0119
Personalized nameplate in indention
39H7413
Personalization screen at startup
85G1957
International Warranty Service
45H8786
IBM SystemXtra Program
00K7903
24 hour / 7 day telephone, bulletin
board, fax, electronic, and Internet
(http://www.pc.ibm.com) support
IBM and dealer warranty/service
Online Housecall (remote diagnostics)
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(760XL) Compiled by Roger Dodson, IBM. December 1997
41H9720
29H9329
85G1522
49G2167
disks not supported)
29H9325
69H8414
45H8789
00K7902
